LPC12065LTED1R0 datasheet, PDF

Datasheet> All Categories > Passive components> inductor> LPC12065LTED1R0

LPC12065LTED1R0: DescriptionGeneral Purpose Inductor, 1uH, 20%, 1 Element, Ferrite-Core, SMD,; CategoryPassive components inductor; File Size70KB，4 Pages; ManufacturerKOA Speer; Websitehttp://www.koaspeer.com/

Download Datasheet Parametric View All

LPC12065LTED1R0 Overview

General Purpose Inductor, 1uH, 20%, 1 Element, Ferrite-Core, SMD,

LPC12065LTED1R0 Parametric

Parameter Name	Attribute value
Maker	KOA Speer
Reach Compliance Code	compliant
ECCN code	EAR99
core material	FERRITE
DC Resistance	0.007 Ω
Nominal inductance(L)	1 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e0
Number of functions	1
Number of terminals	2
Maximum operating temperature	80 °C
Minimum operating temperature	-30 °C
Minimum quality factor (at nominal inductance)	20
Maximum rated current	8.5 A
self resonant frequency	60 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	TIN LEAD
Terminal location	DUAL ENDED
Terminal shape	NO LEAD
Test frequency	1 MHz
Tolerance	20%

Preview

Download Datasheet

View All

KOA SPEER ELECTRONICS, INC.

SS-198 R3

AHA 11/26/02

Surface Mount

Power Chip Inductors

Type LPC12065

1. Scope

This specification applies to LPC12065 power chip inductors produced by KOA Corporation.

2. Type Designation

The type designation shall be the following form:

Old Type

CERTIFIED

LPC

Type

4045

Size

TED

Packaging

101

Nominal

Inductance

Tolerance

New Type

LPC

Type

4045

Size

Termination

Material

L: SnPb

A: SnAg

TED

Packaging

TED: 10" Embossed Plastic

1,500 pcs/reel

101

Nominal

Inductance

101: 100µH

221: 220µH

Tolerance

K: ±10%

M: ±20%

N: ±30%

12065

3. Rating

No.

Item

Nominal inductance range

Nominal inductance tolerance

Q (Quality factor)

Self-resonant frequency (MHz)

DC resistance (ohm)

Allowable current (mA)

Measurement frequency (MHz)

Storage temperature range

Operating temperature range

Specification

0.68

µH

~ 6.8 mH (E-6 series)

The rating shall be shown in the Table-1

-40°C ~ +85°C

-30°C ~ +80°C

PAGE 1 OF 4

Bolivar Drive

P.O. Box 547

Bradford, PA 16701

USA

814-362-5536

Fax 814-362-8883

www.koaspeer.com
