5-1532124-8

Description
D MICROMINIATURE CONNECTOR
CategoryThe connector    The connector
File Size135KB,2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric Compare View All

5-1532124-8 Overview

D MICROMINIATURE CONNECTOR

5-1532124-8 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codeunknown
Connector typeD MICROMINIATURE CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact materialNOT SPECIFIED
Manufacturer's serial number1532124
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Pin & Socket Connectors > Product Feature Selector > Product Details
M83513/10­D02NN Product Details
Microminiature D Connectors
Not EU RoHS or ELV Compliant
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
Connector
Connector Design = PCB Connector
Connector Style = Plug
Contact Type = Pin
Product Series = MCK (Full Metal)
M83513/10­D02NN
(5­1532124­8)
TE Internal Number: 5­1532124­8
View all Features
 Pending Obsolescence
Contact Product Information Center
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Connector
Connector Design = PCB Connector
Product Series = MCK (Full Metal)
PCB Mounting Orientation = Right Angle
Mechanical Attachment:
Mounting Hardware = None
Termination Features:
Termination Post Length (mm [in]) = 3.56 [0.140]
Body Features:
Shell Plating = Nickel, Electroless
Contact Features:
Contact Type = Pin
Contact Style = Printed Circuit Board
Housing Features:
Connector Style = Plug
Housing Material = Polyphenylene Sulfide (PPS)
Configuration Features:
Number of Positions = 25
Industry Standards:
Government/Industry Qualification = Yes
Government/Industry Part Number = M83513/10­D02NN
RoHS/ELV Compliance = Not ELV/RoHS compliant
Lead Free Solder Processes = Not reviewed for lead free solder
process
Other:
Brand = Microdot
Comment = Also available in commercial grade.
Corporate Information
About TE
Investors
News Room
Supplier Portal
Careers
Terms & Conditions
Privacy Policy
AODA Accessibility Policy
Quick Links
Distributor Inventory
Product Cross Reference
Documents & Drawings
Product Compliance Support Center
Site Map
Customer Support
Email or Chat With Us
Find a Phone Number
Knowledge Base
Manage Your Account
Keep Me Informed


5-1532124-8 Related Products

5-1532124-8 M83513/10-D02NN
Description D MICROMINIATURE CONNECTOR D MICROMINIATURE CONNECTOR
Is it Rohs certified? incompatible incompatible
Reach Compliance Code unknown unknown
Connector type D MICROMINIATURE CONNECTOR D MICROMINIATURE CONNECTOR
Contact to complete cooperation NOT SPECIFIED NOT SPECIFIED
Contact material NOT SPECIFIED NOT SPECIFIED
