Document 333-1
SMT Power Inductors - LPO6610 Series
• Very low profile - only 1.0 mm high!
• Handles current up to 1.7 Amps rms
Designer’s Kit C367
contains 3 each of all values
Core material
Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
91.0 – 95.0 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
1000/7″reel Plastic tape: 12 mm wide, 0.3 mm thick,
8 mm pocket spacing, 1.2 mm pocket depth
PCB washing
Only pure water or alcohol recommended
Part number
1
L
2
DCR
±20% max
(µH) (Ohms)
SRF
typ
(MHz)
190
140
115
90
88
66
55
42
38
29
22
18
14
12
10
8
1. When ordering, please specify
termination
and
packaging
codes:
Isat
3
(A)
2.1
1.9
1.6
1.3
1.1
0.90
0.80
0.65
0.50
0.40
0.35
0.30
0.25
0.18
0.16
0.13
Irms
4
(A)
1.7
1.5
1.4
1.2
1.1
0.85
0.75
0.60
0.52
0.42
0.36
0.30
0.26
0.21
0.18
0.13
LPO6610-334MLC
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (1000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc using an Agilent/HP
4263B LCR meter or equivalent.
3. DC current at which the inductance drops 10% (typ) from its value
without current.
4. Current that causes a 40°C temperature rise from 25°C ambient.
5. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
LPO6610-122ML_
1.2
0.08
LPO6610-152ML_
1.5
0.10
LPO6610-222ML_
2.2
0.12
LPO6610-332ML_
3.3
0.16
LPO6610-472ML_
4.7
0.20
LPO6610-682ML_
6.8
0.32
LPO6610-103ML_
10
0.41
LPO6610-153ML_
15
0.55
LPO6610-223ML_
22
0.85
LPO6610-333ML_
33
1.3
LPO6610-473ML_
47
1.8
LPO6610-683ML_
68
2.5
LPO6610-104ML_ 100
3.5
LPO6610-154ML_ 150
5.0
LPO6610-224ML_ 220
7.0
LPO6610-334ML_ 330
15.0
Specifications subject to change without notice.
Please check our website for latest information.
Document 333-1
Revised 10/15/08
© Coilcraft, Inc. 2009
