PIC16F1825-I/SO datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> PIC16F1825-I/SO

PIC16F1825-I/SO: Description8-BIT, FLASH, 32 MHz, RISC MICROCONTROLLER, PQCC16; CategoryThe embedded processor and controller Microcontrollers and processors; File Size131KB，2 Pages; ManufacturerMicrochip; Websitehttps://www.microchip.com

Download Datasheet Parametric View All

PIC16F1825-I/SO Overview

8-BIT, FLASH, 32 MHz, RISC MICROCONTROLLER, PQCC16

PIC16F1825-I/SO Parametric

Parameter Name	Attribute value
Maker	Microchip
Parts packaging code	SOIC
package instruction	7.50 MM, PLASTIC, SOIC-20
Contacts	20
Reach Compliance Code	compli
ECCN code	3A991.A.2
Samacsys Descripti	20-Pin Flash Microcontrollers with XLP Technology, SOIC-20
Has ADC	YES
Other features	ALSO OPERATES 1.8V MINIMUM SUPPLY AT 16 MHZ
Address bus width
bit size	8
maximum clock frequency	32 MHz
DAC channel	YES
DMA channel	NO
External data bus width
JESD-30 code	R-PDSO-G20
JESD-609 code	e3
length	12.8 mm
Number of I/O lines	18
Number of terminals	20
On-chip program ROM width	14
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
RAM (bytes)	1024
rom(word)	8192
ROM programmability	FLASH
Maximum seat height	2.65 mm
speed	32 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	2.5 V
Nominal supply voltage	3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	7.5 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC

Preview

Download Datasheet

View All

PIC12F/PIC16F182X Microcontrollers

High Feature, Low Pin Count 8-bit MCUs

Overview

The PIC1XF182X family represents Microchip’s latest

generation 8-bit product offering in 8, 14, 18 and 20 pins,

and provides increased functionality along with many other

enhancements. These products are pin compatible with all

previous generations of low pin count PIC microcontrollers,

allowing users to upgrade to new features and functionality

while retaining a compatible footprint to their existing

application.

The 10 members of the PIC1XF182X family offer up to

14 KB of Flash memory, up to 1 KB of RAM, 256 bytes of

on-board EEPROM, and a number of integrated peripherals

that save engineers both time and cost. Among those are

SPI/I

C™ and EUSART modules available from 8 to 20 pins,

built-in Capacitive Sensing capability, and a proprietary Data

Signal Modulator that supports the creation of Amplitude

Shift Keying (ASK) and Phase Shift Keying (PSK) patterns

with no code overhead.

These new devices combine world class levels of integration

with industry leading current consumption. nanoWatt XLP

technology and other power saving enhancements allow

the PIC1XF182X family to achieve Sleep currents as low

as 20 nA, and Run mode current consumption of less than

50 μA/MHz.

The

“Green”

Microcontroller

years

Whether your application requires

of coin- cell powered operation in

“standby” mode, or simply needs to

execute code with as little current

consumption as possible, the

ﬁt

PIC1XF182X family is designed to

within your power budget.

20 nA in Sleep



Consumes as little as XLP technology

Mode

(1)

with nanoWatt

Current



World’s Lowest Active Hz)

Consumption (<50

μA

(1)

w Power



<500 nA Integrated Lo dic wakeup

Watchdog Timer for perio

onality at less



Real Time Clock functi

than 800 nA

(1)

ation, visit:



For more detailed inform

www.microchip.com/xlp

Note 1: Typical measure

ments taken at V

= 1.8

Key Features

The PIC1XF182X family is designed with a host of features

that enable maximum integration with the smallest possible

footprint.

■

Enhanced Mid-Range Architecture –

At the heart of the

PIC1XF182X family is the 32 MHz Enhanced Mid-Range

core architecture. This new engine offers enhancements

that allow for faster, C-friendly, and more efﬁcient code

execution – including hardware context save during

interrupts.

■

Communications –

SPI/I

C, EUSART and the Data Signal

Modulator are standard on all PIC1XF182X devices. The

PIC16F1827, PIC16F1829 and PIC16F1847 all feature

dual SPI/I

C interfaces for added communication

capability.

■

Human Interface –

mTouch™ Capacitive Sensing

technology can be implemented using a variety of

methods, including the integrated Capacitive Sensing

Module and the Analog-to-Digital converter.

■

Analog Interface –

All devices in the PIC1XF182X family

feature 10-bit Analog-to-Digital converters and Rail-to-Rail

comparators with Set/Reset latch.

■

Motor and Lighting Control –

Multiple independent

PWMs with up to 4 available time bases are available to

support a wide array of motor control and lighting types,

such as LED and ﬂuorescent lighting.

Microchip Technology Incorporated
