FZ3600R17KE3_B2 datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> The transistor> FZ3600R17KE3_B2

FZ3600R17KE3_B2: DescriptionIGBT-modules; CategoryDiscrete semiconductor The transistor; File Size261KB，8 Pages; ManufacturerEUPEC [eupec GmbH]

Download Datasheet Parametric View All

FZ3600R17KE3_B2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	FZ3600R17KE3_B2	-	-	View	Buy Now

FZ3600R17KE3_B2 Overview

IGBT-modules

FZ3600R17KE3_B2 Parametric

Parameter Name	Attribute value
Maker	EUPEC [eupec GmbH]
package instruction	FLANGE MOUNT, R-XUFM-X9
Reach Compliance Code	unknow
Shell connection	ISOLATED
Maximum collector current (IC)	4800 A
Collector-emitter maximum voltage	1700 V
Configuration	PARALLEL, 3 ELEMENTS WITH BUILT-IN DIODE
JESD-30 code	R-XUFM-X9
Number of components	3
Number of terminals	9
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Polarity/channel type	N-CHANNEL
Certification status	Not Qualified
surface mount	NO
Terminal form	UNSPECIFIED
Terminal location	UPPER
Transistor component materials	SILICON
Nominal off time (toff)	2100 ns
Nominal on time (ton)	1050 ns

Preview

Download Datasheet

View All

Technische Information / technical information

IGBT-Module

IGBT-modules

FZ3600R17KE3_B2

Vorläufige Daten / preliminary data
