Customer Drawing
100G0111
Issue 9
14th November 2012
Page 1 of 2
Page 2 is for internal use only
WIRE, HALOGEN FREE, THIN WALL,
750/1300 VOLT AC, 125°C
The complete requirements for procuring the wire described herein shall consist of this document.
Conductor -
Tin Plated Copper
Insulation -
Halogen Free
Polymer
C6
Part
Description
C7
Nominal Nominal
Cross Conductor Equivalent
Sectional Stranding
AWG
Area
No./Diam.
Size
(mm²)
(mm)
0.15
0.25
0.40
0.50
0.60
0.75
1.00
1.20
1.50
2.00
2.50
3.00
4.00
19/0.10
19/0.13
19/0.16
19/0.18
19/0.20
19/0.23
19/0.25
19/0.29
37/0.23
37/0.25
37/0.29
37/0.32
56/0.30
26
24
22
-
20
-
18
16
15
14
13
12
-
C8
C9
C11
C16
C17
C18
C20
Maximum
Weight
(kg/km)
Conductor
Diameter
(mm)
#
#
#
#
#
#
#
100G0111-0.15-*
100G0111-0.25-*
100G0111-0.40-*
100G0111-0.50-*
100G0111-0.60-*
100G0111-0.75-*
100G0111-1.00-*
100G0111-1.20-*
100G0111-1.50-*
100G0111-2.00-*
100G0111-2.50-*
100G0111-3.00-*
100G0111-4.00-*
Min.
0.45
0.55
0.73
0.82
0.95
1.04
1.17
1.32
1.46
1.68
1.85
2.12
2.41
FINISHED WIRE
Minimum Maximum
Diameter
Insulation Resistance
(mm)
Thickness
@ 20°C
Lower
Upper
(mm)
(ohms/km)
Spec
Target
Spec
Max.
Limit
Limit
0.50
0.20
132.9
0.98
1.03
1.08
0.63
0.20
84.32
1.09
1.14
1.19
0.79
0.20
50.50
1.28
1.33
1.38
0.90
0.20
40.10
1.37
1.40
1.45
1.01
0.20
31.10
1.47
1.52
1.57
1.15
0.20
26.70
1.59
1.60
1.65
1.26
0.20
20.00
1.69
1.75
1.80
1.42
0.20
15.80
1.88
1.93
1.98
1.58
0.20
13.70
2.03
2.08
2.13
1.82
0.20
10.50
2.31
2.36
2.41
2.01
0.25
8.21
2.50
2.55
2.63
2.24
0.25
6.58
2.70
2.78
2.86
2.57
0.25
4.89
3.01
3.09
3.17
2.59
3.59
5.18
6.60
7.40
8.90
10.70
13.60
16.00
20.30
25.70
31.00
43.60
COLOUR CODE:
The '*' in the part number shall be replaced by a standard colour code designator
in accordance with Mil Std 681.
eg: 100G0111-1.00-2 Red insulation
PERFORMANCE
REQUIREMENTS:
All sizes shall be tested and meet the requirements of the issue in effect of
WSD 912
Sizes Indicated with # shall also meet the requirements of the issue in effect of
ENG-SYS-825-904
This product will be available in the full colour range and may be marked or unmarked in accordance with the order.
