5 WATTS OUTPUT POWER
2:1 AND 4:1 WIDE INPUT VOLTAGE RANGE
FIVE-SIDED SHIELD
HIGH EFFICIENCY UP TO 84%
STANDARD 24 PIN DIP PACKAGE
FIXED SWITCHING FREQUENCY
T E C H N I C A L S P E C I F I C AT I O N
OUTPUT SPECIFICATIONS
Output power
Voltage accuracy
Minimum load (Note 1)
Line regulation
Load regulation
Cross regulation(Dual)
Ripple and noise
Temperature coefficient
Transient response recovery time 25% load step change
Over load protection
Short circuit protection
% of FL at nominal input
LL to HL at Full Load
Single
25% to 100% FL
Dual
Asymmetrical load 25% / 100%
FL
20MHz bandwidth
Full load and nominal Vin
All specifications are typical at nominal input, full load and 25ºC otherwise noted
GENERAL SPECIFICATIONS
5 Watts, max
± 1%
10% of FL
± 0.2%
± 0.5%
± 1%
± 5%
50mVp-p
±0.02%
/ ºC, max
200uS
170%, typ
Isolation resistance
Isolation capacitance
Switching frequency
Case material
Base material
Potting material
Dimensions
Weight
MTBF (Note 3)
Efficiency
Isolation voltage
Input to Output
Input ( Output ) to Case
See table
1600VDC, min
1600VDC, min
10 ohms, min
300pF, max
300KHz, typ
Nickel-coated copper
Non-conductive black plastic
Epoxy (UL94-V0)
1.25 X 0.80 X 0.40 Inch
(31.8 X 20.3 X 10.2 mm)
16g (0.55oz)
3.165 x 10 hrs
6
9
Continuous, automatics recovery
INPUT SPECIFICATIONS
MT5A
Input voltage range
MT5A-W
Input filter
Input surge voltage
100mS max
Input reflected ripple
Start up time
12V input
24V input
48V input
Nominal Vin and full load
Power up
12V nominal input
24V nominal input
48V nominal input
24V nominal input
48V nominal input
9 – 18VDC
18 – 36VDC
36 – 75VDC
9 – 36VDC
18 – 75VDC
Pi type
36VDC
50VDC
100VDC
20mAp-p
450mS, max
ENVIRONMENTAL SPECIFICATIONS
Operating temperature range
Maximum case temperature
Storage temperature range
Thermal impedance
Thermal shock
Vibration
Relative humidity
Nature convection
Standard
-25ºC~+85ºC (with derating)
M1 (Note 2)
-40ºC~+85ºC (non-derating)
M2 (W series) -40ºC~+85ºC (with derating)
+100ºC
-55ºC ~ +105ºC
20ºC/watt
MIL-STD-810D
10~55Hz, 10G, 30minitues along X,Y and Z
5% to 95% RH
Nominal Vin and
constant resistive load
EMC CHARACTERISTICS
Conducted emissions
Radiated emissions
ESD
Radiated immunity
Fast transient
Surge
Conducted immunity
EN55022
EN55022
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
Class A
Class A
Perf. CriteriaB
Perf. CriteriaA
Perf. CriteriaB
Perf. CriteriaB
Perf. CriteriaA
Kaga Electronics (USA) Inc.
2480 N. First St, Suite #100
San Jose, CA 95131
Tel: (408)570-0955 Fax: (408)570-0186
www.volgen.com
Efficiency
(5)
(%)
76
78
82
81
78
81
84
75 (76)
77 (79)
81 (81)
81 (84)
80 (78)
84 (82)
81 (84)
74 (73)
77 (79)
82 (80)
81 (82)
78 (76)
82 (80)
83 (80)
Model
Number
MT5A-1233SI
MT5A-1205SI
MT5A-1212SI
MT5A-1215SI
MT5A-1205WI
MT5A-1212WI
MT5A-1215WI
MT5A-2433SI (W)
MT5A-2405SI (W)
MT5A-2412SI (W)
MT5A-2415SI (W)
MT5A-2405WI (W)
MT5A-2412WI (W)
MT5A-2415WI (W)
MT5A-4833SI (W)
MT5A-4805SI (W)
MT5A-4812SI (W)
MT5A-4815SI (W)
MT5A-4805WI (W)
MT5A-4812WI (W)
MT5A-4815WI (W)
Input
Range
9 – 18 VDC
9 – 18 VDC
9 – 18 VDC
9 – 18 VDC
9 – 18 VDC
9 – 18 VDC
9 – 18 VDC
18 – 36 (9 – 36) VDC
18 – 36 (9 – 36) VDC
18 – 36 (9 – 36) VDC
18 – 36 (9 – 36) VDC
18 – 36 (9 – 36) VDC
18 – 36 (9 – 36) VDC
18 – 36 (9 – 36) VDC
36 – 75 (18 – 75) VDC
36 – 75 (18 – 75) VDC
36 – 75 (18 – 75) VDC
36 – 75 (18 – 75) VDC
36 – 75 (18 – 75) VDC
36 – 75 (18 – 75) VDC
36 – 75 (18 – 75) VDC
Output
Voltage
3.3 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
Output
Current
1000mA
1000mA
470mA
400mA
± 500mA
± 230mA
± 190mA
1000mA
1000mA
470mA
400mA
± 500mA
± 230mA
± 190mA
1000mA
1000mA
470mA
400mA
± 500mA
± 230mA
± 190mA
Input
Current
(4)
382mA
563mA
603mA
649mA
563mA
597mA
594mA
194mA (191mA)
285mA (278mA)
305mA (305mA)
325mA (312mA)
274mA (282mA)
288mA (295mA)
308mA (297mA)
98mA (100mA)
143mA (138mA)
151mA (155mA)
162mA (160mA)
141mA (145mA)
147mA (151mA)
150mA (156mA)
Note
1.
2.
3.
4.
5.
6.
The MT5A series required a minimum 10% loading on the output to maintain specified regulation. Operation under no-load condition will not
damage these devices, however they may not meet all listed specification.
BELLCORE TR-NWT-000332. Case 1：
50% Stress, Temperature at 40ºC. (Ground fixed and controlled environment)
M1 version is more efficient, therefore, it can be operated in a more extensive temperature range
than standard and M2 version
Maximum value at nominal input voltage and full load of standard type.
Typical value at nominal input voltage and full load
There is no pin at PIN10 & PIN15 for MT5A-W series
OUTPUT POWER (%)
120
100
80
60
40
20
0
-25
-5
15
35
55
75
95
115
1. All dimensions in Inches (mm)
Tolerance : x.xx±0.02(x.x±0.5)
x.xxx±0.01(x.xx±0.25)
2. Pin pitch tolerance
±0.014(0.35)
AMBIENT TEMPERATURE(℃)
DIP PIN CONNECTION
PIN
2
3
9
10
11
SINGLE
- INPUT
- INPUT
DUAL
- INPUT
- INPUT
PIN
23
22
16
15
14
SINGLE
+ INPUT
+ INPUT
DUAL
+ INPUT
+ INPUT
NC
COMMON
NC (Note6) NC (Note6)
NC
- OUTPUT
- OUTPUT COMMON
NC (Note6) NC (Note6)
+ OUTPUT + OUTPUT
Talking
