SBR250-10JS

Description
25 A, 100 V, SILICON, RECTIFIER DIODE, TO-220AB
CategoryDiscrete semiconductor    diode
File Size243KB,3 Pages
ManufacturerSANYO
Websitehttp://www.semic.sanyo.co.jp/english/index-e.html
Download Datasheet Parametric View All

SBR250-10JS Overview

25 A, 100 V, SILICON, RECTIFIER DIODE, TO-220AB

SBR250-10JS Parametric

Parameter NameAttribute value
MakerSANYO
Parts packaging codeTO-220AB
package instructionR-XSFM-T3
Contacts3
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresHIGH RELIABILITY, LOW NOISE
applicationGENERAL PURPOSE
ConfigurationCOMMON CATHODE, 2 ELEMENTS
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)0.85 V
JEDEC-95 codeTO-220AB
JESD-30 codeR-XSFM-T3
Maximum non-repetitive peak forward current120 A
Number of components2
Phase1
Number of terminals3
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Maximum output current25 A
Package body materialUNSPECIFIED
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Certification statusNot Qualified
Maximum repetitive peak reverse voltage100 V
surface mountNO
technologySCHOTTKY
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Base Number Matches1
Ordering number : ENA1658
SBR250-10JS
SANYO Semiconductors
DATA SHEET
SBR250-10JS
Applications
Schottky Barrier Diode (Twin Type
Cathode Common)
100V, 25A Rectifier
High frequency rectification (switching regulators, converters, choppers).
Features
Low reverse current.
Low switching noise.
High reliability due to highly reliable planar structure.
Attachment workability is good by Mica-less package.
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Repetitive Peak Reverse Voltage
Nonrepetitive Peak Reverse Surge Voltage
Average Output Current
Surge Forward Current
Junction Temperature
Storage Temperature
Symbol
VRRM
VRSM
I
O
I
FSM
Tj
Tstg
50Hz resistive load, sine wave Tc=59°C
50Hz sine wave, 1 cycle
Conditions
Ratings
100
105
25
120
-
-55 to +150
-
-55 to +150
Unit
V
V
A
A
°C
°C
Electrical Characteristics
at Ta=25°C
Parameter
Reverse Voltage
Forward Voltage
Reverse Current
Interterminal Capacitance
Thermal Resistance
Symbol
VR
VF
IR
C
Rth(j-c)
Conditions
IR=5mA, Tj=25°C *
IF=12.5A, Tj=25°C *
VR=50V, Tj=25°C *
VR=10V, Tj=25°C *
Junction-Case : Smoothed DC
450
3.0
Ratings
min
100
0.85
300
typ
max
Unit
V
V
μA
pF
°C / W
Note)
*
: Value per element
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not
be intended for use for any "special application" (medical equipment whose purpose is to sustain life,
aerospace instrument, nuclear control device, burning appliances, transportation machine, traffic signal
system, safety equipment etc.) that shall require extremely high level of reliability and can directly threaten
human lives in case of failure or malfunction of the product or may cause harm to human bodies, nor shall they
grant any guarantee thereof. If you should intend to use our products for applications outside the standard
applications of our customer who is considering such use and/or outside the scope of our intended standard
applications, please consult with us prior to the intended use. If there is no consultation or inquiry before the
intended use, our customer shall be solely responsible for the use.
Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are
not guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer' s products or equipment. To verify symptoms and states that cannot be evaluated in an
independent device, the customer should always evaluate and test devices mounted in the customer' s
products or equipment.
www.semiconductor-sanyo.com/network
21710SD TK IM TC-00002262 No. A1658-1/3
