481MP86E: Description0 MHz - 5000 MHz RF/MICROWAVE WIDE BAND LOW POWER AMPLIFIER; CategoryTopical application Wireless rf/communication; File Size224KB，6 Pages; ManufacturerHittite Microwave（ADI）; Websitehttp://www.hittite.com/

Download Datasheet Parametric Compare View All

481MP86E Overview

0 MHz - 5000 MHz RF/MICROWAVE WIDE BAND LOW POWER AMPLIFIER

481MP86E Parametric

Parameter Name	Attribute value
Maximum input power	10 dBm
Number of terminals	4
Minimum operating frequency	0.0 MHz
Maximum operating frequency	5000 MHz
Minimum operating temperature	-40 Cel
Maximum operating temperature	85 Cel
Processing package description	ROHS COMPLIANT, PLASTIC, SMT, MICRO-P-4
each_compli	Yes
EU RoHS regulations	Yes
state	Active
Microwave RF Type	WIDE BAND LOW POWER
Impedance characteristics	50 ohm
structure	COMPONENT
Gain	9 dB
jesd_609_code	e3
Number of functions	1
Packaging Materials	PLASTIC/EPOXY
ckage_equivalence_code	SL,4GW-LD,.085CIR
wer_supplies__v_	8
sub_category	RF/Microwave Amplifiers
Maximum supply voltage	85 mA
Craftsmanship	BIPOLAR
terminal coating	MATTE TIN (394) OVER COPPER

Preview

Download Datasheet

View All

HMC481MP86

481MP86E

v03.0810

SiGe HBT GAIN BLOCK

MMIC AMPLIFIER, DC - 5 GHz

Typical Applications

Features

P1dB Output Power: +20 dBm

Gain: 20 dB

Output IP3: +33 dBm

Cascadable 50 Ohm I/Os

Single Supply: +6V to +12V

Included in the HMC-DK001 Designer’s Kit

AMPLIFIERS - DRIVER & GAIN BLOCK - SMT

The HMC481MP86 / HMC481MP86E is an ideal RF/

IF gain block & LO or PA driver for:

• Cellular / PCS / 3G

• Fixed Wireless & WLAN

• CATV, Cable Modem & DBS

• Microwave Radio& Test Equipment

Functional Diagram

General Description

The HMC481MP86 & HMC481MP86E are SiGe

Heterojunction Bipolar Transistor (HBT) Gain Block

MMIC SMT amplifiers covering DC to 5 GHz. This

Micro-P packaged amplifier can be used as a cas-

cadable 50 Ohm RF/IF gain stage as well as a LO

or PA driver with up to +21 dBm output power. The

HMC481MP86(E) offers 20 dB of gain with a +33 dBm

output IP3 at 850 MHz while requiring only 74 mA

from a single positive supply. The Darlington feedback

pair used results in reduced sensitivity to normal

process variations and excellent gain stability over

temperature while requiring a minimal number of

external bias components.

Electrical Specifi cations,

Vs= 8.0 V, Rbias= 39 Ohm, T

= +25° C

Parameter

DC - 1.0 GHz

1.0 - 2.0 GHz

2.0 - 3.0 GHz

3.0 - 4.0 GHz

4.0 - 5.0 GHz

DC - 5 GHz

DC - 1.0 GHz

1.0 - 5.0 GHz

DC - 1.0 GHz

1.0 - 4.0 GHz

4.0 - 5.0 GHz

DC - 5 GHz

0.5 - 1.0 GHz

1.0 - 2.0 GHz

2.0 - 3.0 GHz

3.0 - 4.0 GHz

4.0 - 5.0 GHz

0.5 - 2.0 GHz

2.0 - 3.0 GHz

3.0 - 4.0 GHz

4.0 - 5.0 GHz

DC - 2.0 GHz

2.0 - 4.0 GHz

4.0 - 5.0 GHz

Min.

18.5

15.5

12.5

10.5

9.0

Typ.

20.0

17.0

14.0

12.0

10.5

0.008

3.5

4.0

4.5

0.012

Max.

Units

dB/ °C

dBm

Gain

Gain Variation Over Temperature

Input Return Loss

Output Return Loss

Reverse Isolation

Output Power for 1 dB Compression (P1dB)

Output Third Order Intercept (IP3)

(Pout= 0 dBm per tone, 1 MHz spacing)

Noise Figure

Supply Current (Icq)

Note: Data taken with broadband bias tee on device output.

8-1

For price, delivery and to place orders: Hittite Microwave Corporation, 20 Alpha Road, Chelmsford, MA 01824

Phone: 978-250-3343

Fax: 978-250-3373

Order On-line at www.hittite.com

Application Support: Phone: 978-250-3343 or apps@hittite.com
