Preview

CW030C1-M: DescriptionAnalog Circuit, Hybrid, MDIP38; CategoryAnalog mixed-signal IC The signal circuit; File Size1MB，16 Pages; ManufacturerLSC/CSI; Websitehttps://lsicsi.com

Download Datasheet Parametric Compare View All

CW030C1-M Overview

Analog Circuit, Hybrid, MDIP38

CW030C1-M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	LSC/CSI
package instruction	DIP, DIP38,2.5
Reach Compliance Code	unknown
Maximum input voltage	75 V
Minimum input voltage	36 V
JESD-30 code	R-MDIP-T38
JESD-609 code	e0
Number of terminals	38
Maximum output current	2 A
Nominal output voltage	15 V
Package body material	METAL
encapsulated code	DIP
Encapsulate equivalent code	DIP38,2.5
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL

Preview

Download Datasheet

View All

CW030C1-M Related Products

	CW030C1-M	CW030B87-M	CW030B871-M	CW030B8-M	CW030B1-M	CW030B71-M	CW030B81-M	CW030C8-M	CW030C871-M
Description	Analog Circuit, Hybrid, MDIP38	Analog Circuit, Hybrid, MDIP38	Analog Circuit, Hybrid, MDIP38	Analog Circuit, Hybrid, MDIP38	Analog Circuit, Hybrid, MDIP38	Analog Circuit, Hybrid, MDIP38	Analog Circuit, Hybrid, MDIP38	Analog Circuit, Hybrid, MDIP38	Analog Circuit, Hybrid, MDIP38
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
Maker	LSC/CSI	LSC/CSI	LSC/CSI	LSC/CSI	LSC/CSI	LSC/CSI	LSC/CSI	LSC/CSI	LSC/CSI
package instruction	DIP, DIP38,2.5	DIP, DIP38,2.5	DIP, DIP38,2.5	DIP, DIP38,2.5	DIP, DIP38,2.5	DIP, DIP38,2.5	DIP, DIP38,2.5	DIP, DIP38,2.5	DIP, DIP38,2.5
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Maximum input voltage	75 V	75 V	75 V	75 V	75 V	75 V	75 V	75 V	75 V
Minimum input voltage	36 V	36 V	36 V	36 V	36 V	36 V	36 V	36 V	36 V
JESD-30 code	R-MDIP-T38	R-MDIP-T38	R-MDIP-T38	R-MDIP-T38	R-MDIP-T38	R-MDIP-T38	R-MDIP-T38	R-MDIP-T38	R-MDIP-T38
JESD-609 code	e0	e0	e0	e0	e0	e0	e0	e0	e0
Number of terminals	38	38	38	38	38	38	38	38	38
Maximum output current	2 A	2.5 A	2.5 A	2.5 A	2.5 A	2.5 A	2.5 A	2 A	2 A
Nominal output voltage	15 V	12 V	12 V	12 V	12 V	12 V	12 V	15 V	15 V
Package body material	METAL	METAL	METAL	METAL	METAL	METAL	METAL	METAL	METAL
encapsulated code	DIP	DIP	DIP	DIP	DIP	DIP	DIP	DIP	DIP
Encapsulate equivalent code	DIP38,2.5	DIP38,2.5	DIP38,2.5	DIP38,2.5	DIP38,2.5	DIP38,2.5	DIP38,2.5	DIP38,2.5	DIP38,2.5
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	NO	NO	NO	NO	NO	NO	NO
technology	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Base Number Matches	-	1	1	1	1	1	1	-	-
