150mA Low Noise LDO Regulator
FEATURES
Ultra Low Noise Output
High Output Voltage Accuracy
Guaranteed 150mA Output
Maximum Output Voltage of Adjustable type is 8.5V.
Low Quiescent Current
Low Dropout Voltage
Extremely Tight Load and Line Regulation
Very Low Temperature Coefficient
Current and Thermal Limiting
Reverse-battery Protection
“Zero” off-mode Current
Logic-controlled Enable
Moisture Sensitivity Level 3
SOT-23 5L
TJ5205
SOP-8PP
APPLICATION
Cellular Telephones
Laptop, Notebook, and Palmtop Computers
Battery-powered Equipment
PCMCIA V
CC
and V
PP
Regulation/Switching
Consumer/Personal Electronics
SMPS Post-regulator/DC to DC Modules
High-efficiency Linear Power Supplies
ORDERING INFORMATION
Device
TJ5205SF5-X.X
TJ5205SF5-ADJ
TJ5205DP-X.X
TJ5205DP-ADJ
Package
SOT-23 5L
SOP-8PP
X.X = Output Voltage = 2.5, 2.7, 2.8, 2.85, 2.9, 3.0, 3.3, 3.6,
3.8, 4.0, 5.0
DESCRIPSION
The TJ5205 is an efficient linear voltage regulator with ultra low-noise output, very low dropout voltage (typically
17mV at light loads and 165mV at 150mA), and very low ground current (600µA at 100mA output).
The TJ5205 offers better than 1% initial accuracy. Designed especially for hand-held, battery-powered devices,
the TJ5205 includes a CMOS or TTL compatible enable/shutdown control input. When shutdown, power
consumption drops nearly to zero.
Regulator ground current increases only slightly in dropout, further prolonging battery life.
Key TJ5205 features include a reference bypass pin to improve its already excellent low-noise performance,
reversed-battery protection, current limiting, and over temperature shutdown.
The TJ5205 is available in fixed and adjustable output voltage versions in SOT-23-5 PKG and SOP-8PP PKG.
And adjustable type’s maximum output voltage is 8.5V.
Absolute Maximum Ratings
(Note 1)
CHARACTERISTIC
Input Supply Voltage
Enable Input Voltage
Lead Temperature (Soldering, 5 sec)
Storage Temperature Range
Operating Junction Temperature Range
Dec. 2010 - Rev. 1.5.1
-
1
SYMBOL
V
IN
V
EN
T
SOL
T
STG
T
JOPR
MIN.
-0.3
-0.3
-
-65
-40
MAX.
20
20
260
150
125
UNIT
V
V
℃
℃
℃
-
