ZD5233A

Description
500mW Zener Diode Series
File Size262KB,14 Pages
ManufacturerCYSTEKEC
Websitehttp://www.cystekec.com/
Download Datasheet Compare View All

ZD5233A Overview

500mW Zener Diode Series

CYStech Electronics Corp.
Zener Diode Series
Spec. No. : C326N3
Issued Date : 2003.04.14
Revised Date : 2013.08.05
Page No. : 1/14
ZD52XXAN3
SOT-23
Thermal Characteristics
Characteristics
Total Device Dissipation FR-5 Board
TA=25°C, Derate above 25°C
Total Device Dissipation
Alumina Substrate**TA=25°C, Derate above 25°C
Thermal Resistance Junction to Ambient
Junction and Storage Temperature
Symbol
PD
PD
RθJA
Tj, Tstg
Max
225
1.8
300
2.4
417
-55 to +150
Unit
mW
mW/°C
mW
mW/°C
°C/W
°C
*FR-5 - 1.0×0.75×0.062 in. **Alumina - 0.4×0.3×0.024 in. 99.5% alumina.
Electrical Characteristic
(V
F
=0.9V Max @I
F
=10mA for all types.)
Device
ZD5221A
ZD5223A
ZD5225A
ZD5226A
ZD5227A
ZD5228A
ZD5229A
ZD5230A
ZD5231A
ZD5232A
ZD5233A
ZD5234A
ZD5235A
ZD5236A
ZD5237A
ZD5238A
ZD5239A
ZD5240A
ZD5241A
ZD5242A
ZD5243A
ZD5245A
ZD5246A
Marking
Code
18A
18C
18E
8A
8B
8C
8D
8E
8F
8G
8H
8J
8K
8L
8M
8N
8P
KF5
8R
8S
8T
8V
8W
Nom. Zener Voltage
V
Z
@I
ZT
(V)
Nom. Min Max
2.4
2.35 2.45
2.7
2.65 2.75
3.0
2.94 3.06
3.3
3.23 3.37
3.6
3.53 3.67
3.9
3.82 3.98
4.3
4.21 4.39
4.7
4.61 4.79
5.1
5.00 5.20
5.6
5.49 5.71
6.0
5.88 6.12
6.2
6.08 6.32
6.8
6.66 6.94
7.5
7.35 7.65
8.2
8.04 8.36
8.7
8.53 8.87
9.1
8.92 9.28
10
9.80 10.20
11
10.78 11.22
12
11.76 12.24
13
12.74 13.26
15
14.70 15.30
16
15.68 16.32
Max. Zener Impedance
Z
ZT
(Ω)
30
30
30
28
24
23
22
19
17
11
7.0
7.0
5.0
6.0
8.0
8.0
10
17
22
30
13
16
17
I
ZT
(mA)
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
9.5
8.5
7.8
Z
ZK
(Ω)
1200
1300
1600
1600
1700
1900
2000
1900
1600
1600
1600
1000
750
500
500
600
600
600
600
600
600
600
600
I
ZK
(mA)
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
Max. Zener
Current
I
ZM
@Ta
(mA)
188
167
150
138
126
115
106
97
89
81
76
73
67
61
55
55
50
45
41
38
35
30
28
Max. Reverse
Leakage Current
I
R
V
R
(μA)
(V)
100
1.0
1.0
75
1.0
50
1.0
25
1.0
15
1.0
10
1.0
5.0
2.0
5.0
2.0
5.0
5.0
3.0
5.0
3.5
5.0
4.0
3.0
5.0
3.0
6.0
3.0
6.5
3.0
6.5
3.0
7.0
3.0
8.0
2.0
8.4
1.0
9.1
0.5
9.9
0.1
11
0.1
12
ZD52XXAN3 series
CYStek Product Specification
