Lift |
Spacing 3.81 mm
AKZ1550/..F-3.81-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.14 mm²
1.5 mm²
0.14 mm²
1.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
-
-
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
17.22
21.03
24.84
28.65
32.46
36.27
40.08
43.89
47.70
51.51
55.32
59.13
62.94
66.75
70.56
74.37
78.18
81.99
85.80
Article Designation
AKZ1550/2F-3.81-GREEN
AKZ1550/3F-3.81-GREEN
AKZ1550/4F-3.81-GREEN
AKZ1550/5F-3.81-GREEN
AKZ1550/6F-3.81-GREEN
AKZ1550/7F-3.81-GREEN
AKZ1550/8F-3.81-GREEN
AKZ1550/9F-3.81-GREEN
AKZ1550/10F-3.81-GREEN
AKZ1550/11F-3.81-GREEN
AKZ1550/12F-3.81-GREEN
AKZ1550/13F-3.81-GREEN
AKZ1550/14F-3.81-GREEN
AKZ1550/15F-3.81-GREEN
AKZ1550/16F-3.81-GREEN
AKZ1550/17F-3.81-GREEN
AKZ1550/18F-3.81-GREEN
AKZ1550/19F-3.81-GREEN
AKZ1550/20F-3.81-GREEN
Article Number
51550022025F
51550032025F
51550042025F
51550052025F
51550062025E
51550072025D
51550082025D
51550092025D
51550102025D
51550112025D
51550122025D
51550132025D
51550142025D
51550152025D
51550162025D
51550172025D
51550182025D
51550192025D
51550202025D
PU
200
200
200
200
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.25 mm²
min
Stranded with Ferrule 1.0 mm²
max
Dimensions
Stripped Length
Materials
Clamp
Screw
Screw, Flange
Contact Spring
Brass
Bronze
Steel
Bronze
7.0 mm
Colours
GREEN
BLACK
LIGHT GREEN
RAL6018
RAL9011
similar RAL 6018
RAL6018
RAL9011
Accessories
Figure
Designation
Bridge, 2-pole, BR/2-5.0/5.08-L7.5
Article Number
50000000015
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Counterparts (Spacing 3.81 mm)
Pin Strip/Terminal Blocks
STLZ1550
STLZ1570
Bridge, 3-pole, BR/3-3.5/3.81-L7.5
50000000016
Bridge, 2-pole, insulated, BRI/2-7.0/7.62-
L7.5-LIGHT GREY
50000000018
Ratings
Usegroup
Rated Voltage
Rated Current
Overvoltage Category
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
Pollution Degree
B
300 V
8A
C
-
-
D
300 V
8A
min
0.5 mm² (6 A)
0.5 mm² (6 A)
160 V
9A
III
max
1.5 mm² (9 A)
1.5 mm² (9 A)
0.25 Nm
M2
2.5 kV
3
AWG 28-16
AWG 28-16
0.25 Nm
M2
1.6 kV
-
-
-
-
-
AWG 28-16
AWG 28-16
0.25 Nm
M2
1.6 kV
