14611163 Product Details
Industrial Relays (General Purpose)
Converted to EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
OJT Series
Contact Current Class = 2A to 5A Class, Less Than
16A
Contact Rated Current = 5 A
Terminal Type = PCBTHT
Contact Arrangement = 1 Form A (NO)
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
14611163
TE Internal Number: 14611163
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
OJTSSDM 000 CUSTOMER DWG (PDF, English)
Catalog Pages/Data Sheets:
OJT Series Relay Datasheet (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Contact Current Class = 2A to 5A Class, Less Than 16A
Contact Rated Current (A) = 5
Contact Limiting Continuous Current (A) = 5
Contact Limiting Making Current (A) = 5
Contact Limiting Breaking Current (A) = 5
Insulation Initial Dielectric Between Coil/Contact Class = 3500V to
4000V Class
Insulation Initial Dielectric Between Open Contacts (V rms) = 750
Insulation Initial Dielectric Between Contacts and Coil (V rms) =
4000
Contact Rated Voltage (VAC) = 250
Contact Switching Voltage Max. (VAC) = 250
Contact Limiting ShortTime Current (A) = 5
Contact Switching Recommended Load, Min. = 100mA at 5V
Coil Rated Voltage (VDC) = 5
Coil Resistance (Ω) = 56
Coil Rated Power, DC (mW) = 450
Coil Rated Power Class = 400mW to 500mW Class
Insulation Creepage Class = 5.5mm to 8mm Class
Insulation Clearance Class = 2.5mm to 4mm Class
Dimensions:
Mechanical Length Class = 16mm to 20mm Class
Length (mm [in]) = 18.20 [0.717]
Mechanical Width Class = 10mm to 12mm Class
Width (mm [in]) = 10.20 [0.400]
Mechanical Height Class = 14mm to 15mm Class
Height (mm [in]) = 14.70 [0.579]
Insulation Clearance Between Contact and Coil (mm [in]) = 3.2
[0.126]
Body Features:
Mount Type = PCB
Weight (g [oz]) = 10.00 [0.353]
Contact Features:
Terminal Type = PCBTHT
Contact Material = AgSnO
Contact Number of Poles = 1
Configuration Features:
Contact Arrangement = 1 Form A (NO)
Coil Magnetic System = Monostable, DC
Coil Special Features = UL Coil Insulation Class B
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 260°C, Wave
solder capable to 240°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Converted to comply with RoHS
directive
Approved/Registered Standards = CQC, TUEV, cULus, VDE
Environmental:
Environmental Category of Protection = RTII
Environmental Ambient Temperature, Max. (°C [°F]) = 85 [185]
Environmental Ambient Temperature Class = 70°C to 85°C Class
Packaging Features:
Packaging Method = Tray
Other:
Series = OJT
