Compact Film Chip Resistors
MCR006 (0201 size : 1 / 20W)
Features
1) Extremely small light
Area ratio is 60% smaller than that of chip 0402, while weight ratio has been cut 80%.
2) Highly reliable chip resistor
Ruthenium oxide dielectric offers superior resistance to the elements.
3) Electrodes not corroded by soldering
Thick film makes the electrodes very strong.
4) Flat surface further facilitates mounting
5) ROHM resistors have approved ISO9001- / ISO/TS 16949- certification.
Design and specifications are subject to change without notice. Carefully check the specification sheet supplied
with the product before using or ordering it.
Ratings
Item
Rated power
Conditions
Power must be derated according to the power derating curve in
Figure 1 when ambient temperature exceeds 70°C.
100
80
POWER LOAD (%)
Specifications
0.05W (1 / 20W)
at 70°C
60
40
20
0
−55
0
70
100
125
AMBIENT TEMPERATURE (°C)
Fig.1
Rated voltage
The voltage rating is calculated by the following equation.
If the value obtained exceeds the limiting element voltage,
the voltage rating is equal to the maximum operating voltage.
E: Rated voltage (V)
P: Rated power (W)
R: Nominal resistance (Ω)
E= P×R
Nominal resistance
Operating temperature
See Table 1.
Limiting element voltage
25V
−55°C
to
+125°C
Jumper type
Resistance
Rated current
Max. 50mΩ
0.5A
Table 1
Resistance tolerance
J (±5%)
F (±1%)
D (±0.5%)
Resistance range
(Ω)
1.0 to 9.1
10 to 10M
10 to 10M
10 to 910
1k to 1M
(E24)
(E24)
(E24)
(E24)
(E24)
Resistance temperature coefficient
(ppm /
°C)
+600/−200
±250
±250
±200
±100
Operating temperature
−55°C
to
+125°C
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
1/3
2011.06 - Rev.H
MCR006 (0201 size : 1 / 20W)
Characteristics
Item
Resistance
Guaranteed value
Resistor type
Jumper type
J :
±5%
F :
±1%
D :
±0.5%
See Table.1
±
(2.0%+0.1Ω)
Max. 50mΩ
Test conditions (JIS C 5201-1)
JIS C 5201-1 4.5
Data Sheet
Variation of resistance
with temperature
Overload
Max. 50mΩ
JIS C 5201-1 4.8
Measurement :
+20
/
−55
/
+20
/
+125°C
JIS C 5201-1 4.13
Rated voltage (current)
×2.5,
2s.
Limiting element voltage
×2
: 50V
JIS C 5201-1 4.17
Rosin·Ethanol (25%WT)
Soldering condition : 235±5°C
Duration of immersion : 2.0±0.5s.
JIS C 5201-1 4.18
Soldering condition : 260±5°C
Duration of immersion : 10±1s.
JIS C 5201-1 4.19
Test temp. :
−55°C
to
+125°C
100cyc
JIS C 5201-1 4.24
40°C, 93%RH
Test time : 1,000h to 1,048h
JIS C 5201-1 4.25.1
Rated voltage (current), 70°C±3°C
1.5h : ON
−
0.5h : OFF
Test time : 1,000h to 1,048h
JIS C 5201-1 4.25.3
125°C
Test time : 1,000h to 1,048h
JIS C 5201-1 4.29
23±5°C, Immersion cleaning, 5±0.5min.
Solvent : 2-propanol
JIS C 5201-1 4.33
Max. 50mΩ
Solderability
A new uniform coating of minimum of
95% of the surface being immersed
and no soldering damage.
±
(1.0%+0.05Ω)
Max. 50mΩ
No remarkable abnormality on the appearance.
±
(1.0%+0.05Ω)
±
(3.0%+0.1Ω)
Max. 50mΩ
Max. 100mΩ
Resistance to
soldering heat
Rapid change of
temperature
Damp heat, steady state
±
(3.0%+0.1Ω)
Endurance at 70°C
±
(3.0%+0.1Ω)
Endurance
±
(1.0%+0.05Ω)
Resistance to solvent
Max. 100mΩ
Max. 100mΩ
Max. 50mΩ
Bend strength of
the end face plating
±
(1.0%+0.05Ω)
Max. 50mΩ
Without mechanical damage such as breaks.
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
2/3
2011.06 - Rev.H
