SMT Power Inductors - LPO6013 Series
• Very low profile – only 1.3 mm high!
• Handles saturating current up to 1.9 Amps
Designer’s Kit C352
contains 3 each of all values
Core material
Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
111 – 122 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
1000/7″reel; 3500/13″ reel Plastic tape: 12 mm wide,
0.23 mm thick, 8 mm pocket spacing, 1.4 mm pocket depth
Recommended pick and place nozzle
OD: 5.6 mm; ID:
≤
2.8 mm
PCB washing
Only pure water or alcohol recommended
1
2
Part number
1
L
2
(µH)
1.0
1.5
2.2
3.3
3.9
±20%
±20%
±20%
±20%
±20%
2
DCR
SRF
max
typ
2
Isat
3
3
Irms
4
(Ohms) (MHz) (A)
(A)
0.06
0.07
0.08
0.11
0.13
0.15
0.20
0.22
0.30
0.38
0.52
0.73
0.96
1.0
1.7
3.2
4.3
5.8
7
10
14
21
200
200
150
110
100
90
70
65
60
47
37
30
28
25
21
17
14
10
8
7
1.9
1.6
1.3
1.1
1.0
0.90
0.70
0.70
0.60
0.55
0.45
0.40
0.35
0.30
0.28
0.22
0.19
0.15
0.13
0.10
1.5
1.4
1.3
1.3
1.2
1.2
1.2
1.0
1.0
0.85
0.80
0.74
0.67
0.60
0.49
0.35
0.30
0.26
0.23
0.20
0.18
0.13
1. When ordering, please specify
termination
and
packaging
code:
LPO6013-473KLC
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
Special order: T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (1000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape (3500 parts per full reel).
2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc.
3. DC current at which the inductance drops 10% (typ) from its value
without current.
4. Current that causes a 40°C temperature rise from 25°C ambient.
5. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
LPO6013-102ML_
LPO6013-152ML_
LPO6013-222ML_
LPO6013-332ML_
LPO6013-392ML_
LPO6013-472ML_
LPO6013-682ML_
LPO6013-822ML_
LPO6013-103KL_
LPO6013-153KL_
LPO6013-223KL_
LPO6013-333KL_
LPO6013-393KL_
LPO6013-473KL_
LPO6013-683KL_
LPO6013-104KL_
LPO6013-154KL_
LPO6013-224KL_
LPO6013-334KL_
LPO6013-474KL_
4.7 ±20%
6.8 ±20%
8.2 ±20%
10. ±10%
15. ±10%
22. ±10%
33. ±10%
39. ±10%
47. ±10%
68. ±10%
100. ±10%
150. ±10%
220. ±10%
330. ±10%
470. ±10%
LPO6013-684KL_ 680. ±10%
LPO6013-105KL_ 1000. ±10%
5.6 0.09
4.7 0.07
Specifications subject to change without notice.
Please check our website for latest information.
Document 286-1
Revised 10/15/08
© Coilcraft, Inc. 2009
