YAGEO CORPORATION
SMD RESISTORS
Thick Film Chip Resistors
RC Series
FEATURES
Extremely Thin and Light
Highly Reliable Multilayer Electrode Construction
Compatible with all Soldering Process
Highly Stable in Auto-Placement Surface Mounting Applications
Barrier Layer End Termination
Zero Ohm Jumper is Available
Available in 8mm Tape & Reel per EIA RS481
Resistor(RuO
2
)
(Jumper chip is a conductor)
Overcoat
Alumina Substrate
Secondary Electrode
(Nickel Plated)
External Electrode
(Solder Plated)
Internal Electrode (Ag-Pd)
DIMENSIONS
STYLE
I
1
I
1
Unit : mm
L
0.60± 0.10
1.00± 0.10
1.60± 0.10
2.00± 0.10
3.10± 0.10
3.10± 0.10
5.00± 0.10
6.35± 0.10
W
0.30± 0.05
0.50± 0.05
0.80± 0.10
1.25± 0.10
1.60± 0.10
2.60± 0.15
2.50± 0.15
3.20± 0.15
H
0.25± 0.05
0.35± 0.05
0.45± 0.10
0.50± 0.10
0.55± 0.10
0.55± 0.10
0.55± 0.10
0.55± 0.10
I
1
0.15± 0.10
0.20± 0.10
0.25± 0.15
0.35± 0.20
0.45± 0.20
0.50± 0.20
0.60± 0.20
0.60± 0.20
I
2
0.15± 0.10
0.25± 0.10
0.25± 0.15
0.35± 0.20
0.40± 0.20
0.50± 0.20
0.50± 0.20
0.50± 0.20
RC0201
RC0402
RC0603
H
I
2
L
RC0805
I
2
W
RC1206
RC1210
RC2010
RC2512
2
3
Note :
ELECTRICAL CHARACTERISTICS
STYLE
Power Rating @ 70°C
Operating Temp. Range
Maximum Working Voltage
Maximum Overload Voltage
Dielectric Withstand Voltage
Resistance Range
E24Tol.
±
2%,
±
5%
E96Tol.
±
0.5%,
±
1%
Zero Ohm Jumper<(0.05Ω)
TCR
±
100ppm/°C
±
200ppm/°C
±
400ppm/°C
Jumper Criteria
Rated Current (A)
Maximum Current (A) @<1sec
0.5
1.0
1.0
2.0
1.0
2.0
2.0
5.0
2.0
10.0
2.0
10.0
2.0
10.0
2.0
10.0
–
10Ω ~ 1MΩ
–
–
10Ω ~ 3.3MΩ
2Ω ~ 10Ω
10Ω ~ 1MΩ
1Ω ~ 10Ω, >1MΩ
–
10Ω ~ 1MΩ
2Ω ~ 3.3MΩ
1Ω ~ 22MΩ
RC0201
1/20W
-55°C ~ +125°C
25V
50V
50V
50V
100V
100V
50V
100V
100V
150V
300V
300V
200V
400V
500V
200V
400V
500V
200V
400V
500V
200V
400V
500V
RC0402
1/16W
RC0603
1/10W
RC0805
1/8W
RC1206
1/4W
RC1210
1/3W
RC2010
3/4W
RC2512
1W
100Ω ~ 2.2MΩ 100Ω ~ 2.2MΩ
ENVIRONMENTAL CHARACTERISTICS
PERFORMANCE TEST
Temperature Coefficient
Thermal Shock
Low Temperature Operation
Short Time Overload
Insulation Resistance
Dielectric Withstand Voltage
Resistance to Soldering Heat
Moisture Resistance
Life
Solderability
Bending Strength
TEST METHOD
MIL-STD-202F, Method 304
MIL-STD-202F, Method 107
MIL-R-55342D, Para.4.7.4
MIL-R-55342D, Para.4.7.5
MIL-STD-202F, Method 302
MIL-STD-202F, Method 301
MIL-STD-202F, Method 210C
MIL-STD-202F, Method 106F
MIL-STD-202F, Method 108A
MIL-STD-202F, Method 208G
- 55°C to +125°C
5 Cycles, -55°C to +125°C (Step by Step 2 min.)
One Hour at - 65°C Followed by 45 Minutes RCWV
2.5 Times RCWV for 5 Seconds
RCOV for 1 Minute
R.M.S. for 1 Minute
Soldered to Test Board at 260°C for 10 Seconds
42 Cycles. Total 1000 Hours
1000 Hours at 70°C RCWV Intermittent
230°C for 5 Seconds
±
(1%+0.05Ω)
±
(0.5%+0.05Ω)
±
(0.5%+0.05Ω)
±
(1%+0.05Ω)
±
(0.5%+0.05Ω)
±
(0.5%+0.05Ω)
±
(1%+0.05Ω)
1% TOL.
5% TOL.
by Type
±
(1%+0.05Ω)
±
(1%+0.05Ω)
±
(2%+0.05Ω)
>10GΩ
by Type
±
(1%+0.05Ω)
±
(2%+0.05Ω)
±
(3%+0.05Ω)
>95% Coverage
±
(1%+0.05Ω)
JIS-C-5202, Para.6.1.4, Unit Mounted in Center of 90mm Board Length,
Deflected 5mm (power chip 2mm) in Either Direction for 5 Seconds
35
14
Note :
EXPLANATIONS OF ORDERING CODE
For Chip Resistors (RC, RT, RJ, RL, RS, SK Series) & RW, RP Series
Explanations of Ordering Code
RC
0805
F
R
D
10
1K47
Code 12~23
Resistance Value
for Example
0R1
100K
1R
1M
10R
10M
100R
1K
10K
Code 1~2
Series Name
See Index
Code 3~6
Size Code
See Following
Table
Code 8
Packing Style
R=Paper Tape Reel
K=Embossed Plastic
Tape Reel
B=Bulk Bag
C=Bulk Cassette
Code 10~11
Special Type
07=7 inch Dia. Reel
10=10 inch Dia. Reel
13=13inch Dia. Reel
MA=MA-Type Forming
MB=MB-Type Forming
MN=MN-Type Forming
MW=MW-Type Forming
Code 7
Resistance Tolerance
B=± 0.1%
C=± 0.25%
D=± 0.5%
F=± 1%
G=± 2%
J=± 5%
K=± 10%
Code 9
Temperature Coefficient
of Resistance
A=± 5ppm/˚C
B=± 10ppm/˚C
C=± 15ppm/˚C
D=± 25ppm/˚C
E=± 50ppm/˚C
F=± 100ppm/˚C
G=± 200ppm/˚C
H=± 250ppm/˚C
“-”Base on Spec.
CODE 3~6
SIZE CODE (UNIT: INCHES)
0201=0.024 x 0.012
0402=0.040 x 0.020
0603=0.063 x 0.033
0805=0.083 x 0.051
1206=0.122 x 0.063
1210=0.122 x 0.102
2010=0.197 x 0.098
2512=0.250 x 0.126
5020=0.472 x 0.196
5020=0.472 x 0.196
5021=0.472 x 0.196
5022=0.472 x 0.196
