UltraSeal
®
Series
“F” Series 59 and 6 Connectors Product Information
Broadband
Products
Connector Specifications
Moisture Migration:
Passes SCTE interface
moisture migration test
(SCTE IPS TP 013)
Water Immersion:
Passes Bellcore water
immersion test
(GR-1503-CORE)
Shielding Effectiveness:
Exceeds Bellcore
GR-1503-CORE specifications
Insertion Loss:
Exceeds Bellcore
GR-1503-CORE specifications
Pull Force:
Typical pull force of
approximately 70 lbs.
exceeds both SCTE and
Bellcore GR-1503-CORE cable
pull strength specifications.
Port Interface:
Meets SCTE IPS SP 401
recommended “F” port
interface specification.
The UltraSeal
®
Series is the next generation
of high performance sealed compression
“F” connectors. This compression connector
series combines ease of installation with
superior performance features.
The UltraSeal 59 & 6 connector design
incorporates a free spinning nut making
installation faster and more reliable.
The one-piece design includes all brass
construction without any loose parts.
Connectorization can be performed rapidly
and consistently without the risk of
misalignment of multiple parts.
The UltraSeal compression technology
provides 360 degrees of contact to the cable,
providing excellent RF shielding integrity
and a complete seal to the cable jacket to
lock out moisture.
UltraSeal is a trademark of Corning Gilbert Inc., Glendale, Arizona.
© 2003 Corning Gilbert Inc. G-1400-504 03/03
Materials and Construction
of Connector Components :
One step cable preparation
of 1/4 ”[6.5 mm ] Braid and
Dielectric and 5/16: [8.0 mm ]
center conductor.
Product Features and Benefits
• Three point sealing system passes
the SCTE interface moisture migration
tests and Bellcore water immersion.
• A free-spinning sealed nut design
(Patent #5975591) permits the
7/16” nut to spin freely for easy
installation.The o-ring seals when
nut is tightened.
• 360° radial compression
(Patent #5997350) at the
connector/cable interface provides
excellent RF shielding and prevents
moisture migration.
• All brass construction, no plastic parts .
• One piece construction eliminates
lost components.
• One connector for both indoor and
outdoor applications.
• One step cable preparation.
• Uses commonly available compression
tools.
• Longer hex flats facilitates easier
installation.
• Cable series permanently marked on
connector for easy identification.
• For outdoor applications, the
Gilbert Seal Ring (G-SR-1/2) will
prevent moisture from entering the
connector/equipment interface on
ports which meet SCTE IPS SP 400.
Seal rings available for non-SCTE ports.
3/8-32 THD
Free Spinning
Sealed Nut
7/16 [11.1mm] Hex
Ordering Information
Cable Preparation Tool:
G-CPT-6560 or equivalent
Compression Tool:
G-CAT-UNIVERSAL-FX
or equivalent
Part Number
GF-US-59
GF-US-59Q
GF-US-6
GF-US-6Q
Color Code
Black
Green
Gold
Silver
Cable Type
Series 59
Series 59
Series 6
Series 6
Braid Coverage
60% to Tri shield
Quad
60% to Tri shield
Quad
Prep. Tool
G-CPT-6590
G-CPT-6590
G-CPT-6590
G-CPT-6590
Compression Tool
G-CAT-UNIVERSAL-FX
G-CAT-UNIVERSAL-FX
G-CAT-UNIVERSAL-FX
G-CAT-UNIVERSAL-FX
Corning Gilbert Inc.
Broadband Products
5310 W. Camelback Rd.
Glendale, AZ 85301 U.S.A.
phone:
800 528 5567 (U.S. and Canada)
(01) 623 245 1050 (International)
800 344 6358
(01) 623 931 0684
fax:
website: www.corning.com/corninggilbert
e-mail:
info-gilbert@corning.com
© 2003 Corning Gilbert Inc. G-1400-504 03/03
