B09TKTB

Description
General Purpose Inductor, 0.0355uH, 10%, 1 Element, Air-Core, SMD, ROHS COMPLIANT
CategoryPassive components    inductor
File Size123KB,2 Pages
ManufacturerCOILCRAFT
Websitehttp://www.coilcraft.com/
Environmental Compliance
Download Datasheet Parametric View All

B09TKTB Overview

General Purpose Inductor, 0.0355uH, 10%, 1 Element, Air-Core, SMD, ROHS COMPLIANT

B09TKTB Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerCOILCRAFT
Reach Compliance Codecompliant
ECCN codeEAR99
core materialAIR
DC Resistance0.0068 Ω
Nominal inductance(L)0.0355 µH
Inductor ApplicationsRF INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
JESD-609 codee1
Manufacturer's serial numberB09T
Number of functions1
Number of terminals2
Maximum operating temperature140 °C
Minimum operating temperature-40 °C
Minimum quality factor (at nominal inductance)112
self resonant frequency1500 MHz
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldNO
special characteristicsQ MEASURED AT 150MHZ
surface mountYES
Terminal surfaceTin/Silver/Copper (Sn/Ag/Cu)
Terminal locationDUAL ENDED
Terminal shapeWIRE
Tolerance10%
Document 107-1
Mini Spring
Air Core Inductors
• Small air core inductors feature high Q and tight tolerances
• Acrylic jacket provides a flat top for pick and place
• Solder coated leads ensure reliable soldering
Designer’s Kit C302
contains 12 each of all 5% values.
Kit C302-2 contains12 each of all 2% values.
Terminations
RoHS compliant tin-silver over copper. Other
terminations available at additional cost.
Ambient temperature
–40°C to +125°C with
Irms
current, +125°C
to +140°C with derated current
Storage temperature
Component: –40°C to +140°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+5 to +70 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Mean Time Between Failures (MTBF)
One billion hours
Packaging A0xT:
700/7″ reel; 2500/13″ reel Plastic tape: 12 mm wide,
0.32 mm thick, 8 mm pocket spacing, 3.3 mm pocket depth
BxxT:
500/7″ reel; 2200/13″ reel Plastic tape: 16 mm wide, 0.28 mm
thick, 8 mm pocket spacing, 3.4 mm pocket depth
PCB washing
Only pure water or alcohol recommended
SRF
DCR
Part
L
2
Percent Q
4
min
5
max
6
Irms
7
Weight
1
Turns (nH)
3
number
tol
min (GHz) (mOhm) (A)
(mg)
A01TKL_
1
2.5
10
145 12.5
1.1
4
31
A02T_L_
2
5.0
5,2
140
6.5
1.8
4
42
A03T_L_
3
8.0
5,2
140
5.0
2.6
4
52
A04T_L_
4
12.5
5,2
137
3.3
3.4
4
65
A05T_L_
5
18.5
5,2
132
2.5
3.9
4
78
B06T_L_
6
17.5
5,2
100
2.2
4.5
4
100
B07T_L_
7
22.0
5,2
102
2.1
5.2
4
110
B08T_L_
8
28.0
5,2
105
1.8
6.0
4
118
B09T_L_
9
35.5
5,2
112
1.5
6.8
4
133
B10T_L_
10
43.0
5,2
106
1.2
7.9
4
147
1. When ordering, please specify
tolerance, termination
and
packaging
codes:
A02TGLC
Tolerance: G
= 2%
J
= 5%
K
= 10% (Table shows stock tolerances in bold.)
Termination: L
= RoHS compliant tin-silver (96.5/3.5) over copper.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic tape,
700 (AxxT) or 500 (BxxT) parts per full reel.
B
= Less than full reel. In tape, but not machine-ready. To have
a leader and trailer added ($25 charge), use code letter C
instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic tape.
Factory order only, not stocked, 2500 (AxxT) or 2200 (BxxT)
parts per full reel.
2. Inductance measured with an Agilent/HP 4286, a Coilcraft SMD-A and correlation.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured at 150 MHz using an Agilent/HP 4291A with an Agilent/HP 16193A
test fixture.
5. SRF tested on an Agilent/HP 8720D and a Coilcraft SMD-D test fixture.
6. DCR tested on the Cambridge Technology Model 510 Micro-ohmmeter.
7. Current that causes a 15°C temperature rise from 25°C ambient.
8. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
A
D
Encapsulant
E
C
B
F
Size A max
A
0.155
3,94
B
0.270
6,86
B max
0.175
4,45
0.175
4,45
C max
0.124
3,15
0.124
3,15
D
E
0.125 ±0.010 0.115 ±0.010
3,18 ±0,25
2,92 ±0,25
0.125 ±0.010 0.230 ±0.015
3,18 ±0,25
5,84 ±0,38
F max
0.029
0,74
0.029
0,74
Strip
max
Length
135°
0° min
Recommended Land Patterns
Size A
0.050
1,27
0.130
3,30
Size B
0.050
1,27
0.130
3,30
0.110
2,79
0.110
2,79
0.115
2,92
Dimensions are in
inches
mm
0.235
5,97
Specifications subject to change without notice.
Please check our website for latest information.
Document 107-1
Revised 10/29/08
© Coilcraft, Inc. 2008
