CL-0-2002-9914-I datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> CL-0-2002-9914-I

CL-0-2002-9914-I: DescriptionSingle Color LED,; CategoryLED optoelectronic/LED photoelectric; File Size379KB，1 Pages; ManufacturerVisual Communications Company, LLC; Websitehttp://vcclite.com

Download Datasheet Parametric View All

CL-0-2002-9914-I Overview

Single Color LED,

CL-0-2002-9914-I Parametric

Parameter Name	Attribute value
Maker	Visual Communications Company, LLC
Reach Compliance Code	compliant
Optoelectronic device types	SINGLE COLOR LED

Preview

Download Datasheet

View All

CL Series 10mm

Panel Mount LED

Special Features

•

Rugged watertight construction – sealed to IP67

Front mounts with supplied hex nut, spacer and gasket

Optional internal resistor for 5V-60VDC and 5V-240VAC

Mil Spec MIL-W22759/33 wire and connector options

Internally potted-suitable for high vibration applications

10mm Panel Mount LED Assemblies

Specifications

• Mounting hole: .555” +.004/-.000 (14.10 +0.10/-0 mm)

• Termination: 24AWG UL1061 6.0” (152.4mm) red (anode) and

black (cathode) leads stripped .250” (6.35 mm) standard or

LED pins

• Housing: Nickel-plated brass housing M14 size

• Mounting torque: 20 ± 2 in-lb ( 2.26 ± 0.23 N-mm )

• Maximum panel thickness: .394”(10mm) without gasket, .354”

(9mm) with gasket

Resistor Chart

OPERATING SPECIFICATIONS

Resistor

Value

Code

0000

9900

9928

9901

Voltage

Current

(mA)

10 or 20

3.5

16500

66400

8250

7500

Contact

VCC

Contact

VCC

4870

4530

1100

953

511

357

150

2610

2320

2210

1910

1000

715

Resistor Value

(Ohms)

Green,Yellow

Red, Bicolor LED

None

332

121

Resistor Value

(Ohms)

Blue,

White LED

Not Available

120VAC

240VAC

Electrical and Optical Characteristics (TA = 25°C)

LED

Part #

Color

Luminous

Intensity (mcd)

Typ. @ I

(mA)

Typ. @ I

(mA)

Viewing

Angle

Peak

Wave-

length

(nm)

9902

9903

9904

9905

9906

9907

9922

9908

9909

HIGH EFFICIENCY

2001

2002

2003

Red

Green

Yellow

100.0

60.0

50.0

2.0

2.2

2.1

30°

627

565

590

ULTRA BRIGHT – DAYLIGHT READABLE

2006

2007

2008

Red

Yellow

Green

420.0

500.0

100.0

1.85

2.0

2.1

30°

655

590

574

9910

9911

9912

9913

BICOLOR (2 leaded)

2005

BLUE

2004

Blue

400.0

3.3

20°

460

Red

Green

750.0

130.0

1.95

2.1

50°

645

574

9914

9915

0120

0240

Note: Bi-Color not available in AC voltages.

Package Dimensions - M14

How to Order

LED

Resistor

Specifications Value Code

xxxx

See

LED

Chart

xxxx-I

See

Resistor

Chart

Bipins=0(IP67)

Leads=1(IP67)

All dimensions are in inches (mm)
