RC1/247010% datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> RC1/247010%

RC1/247010%: DescriptionRESISTOR, CARBON COMPOSITION, 0.5W, 10%, 267ppm, 470ohm, THROUGH HOLE MOUNT, AXIAL LEADED; CategoryPassive components The resistor; File Size67KB，2 Pages; ManufacturerSEI(Stackpole Electronics Inc.); Websitehttps://www.seielect.com/; Environmental Compliance; Related ProductsFound5parts with similar functions to RC1/247010%

Download Datasheet Parametric View All

RC1/247010% Overview

RESISTOR, CARBON COMPOSITION, 0.5W, 10%, 267ppm, 470ohm, THROUGH HOLE MOUNT, AXIAL LEADED

RC1/247010% Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	Axial,
Reach Compliance Code	compli
ECCN code	EAR99
Other features	NON-INDUCTIVE
structure	Non-Inductive
JESD-609 code	e3
Lead diameter	0.7 mm
Lead length	26 mm
Manufacturer's serial number	RC
Installation features	THROUGH HOLE MOUNT
Number of terminals	2
Maximum operating temperature	130 °C
Minimum operating temperature	-55 °C
Package diameter	3.6 mm
Package length	9.5 mm
Package shape	TUBULAR PACKAGE
Package form	Axial
method of packing	BULK
Rated power dissipation(P)	0.5 W
Rated temperature	70 °C
resistance	470 Ω
Resistor type	FIXED RESISTOR
series	RC1/2
surface mount	NO
technology	CARBON COMPOSITION
Temperature Coefficient	267 ppm/°C
Terminal surface	Matte Tin (Sn)
Terminal shape	WIRE
Tolerance	10%
Operating Voltage	350 V
Base Number Matches	1

Preview

Download Datasheet

View All

Page 34

Carbon Composition Resistors

SEI

Type RC

•

Non-Inductive Design

Meets Performance Standards of EIA RS-172

Hot Molded Process for Product Uniformity

Ideal for Pulse-Load Handling

Brown Body Color

PERFORMANCE CHARACTERISTICS (TESTED PER MIL-STD-202)

ELECTRICAL

Power Rating (Watts)

Derated to 0 Load at

Rated Continuous Working Voltage (RCWV)

Dielectric Withstand Voltage

Resistance Range

Tolerance

Maximum Pulse Voltage

Insulation Resistance

RC 1/4

1/4 @70°C

130°C

√PR

or 250V

whichever is less

500V (325V @ 3.4"Hg)

2.2Ω – 5.6 meg

±5%

and

±10%

400 volts RMS

10,000 meg min.

±5%

typ. (1% to 7% max.)

±1%

typ. (±2% max.)

-3% typ. (2% to -5% max.)

±1%

max.

±2%

max.

-0.5% to +2% typ. (±3% max.)

±1%

max.

±0.5%

typ. (±2% max.)

-.005%/V to -.032%/V

±0.5%

typ. (±2% max.)

RC 1/2

1/2 @70°C

130°C

√PR

or 350V

whichever is less

700V (450V @ 3.4"Hg)

1.0Ω – 20 meg

±5%

and

±10%

700 volts RMS

10,000 meg min.

±4%

typ. (1% to 6% max.)

±1%

typ. (±2% max.)

-3% typ. (2% to -5% max.)

±1%

max.

±2%

max.

-0.5% to +2% typ. (±3% max.)

±1%

max.

±0.5%

typ. (±2% max.)

-.005%/V to -.032%/V

±0.5%

typ. (±2% max.)

ENVIRONMENTAL

Moisture Resistance

Thermal Shock

Load Life @ 70°C — 1,000 hrs

Vibration (High-Frequency)

Shock (Specified Pulse)

Resistance to Soldering Heat

Terminal Strength

Low-Temperature Operation

Voltage Coefficient (1K - 20 meg)

Short Time Overload

RESISTANCE TEMPERATURE CHARACTERISTICS

Resistance Range

Maximum % resistance change

from room temperature (+25°C)

value.

under 1K

1K to 9.1K

10K to 91K

100K to 910K

1 meg to 10 meg

-55°C

+2.0 to +5.0

+5.0 to +9.0

+8.0 to +11.0

+10.0 to +14.0

+13.0 to +20.0

+105°C

-4.0 to -2.0

-5.0 to -3.0

-7.0 to -5.0

-9.0 to -7.0

-14.0 to -9.0

DIMENSIONS:

FEATURE

A – Lead Length (typ.)

B – Body Length

C – Lead Diameter

D – Body Diameter

Inches (mm)

RC 1/2

1.024

±.032

(26.0

±0.80)

.374 +.032/-.028 (9.50 +0.80/-0.70)

.027

±.002

(0.7

±0.05)

.142

±.008

(3.60

±0.20)

RC 1/4

1.102

.248

.024

.094

±.032

(28.0

±0.80)

±.028

(6.30

±0.70)

±.002

(0.60

±0.05)

±.004

(2.40

±0.10)

ORDERING INFORMATION

1/4

NOTES

1. Special 1Ω

±5%

resistor available in 1/2W only. Contact factory.

2. Dimensions are for bulk packaged product only.

Type

Wattage

Resistance

Tolerance

SEI Electronics Inc.

•

P.O. Box 58789

•

Raleigh, NC 27658-8789

•

Telephone: (919) 850-9500

•

FAX: (919) 850-9504

Toll Free: (888) SEI-SEI-SEI

•

www.seielect.com

•

email: marketing@seielect.com

•

ISO 9002 / QS 9000 Registered

Rev. 12/00
