836-FREQ-AF datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> oscillator> 836-FREQ-AF

836-FREQ-AF: DescriptionHCMOS Output Clock Oscillator, 1MHz Min, 80MHz Max, ROHS COMPLIANT, SMD, 4 PIN; CategoryPassive components oscillator; File Size448KB，2 Pages; ManufacturerFOX [Fox Electronics]; Environmental Compliance

Download Datasheet Parametric View All

836-FREQ-AF Overview

HCMOS Output Clock Oscillator, 1MHz Min, 80MHz Max, ROHS COMPLIANT, SMD, 4 PIN

836-FREQ-AF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	FOX [Fox Electronics]
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	ENABLE/DISABLE FUNCTION; TAPE AND REEL
maximum descent time	6 ns
Frequency Adjustment - Mechanical	NO
frequency stability	100%
JESD-609 code	e4
Installation features	SURFACE MOUNT
Maximum operating frequency	80 MHz
Minimum operating frequency	1 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Oscillator type	HCMOS
Output load	15 pF
physical size	2.1mm x 1.7mm x 0.8mm
longest rise time	6 ns
Maximum supply voltage	1.98 V
Minimum supply voltage	1.62 V
Nominal supply voltage	1.8 V
surface mount	YES
maximum symmetry	55/45 %
Terminal surface	Gold (Au) - with Nickel (Ni) barrier

Preview

Download Datasheet

View All

HCMOS 2.0x1.6mm 1.8V SMD Oscillator

Model: F110 SERIES

Page 1 of 2

RoHS Compliant / Pb Free

Rev. 3/9/2011

http://www.foxonline.com/need_a_sample.htm

FEATURES

• 1.8V Operation

• Standby Function

• Tape and Reel

(3,000 pcs. STD)

• PART nUMbER SELECTIOn

Learn More - Internet Required

Part Number

836-Frequency-xxxxx

836A-Frequency-xxxxx

836B-Frequency-xxxxx

836C-Frequency-xxxxx

836D-Frequency-xxxxx

Model Frequency

Operating

Number Stability Temperature (ºC)

±100PPM

-20 ~ +70

F110

-40 ~ +85

F110R

±100PPM

±50PPM

-20 ~ +70

F115

-40 ~ +85

F115R

±50PPM

±25PPM

-10 ~ +60

F116

Frequency

Range (MHz)

1.000 ~ 80.000

T op V iew

2 .1 M ax

1 .7 M ax

• ELECTRICAL CHARACTERISTICS

PARAMETERS

Frequency Range (F

)

Storage Temperature Range (T

stg

)

Supply Voltage

)

Input Current

)

1.000000 ~ 40.000000 MHz

40.000001 ~ 60.000000 MHz

60.000001 ~ 80.000000 MHz

Output Symmetry (50% V

)

Rise Time (10% ~ 90% V

)

Fall Time (90% ~ 10% V

)

Output Voltage

)

Output Current

)

Output Load

(HCMOS)

Standby Current

Start-up Time

)

Output Disable Time

Output Enable Time

Maximum Soldering Temp / Time

Moisture Sensitivity Level (MSL)

Termination Finish

D o t de notes

pin1.

0 .8 M ax

MAX

(unless otherwise noted)

1.000~ 80.000 MHz

-40ºC ~ +85ºC

1.8V ± 10%

5mA

10mA

15mA

45% ~ 55%

6nS

10% V

90% V

Min

4mA Min

-4mA Min

15pF

10µA

5mS

50uS

5mS

260ºC / 10 Seconds

Au over Ni

0 .5

0 .6

0 .7

0 .5

B ottom

V iew

R e com m ended

S old er P ad La yout

0 .75

0 .65

0 .35

0 .55

All dimensions are in millimeters.

Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change,

reflow freq. shift and one year aging.

Inclusive of 25ºC tolerance and operating temperature range.

An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.

Notes: A 0.01µF capacitor should be placed between V

(Pin 4) and GND (Pin2) to minimize

power supply noise.

Dimensional drawing is for reference to critical specifications defined by size measurements.

Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may

vary.

All specifications subject to change without notice.

Pin Connection

#1 E/D

#2 GND

#3 Output

#4 V

• EnAbLE / DISAbLE FUnCTIOn

Pin 1

OUTPUT (Pin 3)

OPEN

ACTIVE

'1' Level V

≥

70% V

ACTIVE

'0' Level V

≤

30% V

High Z

FOXElectronics

5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554

www.foxonline.com

EMEA

Tel: +44 .11283.568153 |

Canada

+1.888.438.2369 |

Asia

Hong Kong Tel: +852.2854.4285 |

Japan

Tel: +81.3.3374.2079
