MICRO USB 2.0
Series 805 Mighty Mouse
805-082 and 805-083 Plug with USB Micro “B”
Male Interface to Crimp Removable Contacts
How To Order
Sample Part Number
Series
Shell Style
Shell Material and Finish
1
805-082
805-082
= Shield Termination Porch
805-083
= Accessory Threads
16
= Plug with Anti-decoupling Spring
-16 MUSB
-M
A
NF
= AL/Cadmium, Olive Drab
M
= AL/Electroless Nickel
MT
= AL/Nickel PTFE
ZNU
= AL/Black Zinc Nickel
A, B, C, D, E, F
Plug and Rear View of
Crimp Termination
Aternate Key Positions
1
805-082 PLUG WITH INTEGRAL SHIELD TERMINATION PORCH, SHELL SIZE 10
1, 2
EMI/RFI Spring
.6250-.1P-.3L-TS-2B
Master Key
Pin ID 1
V
D-
D+
G
ID
ø.473 (12.01)
ø.830 (21.08)
.073 (1.85)
Rear Grommet
View
1.131 (28.73)
Micro ‘B’
USB Plug
54321
Micro B USB Male Interface
805-083 PLUG WITH INTEGRAL ACCESSORY THREAD, SHELL SIZE 10
1, 2
.5000-28 UNEF-2A
EMI/RFI Spring
.6250-.1P-.3L-TS-2B
Master Key
Pin Id 1
V
D-
D+
G
ID
Ø.830 (21.08)
.073 (1.85)
Rear Grommet
View
1.131 (28.73)
Micro ‘B’
USB Plug
54321
Micro B USB Male Interface
NOTES
1. See Section A for alternate keyway positions and additional
finishes.
2. These plug connectors mate with Glenair receptacles 805-084,
805-085, 805-089 and 805-090.
Wire Schematic
Rear Grommet Side
Label Cable Color (Typ)
V
Red
G
Black
D-
White
D+
Green
ID
None
ID
1
2
3
4
5
Mating Side
Micro USB Pin Description
VBUS (V)
D-
D+
ID
GND (G)
Ground
© 2016 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • SuperSeal™ Catalog
Dimensions in Inches (millimeters) are subject to change without notice.
J-11
Series 805 Triple Start
