60W Isolated Triple Output Switching Power Supply
Features :
I T- 6 0
series
Isolated output & GND for CH1,CH2,CH3
Universal AC input/Full range
Protections:Short circuit/Over load/Over voltage
LED indicator for power on
100% full load burn-in test
Fixed switching frequency at 67KHz
2 years warranty
SPECIFICATION
MODEL
OUTPUT
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
PEAK LOAD (3sec.)
VOLTAGE ADJ. RANGE
IT-60D
CH1
5V
3A
0.5 ~ 3A
58.2W
Note.4
70W
IT-60F
CH2
12V
0.8A
0.1 ~ 1A
CH3
24V
1.4A
0.2 ~ 2A
CH1
5V
3A
0.5 ~ 3A
58.2W
120mVp-p
8.0%
2.0%
5.0%
240mVp-p
8.0%
2.0%
5.0%
80mVp-p
CH1 : 4.75 ~ 5.5V
3.0%
1.0%
2.0%
150mVp-p
8.0%
2.0%
5.0%
240mVp-p
8.0%
2.0%
5.0%
CH2
15V
0.8A
0.1 ~ 1A
CH3
24V
1.3A
0.2 ~ 2A
RIPPLE & NOISE (max.)
Note.2
80mVp-p
CH1 : 4.75 ~ 5.5V
VOLTAGE TOLERANCE
Note.3
3.0%
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
EFFICIENCY(Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVER LOAD
1.0%
2.0%
300ms, 20ms/230VAC
80ms/230VAC
90 ~ 264VAC
47 ~ 63Hz
76%
800ms, 20ms/115VAC at full load
18ms/115VAC at full load
127 ~ 370VDC
INPUT
1.8A/115VAC
0.9A/230VAC
COLD START 20A/115VAC
40A/230VAC
<1mA / 240VAC
72 ~ 90W rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
5V: 5.75 ~ 6.75V
Protection type : Hiccup mode, recovers automatically after fault condition is removed
-10 ~ +60 (Refer to output load derating curve)
20 ~ 90% RH non-condensing
-20 ~ +85 , 10 ~ 95% RH
0.03%/ (0 ~ 50 )on +5V output
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
UL60950-1, TUV EN60950-1 Approved
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
PROTECTION
OVER VOLTAGE
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
ENVIRONMENT
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
WITHSTAND VOLTAGE
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
SAFETY & ISOLATION RESISTANCE
EMI CONDUCTION & RADIATION
Compliance to EN55022 (CISPR22) Class B
EMC
(Note 5)
HARMONIC CURRENT
EMS IMMUNITY
MTBF
Compliance to EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,11, ENV50204, EN55024, Light industry level, criteria A
314.3K hrs min. MIL-HDBK-217F (25 )
159*97*38mm (L*W*H)
0.51Kg; 24pcs/13.2Kg/0.75CUFT
OTHERS
DIMENSION
PACKING
NOTE
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. 5% Duty cycle maximum within every 1min. Average output power should not exceed the rated power.
5. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
File Name:IT-60-SPEC 2006-08-01
