WDM4-22-A-2-R-3 datasheet, PDF

Datasheet> All Categories > Wireless rf/communication> Optical fiber> WDM4-22-A-2-R-3

WDM4-22-A-2-R-3: DescriptionWavelength Division Mux/Demux, 1535nm Min, 1565nm Max, 2X2 Port, SC/PC Connector; CategoryWireless rf/communication Optical fiber; File Size205KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

WDM4-22-A-2-R-3 Overview

Wavelength Division Mux/Demux, 1535nm Min, 1565nm Max, 2X2 Port, SC/PC Connector

WDM4-22-A-2-R-3 Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknown
Connection Type	SC/PC CONNECTOR
Fiber optic equipment types	WAVELENGTH DIVISION MUX/DEMUX
Maximum insertion loss	0.5 dB
Minimum isolation	18 dB
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum operating wavelength	1565 nm
Minimum operating wavelength	1535 nm
Nominal operating wavelength	1550 nm
Port configuration	2X2
minimum return loss	55 dB

Preview

Download Datasheet

View All

FBT WDM

Wavelength Division Multiplexer 980/1550 nm

Parameter

Operating Wavelength Range

Insertion Loss

Isolation

TDL

Return Loss

PDL

Operating & Storage Temperature

Package Dimensions

Light Duty ( B )

Medium Duty ( L )

Heavy Duty ( K, R )

Premium

A Grade

980 ± 10 nm / 1550 ± 15 nm

≤ 0.3 dB

≥ 20 dB

≤ 0.2 dB

≥ 55 dB

≤ 0.1 dB

- 40° C ~ + 85° C

3.0mm () x 60.0mm (L)

3.0mm () x 65.0mm (L)

100.0mm x 12.0mm x 8.0mm

≤ 0.5dB

≥ 18 dB

Note 1: All values specified are without connectors.

Note 2: Higher performance specifications available upon request.

Note 3: Fiber Type – OFS 980 fiber unless otherwise specified.

W D M 4 -

Port Number

12: 1 x 2

22: 2 x 2

Grade

P: Premium

A: A Grade

Fiber Length

1: 1 meter

2: 2 meter

S: Special

Pigtail Style

(=Package style)

B: bare fiber

L: 900

m

loose tube

K: 2mm cable

R: 3mm cable

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

www.lightel.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax
