SMV1960L-LF
PHASE NOISE (1 Hz BW, typical)
14118 Stowe Drive, Suite B | Poway, CA 92064
TEL: (858) 621-2700 | FAX: (858) 486-1927
URL: www.zcomm.com
EMAIL: applications@zcomm.com
Rev A1
Applications
•
Digital Radio
•
PCS Handhelds
•
Application Notes
• AN-101: Mounting and Grounding
• AN-102: Output Loading
• AN-107: Manual Soldering
£(f) (dBc/Hz)
Voltage-Controlled Oscillator
Surface Mount Module
OFFSET (Hz)
Performance Specifications
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW)
Harmonic Suppression (2nd)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance
Pushing
Pulling (14 dB Return Loss, Any Phase)
Operating Temperature Range
Package Style
Power Supply Requirements
Supply Voltage (Vcc, nom.)
Supply Current (Icc)
Additional Notes
Min
1938
Typ
-90
-14
Max
1983
-8
4
Units
MHz
dBc/Hz
dBc
Vdc
MHz/V
dBm
pF
MHz/V
MHz
°C
1
100
10
13.25
50
16.5
50
9
19
-40
SUB-L
Min
Typ
5
20
85
Max
25
Units
Vdc
mA
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 1 of 2
FRM-S-002 B
Voltage-Controlled Oscillator
Surface Mount Module
Tuning Curve, typ.
2170
2120
SMV1960L-LF
Rev A1
FREQUENCY (MHz)
2070
2020
1970
1920
1870
1820
1770
1720
1670
1620
0
0.5
1
1.5
2
2.5
3
3.5
4
85 °C
25 °C
-40 °C
TUNING VOLTAGE (Vdc)
Power Curve, typ.
Footprint
POWER OUTPUT (dBm)
14
13
12
11
10
9
8
7
6
5
4
1673
1730
1783
1833
1888
1942
2001
2056
2108
RECOMMENDED FOOTPRINT
SEVERAL HOLES OF O0.015 ON
GND. PLANE ARE RECOMMENDED
FOR GOOD GROUNDING.
0.030 MIN. CUTBACK
FROM LIVE PADS
FREQUENCY (MHz)
85 °C
25 °C
-40 °C
Physical Dimensions
PIN CONFIGURATION
Z-COMM
XXXXXXXX-LF
W/O#
D/C
P1
P2
P3
REST
Vt
RF Out
Vcc
GROUND
PACKAGE
SUB MINI
SUB MINI-L
H
0.110
0.080
NOTE: ALL DIMENSIONS ARE IN INCHES
TOL: XXX: +/- 0.010
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 2 of 2
FRM-S-002 B
