SWWC-13-P-8-G-2-L-2 datasheet, PDF

Datasheet> All Categories > Wireless rf/communication> Optical fiber> SWWC-13-P-8-G-2-L-2

SWWC-13-P-8-G-2-L-2: DescriptionSplitter/Coupler, 1X3 Port, 80/10 Ratio, FC/APC Connector; CategoryWireless rf/communication Optical fiber; File Size216KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

SWWC-13-P-8-G-2-L-2 Overview

Splitter/Coupler, 1X3 Port, 80/10 Ratio, FC/APC Connector

SWWC-13-P-8-G-2-L-2 Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknown
Connection Type	FC/APC CONNECTOR
Fiber optic equipment types	SPLITTER/COUPLER
Fiber type	SMF-28
Maximum insertion loss	5.5 dB
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Nominal operating wavelength	1510 nm
Port configuration	1X3
minimum return loss	50 dB
Split ratio/coupling ratio	80/10

Preview

Download Datasheet

View All

FBT COUPLER

1 x 3 Single Fused Single Window Wideband Coupler

Parameter

Operating Wavelength Range

Insertion Loss (Max)

Uniformity (Typical)

Return Loss

PDL

TDL

Operating & Storage Temperature

Package Dimensions

Light Duty ( B )

Medium Duty ( L )

Premium

1311 or 1550 ± 40 nm

≤ 5.5 dB

≤ 0.8 dB

≥ 50

≤ 0.15 dB

≤ 0.2dB (- 10° C ~ + 75° C)

A Grade

≤ 6.0 dB

≤ 1.2 dB

≤ 0.15 dB

≤ 0.4dB (- 40° C ~ + 85° C)

- 40° C ~ + 85° C

3.0mm (Φ) x 55.0mm (L)

3.0mm (Φ) x 70.0mm (L)

Tap Coupler

Coupling

Ratio

10/45/45

20/40/40

30/35/35

40/30/30

50/25/25

60/20/20

70/15/15

80/10/10

Max Insertion Loss

Premium

11.5/4.6/4.6 dB

8.2/5.2/5.2 dB

6.2/5.6/5.6 dB

5.2/6.2/6.2 dB

4.2/7.2/7.2 dB

3.4/8.3/8.3 dB

2.6/9.6/9.6 dB

2.2/11.0/11.0 dB

A Grade

11.8/4.8/4.8 dB

8.5/5.4/5.4 dB

6.5/5.8/5.8 dB

5.5/6.5/6.5 dB

4.4/7.5/7.5 dB

3.5/8.5/8.5 dB

2.8/9.8/9.8 dB

2.4/11.5/11.5 dB

Note1: All values specified are without connectors.

Note3: Fiber type Corning SMF-28e.

S W WC - 1 3 -

Port Number

13: 1 x 3

Grade

P: Premium

A: A Grade

Coupling Ratio

R: as above

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

Wavelength

E: 1310 nm

F: 1480 nm

G: 1510 nm

H: 1550 nm

L: 1625 nm

Fiber Length

Pigtail Style

1: 1 meter

(=Package style)

2: 2 meter

B: bare fiber

S: Special

L: 900 µm loose tube

www.lighteltech.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.
