HYMD232G726DFP8N-D43J Overview

184pin Registered DDR SDRAM DIMMs

Preview

Download Datasheet

View All

184pin Registered DDR SDRAM DIMMs based on 256Mb D ver. (FBGA)

This Hynix Registered Dual In-Line Memory Module (DIMM) series consists of 256Mb D ver. DDR SDRAMs in 60 ball

FBGA package on a 184pin glass-epoxy substrate. This Hynix 256Mb D ver. based Registered DIMM series provide a

high performance 8-byte interface in 5.25" width form factor of industry standard. It is suitable for easy interchange

and addition.

FEATURES

•

JEDEC Standard 184-pin dual in-line memory module

(DIMM)

Two ranks 128M x 72, and One rank 64M x 72, 32M

x 72 organization

Error Check Correction (ECC) Capability

2.6V

0.1V VDD and VDDQ Power supply for

DDR400 and 2.5V

0.2V for DDR333

All inputs and outputs are compatible with SSTL_2

interface

Fully differential clock operations (CK & /CK) with

166/200MHz

DLL aligns DQ and DQS transition with CK transition

Programmable CAS Latency: DDR333(2.5 clock),

DDR400(3 clock)

•

Programmable Burst Length 2 / 4 / 8 with both

sequential and interleave mode

Edge-aligned DQS with data outs and Center-aligned

DQS with data inputs

Auto refresh and self refresh supported

8192 refresh cycles / 64ms

Serial Presence Detect (SPD) with EEPROM

Built with 256Mb DDR SDRAMs in 60 ball FBGA pack-

ages

JEDEC standard reference layout

Lead-free product listed for each configuration

(RoHS compliant)

ADDRESS TABLE

Organization

256MB

512MB

1GB

32M x 72

64M x 72

128M x 72

Ranks

SDRAMs

32Mb x 8

64Mb x 4

# of DRAMs

# of row/bank/column Address

13(A0~A12)/2(BA0,BA1)/10(A0~A9)

13(A0~A12)/2(BA0,BA1)/11(A0~A9,A11)

Refresh

Method

8K / 64ms

PERFORMANCE RANGE

Part-Number Suffix

Speed Bin

CL - tRCD- tRP

CL=3

Max Clock Frequency

CL=2.5

CL=2

-D43

DDR400B

3-3-3

200

166

133

-J

DDR333

2.5-3-3

166

133

Unit

MHz

Note:

1. 2.6V

0.1V VDD and VDDQ Power supply for DDR400 and 2.5V

0.2V for DDR333

Rev. 1.1 / May.2005

This document is a general product description and is subject to change without notice. Hynix Semiconductor does not assume any

responsibility for use of circuits described. No patent licenses are implied.
