ETQW
www.vishay.com
Vishay Sprague
Resin-Coated, Radial-Lead
Tantalum Capacitors
FEATURES
•
•
•
•
•
•
•
•
•
•
RoHS compliant design available
Compliant to RoHS Directive 2002/95/EC
Flame retardant encapsulation
Very high temperature range
Improved humidity class
Very low leakage current
Very high CV product
Very low leakage current
Very low failure rate
Preaged under temperature and voltage
Note
*
Pb containing terminations are not RoHS compliant, exemptions
may apply
MECHANICAL SPECIFICATIONS
Color:
Gold
Laser Marked:
Capacity and voltage in clear text; plus pole
marked, date code (year/month) according to DIN IEC 62
Leads:
Standard (tin/lead), RoHS compliant (100 % tin)
Tantalum capacitors with sintered anode and solid
semiconductor electrolyte with flame retardant fluidized bed
coating. The type ETQW is characterized by very favorable
electrical values even at higher ambient temperatures. The
capacitor complies with DIN 45910 part 147. This type is
also available as a radially taped version.
ORDERING INFORMATION
Q1B
TYPE
ETQW 1A ....
ETQW 6R
685
CAPACITANCE
Expressed in
picofarads. The first
two digits are
significant figures.
The third is the number
of zeros following.
603
DC VOLTAGE RATING
AT + 85 °C
Expressed by zeros if
needed to complete the
3 digit block. A decimal
point is indicated by an
“0“ (603 = 6.3 V)
M
CAPACITANCE
TOLERANCE
M = ± 20 %
K = ± 10 %
00
LEAD STYLE AND
PACKAGING
See Lead Styles
and Packaging table
D
E3
RoHS
COMPLIANT
E3 = 100 % tin
termination (RoHS
compliant design)
Blank = SnPb
termination
(standard design)
DIMENSIONS
in millimeters
Basic version
D
D
Form DS
D
Form L
D
H
H
2
H
2
15 ± 5
Ød
4.5 ± 1.5
1.1 ± 0.1
RM ± 0.5
5.5 ± 0.5
RM ± 0.5
RM ± 0.5
MODEL
ETQW - 1
ETQW - 2
ETQW - 3
ETQW - 4
ETQW - 5
ETQW - 6
Revision: 20-Dec-11
D MAX.
4.5
5.0
6.0
6.5
9.0
9.5
H MAX.
7.5
9.5
10.5
11.5
14.0
17.0
RM
2.5
2.5
2.5
2.5
5.0
5.0
Ø D ± 0.05
0.5
0.5
0.5
0.5
0.5
0.5
FORM DS
RM
H
2
MAX.
10.5
5
12.5
5
13.5
5
14.5
5
17.0
5
20.0
5
FORM L
H
2
MAX.
10.5
12.5
13.5
14.5
-
-
RM
5
5
5
5
-
-
Document Number: 42075
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
ETQW
www.vishay.com
Vishay Sprague
RATINGS AND CASE CODES
C
R
(μF)
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
1A
1A
1B
2C
2D
2E
3F
3G
4H
5J
5L
1A
1B
2C
2D
2E
3F
3G
4H
5J
5L
6M
6P
1A
1B
2C
2D
2E
3F
3G
4H
5J
5L
6N
6P
1A
1B
2C
2D
2E
3F
3G
4H
5K
5L
6N
6R
1A
1A
1B
2C
2D
2E
3F
4H
5J
5K
6M
6N
RATED VOLTAGE U
R
AT + 85 °C
3.0 V
6.3 V
10 V
16 V
25 V
35 V
1A
1A
1A
1A
1A
1A
1A
1B
2C
2D
2E
3F
3G
5J
5L
6M
6P
50 V
1A
1A
1A
1B
1B
2C
2D
2E
3F
3G
4H
5J
5L
6M
6P
STANDARD RATINGS
CAPACITANCE
C
R
(μF)
CASE
CODE
DIMENSIONS
PART NUMBER
D MAX.
(mm)
H MAX.
(mm)
H
2
MAX.
(mm)
RM
± 0.05
d
± 0.05
MAX. DCL
AT + 20 °C
(μA)
MAX. Z
AT 100 kHz
()
MAX. DF
AT 120 Hz
+ 20 °C
U
R
= 3 V
DC
AT + 85 °C, SURGE = 3.9 V; U
C
= 2 V
DC
AT + 125 °C
6.8
10
15
22
33
47
68
100
150
220
330
1A
1A
1B
2C
2D
2E
3F
3G
4H
5J
5L
Q1A685003(1)(2)D
Q1A106003(1)(2)D
Q1B156003(1)(2)D
Q2C226003(1)(2)D
Q2D336003(1)(2)D
Q2E476003(1)(2)D
Q3F686003(1)(2)D
Q3G107003(1)(2)D
Q4H157003(1)(2)D
Q5J227003(1)(2)D
Q5L337003(1)(2)D
4.5
4.5
4.5
5.0
5.0
5.0
6.0
6.0
6.5
9.0
9.0
7.5
7.5
7.5
9.5
9.5
9.5
10.5
10.5
11.5
14.0
14.0
10.5
10.5
10.5
12.5
12.5
12.5
13.5
13.5
14.5
17.0
17.0
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
5.0
5.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.8
1.1
1.6
2.4
3.6
5.3
7.9
5.4
4.5
3.6
2.9
2.3
1.8
1.4
1.1
0.9
0.7
0.6
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.08
0.08
0.08
0.08
Note
• Part number definitions:
(1) Insert M for ± 20 % tolerance or K for ± 10 %
(2) Lead style and packaging code, see Lead Styles and Packaging table
Revision: 20-Dec-11
Document Number: 42075
2
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
ETQW
www.vishay.com
Vishay Sprague
DIMENSIONS
STANDARD RATINGS
CAPACITANCE
C
R
(μF)
CASE
CODE
PART NUMBER
D MAX.
(mm)
4.5
4.5
5.0
5.0
5.0
6.0
6.0
6.5
9.0
9.0
9.5
9.5
4.5
4.5
5.0
5.0
5.0
6.0
6.0
6.5
9.0
9.0
9.5
9.5
4.5
4.5
5.0
5.0
5.0
6.0
6.0
6.5
9.0
9.0
9.5
9.5
H MAX.
(mm)
7.5
7.5
9.5
9.5
9.5
10.5
10.5
11.5
14.0
14.0
17.0
17.0
7.5
7.5
9.5
9.5
9.5
10.5
10.5
11.5
14.0
14.0
17.0
17.0
7.5
7.5
9.5
9.5
9.5
10.5
10.5
11.5
14.0
14.0
17.0
17.0
H
2
MAX.
(mm)
10.5
10.5
12.5
12.5
12.5
13.5
13.5
14.5
17.0
17.0
20.0
20.0
10.5
10.5
12.5
12.5
12.5
13.5
13.5
14.5
17.0
17.0
20.0
20.0
10.5
10.5
12.5
12.5
12.5
13.5
13.5
14.5
17.0
17.0
20.0
20.0
RM
± 0.05
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
5.0
5.0
5.0
5.0
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
5.0
5.0
5.0
5.0
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
5.0
5.0
5.0
5.0
d
± 0.05
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
MAX. DCL
AT + 20 °C
(μA)
MAX. Z
AT 100 kHz
()
MAX. DF
AT 120 Hz
+ 20 °C
U
R
= 6.3 V
DC
AT + 85 °C, SURGE = 7.8 V; U
C
= 4 V
DC
AT + 125 °C
4.7
6.8
10
15
22
33
47
68
100
150
220
330
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
1A
1B
2C
2D
2E
3F
3G
4H
5J
5L
6M
6P
1A
1B
2C
2D
2E
3F
3G
4H
5J
5L
6N
6P
1A
1B
2C
2D
2E
3F
3G
4H
5K
5L
6N
6R
Q1A475603(1)(2)D
Q1B685603(1)(2)D
Q2C106603(1)(2)D
Q2D156603(1)(2)D
Q2E226603(1)(2)D
Q3F336603(1)(2)D
Q3G476603(1)(2)D
Q4H686603(1)(2)D
Q5J107603(1)(2)D
Q5L157603(1)(2)D
Q6M227603(1)(2)D
Q6P337603(1)(2)D
Q1A335010(1)(2)D
Q1B475010(1)(2)D
Q2C685010(1)(2)D
Q2D106010(1)(2)D
Q2E156010(1)(2)D
Q3F226010(1)(2)D
Q3G336010(1)(2)D
Q4H476010(1)(2)D
Q5J686010(1)(2)D
Q5L107010(1)(2)D
Q6N157010(1)(2)D
Q6P227010(1)(2)D
Q1A225016(1)(2)D
Q1B335016(1)(2)D
Q2C475016(1)(2)D
Q2D685016(1)(2)D
Q2E106016(1)(2)D
Q3F156016(1)(2)D
Q3G226016(1)(2)D
Q4H336016(1)(2)D
Q5K476016(1)(2)D
Q5L686016(1)(2)D
Q6N107016(1)(2)D
Q6R157016(1)(2)D
0.5
0.5
0.5
0.8
1.1
1.7
2.4
3.4
5.0
7.6
11.1
16.6
0.5
0.5
0.5
0.8
1.2
1.8
2.6
3.8
5.4
8.0
12.0
17.6
0.5
0.5
0.6
0.9
1.3
1.9
2.8
4.2
6.0
8.7
12.8
19.2
5.4
4.5
3.6
2.9
2.3
1.8
1.7
1.1
0.9
0.7
0.6
0.5
5.9
4.5
3.6
2.9
2.3
1.8
1.4
1.1
0.9
0.7
0.6
0.5
6.3
5.4
4.1
2.9
2.3
1.8
1.4
1.1
0.9
0.7
0.6
0.5
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.08
0.08
0.08
0.08
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.08
0.08
0.08
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.08
0.08
U
R
= 10 V
DC
AT + 85 °C, SURGE = 13 V; U
C
= 6.3 V
DC
AT + 125 °C
U
R
= 16 V
DC
AT + 85 °C, SURGE = 20.8 V; U
C
= 10 V
DC
AT + 125 °C
Note
• Part number definitions:
(1) Insert M for ± 20 % tolerance or K for ± 10 %
(2) Lead style and packaging code, see Lead Styles and Packaging table
Revision: 20-Dec-11
Document Number: 42075
3
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
ETQW
www.vishay.com
Vishay Sprague
DIMENSIONS
STANDARD RATINGS
CAPACITANCE
C
R
(μF)
CASE
CODE
PART NUMBER
D MAX.
(mm)
4.5
4.5
4.5
5.0
5.0
5.0
6.0
6.5
9.0
9.0
9.5
9.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
5.0
5.0
5.0
6.0
6.0
9.0
9.0
9.5
9.5
4.5
4.5
4.5
4.5
4.5
5.0
5.0
5.0
6.0
6.0
6.5
9.0
9.0
9.5
9.5
H MAX.
(mm)
7.1
7.5
7.5
9.5
9.5
9.5
10.5
11.5
14.0
14.0
17.0
17.0
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
9.5
9.5
9.5
10.5
10.5
14.0
14.0
17.0
17.0
7.5
7.5
7.5
7.5
7.5
9.5
9.5
9.5
10.5
10.5
11.5
14.0
14.0
17.0
17.0
H
2
MAX.
(mm)
10.5
10.5
10.5
12.5
12.5
12.5
13.5
14.5
17.0
17.0
20.0
20.0
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
12.5
12.5
12.5
13.5
13.5
17.0
17.0
20.0
20.0
10.5
10.5
10.5
10.5
10.5
12.5
12.5
12.5
13.5
13.5
14.5
17.0
17.0
20.0
20.0
RM
± 0.05
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
5.0
5.0
5.0
5.0
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
5.0
5.0
5.0
5.0
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
5.0
5.0
5.0
5.0
d
± 0.05
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
MAX. DCL
AT + 20 °C
(μA)
MAX. Z
AT 100 kHz
()
MAX. DF
AT 120 Hz
+ 20 °C
U
R
= 25 V
DC
AT + 85 °C, SURGE = 32.5 V; U
C
= 16 V
DC
AT + 125 °C
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
1A
1A
1B
2C
2D
2E
3F
4H
5J
5K
6M
6N
1A
1A
1A
1A
1A
1A
1A
1B
2C
2D
2E
3F
3G
5J
5L
6M
6P
1A
1A
1A
1B
1B
2C
2D
2E
3F
3G
4H
5J
5L
6M
6P
Q1A105025(1)(2)D
Q1A155025(1)(2)D
Q1B225025(1)(2)D
Q2C335025(1)(2)D
Q2D475025(1)(2)D
Q2E685025(1)(2)D
Q3F106025(1)(2)D
Q4H156025(1)(2)D
Q5J226025(1)(2)D
Q5K336025(1)(2)D
Q6M476025(1)(2)D
Q6N686025(1)(2)D
Q1A104035(1)(2)D
Q1A154035(1)(2)D
Q1A224035(1)(2)D
Q1A334035(1)(2)D
Q1A474035(1)(2)D
Q1A684035(1)(2)D
Q1A105035(1)(2)D
Q1A155035(1)(2)D
Q2C225035(1)(2)D
Q2D335035(1)(2)D
Q2E475035(1)(2)D
Q3F685035(1)(2)D
Q3G106035(1)(2)D
Q5J156035(1)(2)D
Q5L226035(1)(2)D
Q6M336035(1)(2)D
Q6P476035(1)(2)D
Q1A104050(1)(2)D
Q1A154050(1)(2)D
Q1A224050(1)(2)D
Q1B334050(1)(2)D
Q1B474050(1)(2)D
Q2C684050(1)(2)D
Q2D105050(1)(2)D
Q2E155050(1)(2)D
Q3F225050(1)(2)D
Q3G335050(1)(2)D
Q4H475050(1)(2)D
Q5J685050(1)(2)D
Q5L106050(1)(2)D
Q6M156050(1)(2)D
Q6P226050(1)(2)D
0.5
0.5
0.5
0.7
0.9
1.4
2.0
3.0
4.4
6.6
9.4
13.6
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.9
1.3
1.9
2.8
4.2
6.2
9.2
13.2
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.9
1.3
1.9
2.7
4.0
6.0
8.8
7.7
6.8
5.4
4.1
2.9
2.3
1.8
1.4
1.1
0.9
0.7
0.6
34.2
27.0
20.7
16.2
12.6
9.0
7.2
5.9
4.5
3.2
2.3
1.8
1.4
1.1
0.9
0.7
0.6
34.2
27.0
20.7
16.2
12.6
9.0
7.2
5.9
4.5
3.2
2.3
1.8
1.4
1.1
0.9
0.04
0.04
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.04
0.04
0.04
0.04
0.04
0.04
0.04
0.04
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.04
0.04
0.04
0.04
0.04
0.04
0.04
0.04
0.06
0.06
0.06
0.06
0.06
0.06
0.06
U
R
= 35 V
DC
AT + 85 °C, SURGE = 45.5 V; U
C
= 23 V
DC
AT + 125 °C
U
R
= 50 V
DC
AT + 85 °C, SURGE = 65 V; U
C
= 33 V
DC
AT + 125 °C
Note
• Part number definitions:
(1) Insert M for ± 20 % tolerance or K for ± 10 %
(2) Lead style and packaging code, see Lead Styles and Packaging table
Revision: 20-Dec-11
Document Number: 42075
4
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
ETQW
www.vishay.com
PERFORMANCE CHARACTERISTICS
1.
2.
3.
4.
5.
Climatic Category:
55/125/56 acc. to IEC
Temperature Range:
- 55 °C up to + 125 °C with linear
voltage derating to category voltage UC
Rated Voltage, Category Voltage:
3 V to 50 V;
2 V to 33 V
Surge Voltage:
1.3 times of rated voltage at + 85 °C
Reverse Voltage (Temporary):
15 % of the rated DC voltage at + 20 °C
10 % of the rated DC voltage at + 55 °C
5 % of the rated DC voltage at + 85 °C
Rated Capacitance:
0.1 μF to 330 μF
Capacitance Tolerance:
± 20 %, ± 10 %
Leakage Current in μA:
Measured at + 20 °C after
5 min:
0.008 x C
R
x U
R
or 0.5 μA, whichever is greater
Dissipation Factor:
At 120 Hz and + 20 °C
See table
Vishay Sprague
The values apply for + 20 °C For higher temperatures,
the values have to be multiplied with the following
factors:
TEMPERATURE
+ 50 °C
+ 85 °C
+ 125 °C
FACTOR
0.7
0.5
0.3
Intermediate values can be obtained by linear
interpolation.
For further notes on AC voltage stress: See General
Information
12.
Service life:
> 300 000 h
(1)
13.
Failure percentage:
0.3 % within 100 000 h
(1)
14.
Failure rate ():
0.3 10- 7/h =
30 fit
(1)
15.
Failure criteria:
Catastrophic failure: Short circuit or
interruption
Drift failure:
DC/C > + 5 - 15 %
Z > 3 times initial limit value
IR > 5 times initial value + 5 μA
6.
7.
8.
9.
10.
Impedance:
Measured at 100 kHz and + 20 °C
See table
11.
Permissible AC Voltage Stress:
The highest
permissible AC voltage for the respective frequency
may be taken from the brochure “General information”.
16.
Characteristics at high and low temperatures
(the values shall not exceed the following limits)
TEST TEMPERATURE
C/C
<
tan
1.5 μF
< 10 μF
< 100 μF
100 μF
- 55 °C
- 10 %
0.04
0.06
0.08
0.10
+ 20 °C
-
0.04
0.06
0.06
0.08
0.008 x C
R
x U
R
or 0.5 μA
whichever is greater
+ 85 °C
+ 12 %
0.04
0.06
0.08
0.10
0.08 x C
R
x U
R
or 5.0 μA
whichever is greater
+ 125 °C
+ 15 %
0.04
0.06
0.08
0.10
0.1 x C
R
x U
R
or 6.25 μA
whichever is greater
(2)
Leakage current I
R
-
Notes
(1)
Related to U , + 40 °C and a circuit resistance of
3
/V
R
(2)
Measured at category voltage
Revision: 20-Dec-11
Document Number: 42075
5
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
京公网安备 11010802033920号
EEWORLD
