SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 1
AXIAL INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
AA0307□□□□L□
Ⅰ﹒
CONFIGURATION & DIMENSIONS
：
A
B
C
W
: 3.0 max.
: 7.5 max.
: 61.0 ref.
: 0.50
m/m
m/m
m/m
m/m
B
C
※
Color code
：
1st Color
：
First Significant Figure
2nd Color
：
Second Significant Figure
3rd Color
：
Multiplier
4th Color
：
Tolerance
Ⅱ﹒
SCHEMATIC DIAGRAM
：
A
W∮
b
a
Ⅲ﹒
MATERIALS
：
a
﹒
Core
：
Ferrite DR core
b
﹒
Wire
：
Enamelled copper wire ( class B )
c
﹒
Terminal
：
Cu/Ni/Sn (lead content 100ppm max.)
d
﹒
Coating
：
Epoxy resin
d
c
e
﹒
Remark
：
Ferrite body is exempted with lead content under RoHS regulation
Ⅳ﹒
GENERAL SPECIFICATION
：
a
﹒
Temp. rise
：
20
℃
max.
b
﹒
Ambient temp
：
60
℃
max.
c
﹒
Operating temp
：
-20
℃
---- 80
℃
d
﹒
Terminal tensile strength
：
1.0 KG min
e
﹒
Terminal bending strength
：
0.3 KG min
f
﹒
Dielectric withstanding voltage
：
250 Vrms
g
﹒
Rated cuttent
：
Base on temp. rise
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 2
AXIAL INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
AA0307□
□ □ □
L□
Ⅴ﹒
ELECTRICAL CHARACTERISTICS
：
DWG No.
AA0307R10ML□
AA0307R12ML□
AA0307R15ML□
AA0307R18ML□
AA0307R22ML□
AA0307R27ML□
AA0307R33ML□
AA0307R39ML□
AA0307R47ML□
AA0307R56ML□
AA0307R68ML□
AA0307R82ML□
AA03071R0KL□
AA03071R2KL□
AA03071R5KL□
AA03071R8KL□
AA03072R2KL□
AA03072R7KL□
AA03073R3KL□
AA03073R9KL□
AA03074R7KL□
AA03075R6KL□
AA03076R8KL□
AA03078R2KL□
AA0307100KL□
AA0307120KL□
AA0307150KL□
AA0307180KL□
AA0307220KL□
AA0307270KL□
AA0307330KL□
AA0307390KL□
AA0307470KL□
AA0307560KL□
AA0307680KL□
AA0307820KL□
AA0307101KL□
AA0307121KL□
AA0307151KL□
AA0307181KL□
AA0307221KL□
AA0307271KL□
AA0307331KL□
AA0307391KL□
AA0307471KL□
AA0307561KL□
AA0307681KL□
AA0307821KL□
AA0307102KL□
Q
Inductance
( µ H ) Tol.
min.
0.10 ± 20% 45
0.12 ± 20% 45
0.15 ± 20% 45
0.18 ± 20% 45
0.22 ± 20% 45
0.27 ± 20% 45
0.33 ± 20% 45
0.39 ± 20% 45
0.47 ± 20% 45
0.56 ± 20% 45
0.68 ± 20% 45
0.82 ± 20% 45
1.00 ± 10% 45
1.20 ± 10% 45
1.50 ± 10% 45
1.80 ± 10% 45
2.20 ± 10% 45
2.70 ± 10% 45
3.30 ± 10% 45
3.90 ± 10% 45
4.70 ± 10% 45
5.60 ± 10% 45
6.80 ± 10% 45
8.20 ± 10% 45
10.00 ± 10% 45
12.00 ± 10% 45
15.00 ± 10% 45
18.00 ± 10% 45
22.00 ± 10% 45
27.00 ± 10% 45
33.00 ± 10% 45
39.00 ± 10% 45
47.00 ± 10% 50
56.00 ± 10% 50
68.00 ± 10% 50
82.00 ± 10% 50
100.00 ± 10% 50
120.00 ± 10% 50
150.00 ± 10% 50
180.00 ± 10% 50
220.00 ± 10% 50
270.00 ± 10% 50
330.00 ± 10% 50
390.00 ± 10% 50
470.00 ± 10% 50
560.00 ± 10% 50
680.00 ± 10% 50
820.00 ± 10% 50
1000.00 ± 10% 50
Test
Freq.
( MHz )
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
SRF
( MHz )
min.
480.0
450.0
420.0
400.0
380.0
360.0
320.0
310.0
300.0
280.0
240.0
200.0
180.0
160.0
140.0
120.0
110.0
85.0
74.0
62.0
48.0
35.0
28.0
20.0
18.0
16.0
14.0
12.0
10.0
9.0
8.0
7.5
7.0
6.5
6.0
5.5
5.0
4.8
4.5
4.0
3.5
3.0
2.8
2.6
2.4
2.0
1.8
1.6
1.4
RDC
(
Ω
)
max.
0.06
0.06
0.07
0.07
0.08
0.09
0.10
0.12
0.15
0.18
0.20
0.22
0.25
0.28
0.30
0.35
0.40
0.45
0.50
0.55
0.60
0.65
0.70
0.80
0.85
0.90
1.00
1.20
1.35
1.80
2.10
2.30
2.60
2.90
3.20
3.80
4.20
4.50
5.00
6.00
7.00
7.50
8.00
10.00
13.00
15.00
16.00
23.00
26.00
IDC
( mA )
max.
1400
1350
1270
1200
1150
1100
1100
1000
1000
950
900
900
815
740
700
655
630
595
575
555
530
500
470
425
370
350
335
315
285
270
255
240
205
195
185
175
165
160
150
140
130
120
100
95
90
85
75
65
60
1st
BN
BN
BN
BN
R
R
O
O
Y
GN
BU
GY
BN
BN
BN
BN
R
R
O
O
Y
GN
BU
GY
BN
BN
BN
BN
R
R
O
O
Y
GN
BU
GY
BN
BN
BN
BN
R
R
O
O
Y
GN
BU
GY
BN
Color Code
2nd 3rd
BK SIL
SIL
R
GN SIL
GY SIL
SIL
R
SIL
V
SIL
O
SIL
W
SIL
V
BU SIL
GY SIL
SIL
R
BK GD
GD
R
GN GD
GY GD
GD
R
GD
V
GD
O
GD
W
GD
V
BU GD
GY GD
GD
R
BK BK
BK
R
GN BK
GY BK
BK
R
BK
V
BK
O
BK
W
BK
V
BU BK
GY BK
BK
R
BK BN
BN
R
GN BN
GY BN
BN
R
BN
V
BN
O
BN
W
BN
V
BU BN
GY BN
R
BN
BK
R
4th
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
SIL
1).□
：
Package Information--- A
：
Bulk
B
：
Taping / Box
C : Taping / Reel
2) Test Equipment
：
HP4342A Q meter or equivalent
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 3
AXIAL INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
AA0307□
□ □ □
L□
Ⅵ﹒
PACKAGING INFORMATION FOR ALA HORIZONTAL TAPING IN BOX
(1) Configation
C
A
C
E
H
F
G
B
Y
D
Z
X
( 2 ) Dimensions
Style
Item
A
Specification
26.00± 1.50
13.00± 0.50
50.00± 1.50
2.50 ( max )
52.00± 1.50
26.00± 1.50
76.00± 1.50
F
G
H
Item
B
C
E
Unit:m/m
Specification
5.00± 0.50
6.00± 1.00
0.50 ( max )
T 26
D
X
H
A
1.00 ( max )
1.00 ( max )
2.50 ( max )
T 52
D
X
( 3 ) Q'TY & G.W. Per package
Inner : Box
Series
AA0307
Q'TY (pcs)
G.W. (gw)
Size ( m/m )
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
Size (cm)
3,000
900
250 x 75 x 100
36,000
12.5
37.6 x 26.6 x 34.5
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 4
AXIAL INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
AA0307□
□ □ □
L□
Ⅶ﹒
PACKAGING INFORMATION FOR ALA HORIZONTAL TAPING IN REEL
( 1 ) Configuration
Label
T
R
K
C
A
C
E
H
F
G
D
( 2 ) Dimensions
Item
A
B
C
D
E
H
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
AA0307
AE-001A
Q'TY (pcs)
G.W. (gw)
Size ( m/m )
Q'TY (pcs)
Unit:m/m
Specification
52.00± 1.50
5.00± 0.50
6.00± 1.00
26.00± 1.50
0.50 ( max. )
2.50 ( max. )
Item
F
G
K
R
T
Specification
1.00 ( max. )
1.00 ( max. )
355.00± 0.50
15.00± 0.50
71.00± 3.00
Outer : Carton
G.W. (Kg)
Size (cm)
5,000
1,600
370 x 370 x 85
20,000
8.0
37.9 x 37.9 x 37.3
B
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 5
AXIAL INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
AA0307□
□ □ □
L□
Ⅷ﹒
PACKAGING INFORMATION FOR BDC VERTICAL TAPING IN BOX
( PACKAGING CODE
：
K )
(1) Configuration
P
H
W1
Wo
W2
Do
F
Po
( 2 ) Dimension
Item
P
Po
F
Do
H
Specification
12.70 ± 1.00
12.70 ± 0.30
5.00 +1.0
-0.5
4.00± 0.20
16.00± 0.50
Item
W
Wo
W1
W2
Specification
18.00 +1.0
-0.5
13.0± 0.30
W
Unit:m/m
9.00± 0.50
1.00
ref.
AE-001A
