BN/BT Series T1 3/4
Right Angle LED Bar*
Special Features
*Patented
• Customized to your specifications without tooling charges
— Variable LED spacing, minimum .245˝ maximum bar length 6˝
— Variable color sequence
• Available with 2 to 24 T1 3/4 LEDs in one convenient assembly
• Available with a variety of LEDs
• Bar provides consistent LED alignment for multiple LED mounting
• Available in two LED configurations—direct cross to industry
standard 5mm right angle LED.
• Wave solderable and chemically cleanable
• Housing and bar material UL 94V-0 rated
5mm PC Board Mount LEDs
Package Dimensions
6.0 MAX.
(152.4)
.245
MAX.
(6.2)
.030
(.76)
.245
MAX.
(6.2)
.100
(2.54)
.015 (.38)
.030 (.76)
.020 SQ.
(0.5)
Electrical and Optical Characteristics (TA=25°C)
LED
Part#
Color
Luminous
Intensity (mcd)
Typ.@IF(mA)
VF Typ.@IF (mA)
Viewing
Angle
2Θ
2
Peak
More
Wavelength LED Data
(mm)
Page#
.245 MIN.
(6.2)
HIGH EFFICIENCY
9102
9103
9104
9105
Red
Green
Yellow
Orange
5.6
5.6
5.6
5.6
10
10
10
10
2.0
2.2
2.1
2.0
20
20
20
20
60°
60°
60°
60°
635
565
585
630
24
24
24
24
LOW CURRENT
9121
9122
9123
Red
Yellow
Green
2.5
1.6
1.6
2
2
2
1.7
1.9
1.8
2
2
2
60°
60°
60°
625
590
565
25
25
25
BEVELED CORNER
BEVELED CORNER
FOR CATHODE LEAD
FOR CATHODE LEAD
(Red/Yellow cathode for bicolor)
(Red/Yellow Cathode for Bico
BN
.122 (3.1)
BT
.030
(.76)
.328
(8.3)
5V INTERNAL RESISTOR
9124
9126
9125
Red
Green
Yellow
16.0
16.0
16.0
12
12
12
5.0
5.0
5.0
12
12
12
60°
60°
60°
625
565
590
26
26
26
.19
(4.8)
.255
(6.5)
.245
MAX.
(6.2)
.13
(3.3)
.100
(2.54)
(.38)
.200
(5.0)
BICOLOR
9109
9128
Red
Green
Yellow
Green
38.0
13.0
10.0
20.0
20
20
20
20
2.0
2.2
2.1
2.2
20
20
20
20
60°
60°
660
565
590
565
27
27
.148
(3.75)
FN
.190
(4.8)
FT
.130
(3.3)
ULTRA BRIGHT
9129
9130
9131
Red
Green
Yellow
80.0
50.0
80.0
10
10
10
2.0
2.2
2.1
10
10
10
30°
30°
30°
625
565
590
24
24
24
.122
(3.1)
.020 SQ.
(0.5)
.200
(5.0)
.225
(5.7)
SUPER ULTRA BRIGHT
9132
9133
Red
Green
1500.0
250.0
20
20
1.85
2.2
20
20
30°
30°
660
565
29
29
.200
(5.0)
.225
(5.7)
All Dimensions are in inches (mm)
How To Order
INDIVIDUAL RA LEDs
MULTIPLE RA LEDs ON A BAR
x x R A x — x x x x
Bar mountable = B
Flat style = F
Configuration
N = .19"
T = .13"
LED Color
Red = R
Yellow = Y
Green = G
Orange = O
Bicolor = B
x B x R A x — x x x x — x x x
# of LEDs
Per Bar
Configuration
N = .19"
T = .13"
LED Color
Red = R
Yellow = Y
Green = G
Orange = O
Bicolor = B
Multiple = M
See LED Chart
for Part #
(Use MCOO
for multiple
colors)
Center to Center
Spacing of LEDs
in inches
(If spacing varies,
use SPL)
See LED Chart
for Part #
®
WILBRECHT
ELECTRONICS, INC.
LEDCO
DIVISION
7
1400 Energy Park Drive, Suite 18 • St. Paul, MN 55108-5248 • (651) 659-0919 • Toll free (888) 323-8751 • FAX (651) 659-9204 • www.wilbrecht.com
