Series 804 Push-Pull Mighty Mouse
Rubber Covers
809-083 and 809-087
A
B
C
E
F
G
G
J
K
L
Protective Cover for
use with Series 804
Receptacles
M
© 2010 Glenair, Inc.
Series 804
These
splashproof molded rubber covers
fit all Series 804 plugs and receptacles.
Braided black nylon lanyard is available
with metal rings, cable tie or slipknot for
attachment to panel or to cable.
809-083 Plug Cover
809-087 receptacle Cover
hoW to oRDER
Sample Part Number
809-083
Series
- 05
G
6
- SK
Attachment Code
C
Conductive
Rubber
Omit for
Standard
Neoprene
Shell Size Lanyard type
-05
-06
-07
-08
-09
-10
-12
-14
-G
Lanyard
Length
Length in
Inches
Nylon Rope
(Omit for no
lanyard)
Nylon Cable Tie, 1.77 Inch (45mm) Maximum Wire
Bundle Diameter
-WS
Protective Cover for
use with Series 804
Plugs
809-083
Slip Knot
-SK
Conductive
Rubber
C
Lanyard With No Attachment (Fused End)
-00
Lug terminals and Rings
-01
-02
-05
-06
-07
-08
-09
-10
-11
-12
-15
-16
-17
-18
-19
-20
-21
-25
–
–
–
–
.126 (3.20) I.D.
.145 (3.68) I.D.
.188 (4.78) I.D.
.197 (5.00) I.D.
Lug Terminal
809-087
Solid Ring
– .385 (9.78) I.D.
– .510 (13.11) I.D.
– .583 (14.81) I.D.
– .766 (19.4) I.D.
– .896 (25.76) I.D.
– 1.015 (25.78) I.D.
– .445 (11.30) I.D.
– .570 (14.48) I.D.
– .635 (16.13) I.D.
– .695 (17.65) I.D.
– .885 (22.48) I.D.
– 1.070 (27.18) I.D.
– 1.135 (28.83) I.D.
– .820 (20.8) I.D.
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
www.glenair.com
REV 13-MARCH-2013
G-32
E-Mail: sales@glenair.com
809-083 and 809-087
Attaching a 809-087 Receptacle Cover to a
Rear Panel Mounted Jam Nut Receptacle
ATTACHMENT RING
FITS UNDER JAM NUT
PROTECTIVE
COVER
809-087
PANEL
RECEPTACLE
CONNECTOR
STYLE 07
Attaching a 809-087 Receptacle Cover to a
Front Panel Mounted Jam Nut Receptacle
ATTACHMENT RING
FITS UNDER FLANGE
PROTECTIVE
COVER
809-087
PANEL
RECEPTACLE
CONNECTOR
STYLE 00
JAM
NUT
JAM
NUT
Solid
Ring
Dia.
Code
08
16
18
10
25
12
20
21
Shell
Size
5
6
7, 8
9
10
12
14
15
Conn.
thread
Ref
.5000-32
.5625-28
.6875-28
.7500-28
.8125-28
1.000-28
1.062-20
1.125-28
Ring I.D.
In.
.510
.570
.695
.766
.820
1.015
1.070
1.135
Ring o.D.
In.
.620
.690
.820
.890
.940
1.200
1.200
1.250
mm.
13.0
14.5
17.7
19.4
20.8
25.8
27.2
28.8
mm.
15.7
17.5
20.8
22.6
23.9
30.5
30.5
31.8
Solid
Ring
Attaching a 809-087 Receptacle Cover to a
Panel With a Lug terminal
LUG
TERMINAL
Dia.
Code
15
08
17
18
10
19
12
Shell
Size
5
6
7, 8
9
10
12
14
Ring I.D.
Ring o.D.
Conn.
In.
mm.
In.
mm.
thread
± .010 ±0.25 ± .015 ± 0.38
Ref
.4375-32
.5000-32
.6250-28
.6875-28
.7500-28
.8750-28
1.000-28
.445
.510
.635
.695
.766
.885
1.015
11.3
13.0
16.1
17.7
19.4
22.5
25.8
.570
.620
.760
.820
.890
1.010
1.200
14.5
15.7
19.3
20.8
22.6
25.7
30.5
Attaching a Cover to a Cable Assembly With a
Solid Ring
INSTALL RING BEFORE
MOLDING OR BACKSHELL
INSTALLATION
G
SCREW
CONNECTOR
PROTECTIVE
COVER
809-087
Dia. Shell
Code Size
#4, M3
01
Lug Terminal for
#6
02
Attaching Receptacle
#8, M4
05
Covers to a Panel
with a Screw
#10
06
© 2010 Glenair, Inc.
www.glenair.com
Ring I.D.
In.
mm.
±.005
.126
.145
.188
.197
±0.13
3.20
3.68
4.78
5.00
Ring o.D.
In.
mm.
Max.
.31
.31
.31
.31
Max.
7.9
7.9
7.9
7.9
Solid Ring
Dia.
Code
07
15
16
18
20
Shell
Size
± .010
5,6
7
8, 9
10, 12
14
Ring I.D.
In.
mm.
9.78
11.30
14.48
Ring o.D.
In.
mm.
.510
.565
.685
12.95
14.35
17.40
20.82
30.35
±0.25 ± .015 ± 0.38
.385
.445
.570
.695
1.070
17.65
.820
27.17 1.195
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
SMALL
RING
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
G-33
SCREW
REV 13-MARCH-2013
CONNECTOR
Series 804
Series 804 Push-Pull Mighty Mouse
Rubber Covers
Series 804 Push-Pull Mighty Mouse
Rubber Covers
809-083 and 809-087
A
B
C
E
F
G
G
J
K
L
Shell
Size
5
6
7
8
9
10
12
14
ØA
In
mm
.23
.29
.36
.41
.46
.54
.55
.78
5.8
7.4
9.1
10.4
11.7
13.7
14.0
19.8
SOLID RING
M
Series 804
FRICTION SLEEVE
Attaching a Cover to a Cable Assembly With
type SK Slip Knot
Attaching a Cover to a Cable Assembly With
type WS Cable tie
BLACK NYLON CABLE TIE
WITH SST LOCKING TAB
SST SCREW WITH
SELF-LOCKING NUT
809-083
PLUG COVER
.94 (23.9)
.56 (14.2)
LUG TERMINAL
NO LUG, FUSED END (00)
ø.50
REF
LENGTH MEASURED
AT.50 DIAMETER
øA
øB
809-087
RECEPTACLE COVER
.69 (17.5)
SLIP KNOT (SK)
CABLE TIE (WS)
øC
øD
LENGTH
(SEE ORDERING INFORMATION)
.30 (7.6)
ØB
In
mm
.56
.56
.56
.68
.68
.79
.79
1.11
14.2
14.2
14.2
17.3
17.3
20.1
20.1
28.2
ØC
In
mm
.27
.33
.40
.44
.50
.57
.69
.82
6.9
8.4
10.2
11.2
12.7
14.5
17.5
20.8
ØD
In
mm
.59
.65
.78
.78
.84
.90
1.03
1.15
15.0
16.5
19.8
19.8
21.3
22.9
26.2
29.2
MAtERIALS
Cover
Lanyard
Cable Tie
Ring
Neoprene rubber blend,
black
.062" (1.57) diameter nylon
cord, black
6/6 nylon, black, SST
locking tab
Stainless steel, black zinc-
cobalt finish
© 2010 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
www.glenair.com
REV 13-MARCH-2013
G-34
E-Mail: sales@glenair.com
