8231726A Overview

Trans Voltage Suppressor Diode,

8231726A Parametric

Parameter NameAttribute value
MakerWurth Elektronik
Reach Compliance Codecompliant
Samacsys DescriptionESD Suppressors / TVS Diodes WE-VE femtoF ESD Suppressor 0402; 26Vdc; 0.05pF
Diode typeTRANS VOLTAGE SUPPRESSOR DIODE
Specification for release
Customer
:
Ordercode:
Description :
8231726A
ESD Suppressor WE-VE femtoF
A
Dimensions:
A
B
C
D
Size 0402
1.0 ± 0.2
0.5 ± 0.2
0.6 max
0.3 ± 0.2
mm
mm
mm
mm
@@FRM 1 @@
B
Electrical properties:
Properties
DC operating voltage
capacitance
capacitance
leakage current
trigger voltage
clamping voltage
ESD withstand
1 MHz
1 MHz
12 VDC
TLP measurement
8kV Contact, 30ns
8kV Contact
Test Conditions
Value
Unit
Tol.
max
typ
max
max
typ
typ
min
C
Soldering spec.:
V
DC
C
typ
C
max
I
L max
v
Tr
v
Cl
26
0.05
0.15
0.05
300
50
1000
V
pF
pF
µA
V
V
1.5 - 2.2
0.5
0.6
a [mm]
b [mm]
c [mm]
D
Test equipment:
Keithley 2410
for leakage Current
Agilent 4396B Analyzer
for Capacitance
E
Test conditions:
Humidity:
Temperature:
33%
+20°
C
F
Material & approvals:
Base material:
Ceramic
G
General specifications:
Storage temperature:
Max. operating temperature:
-20° … +60°
C
C
-40° … +85°
C
C
General Release:
Customer
..................................................................................
..................................................................................
Date
Signature
Würth Elektronik
JB
..................................................................................
Version 1
Modification
2010-12-14
..................................................................................
Checked
Approved
Name
Date
This electronic component has been designed and developed for usage in general electronic equipment. Before incorporating this component into any equipment where higher safety and
reliability is especially required or if there is the possibility of direct damage or injury to human body, for example in the range of aerospace, aviation, nuclear control, submarine,
transportation, (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc, Würth Elektronik eiSos GmbH must be
informed before the design-in stage. In addition, sufficient reliability evaluation checks for safety must be performed on every electronic component which is used in electrical circuits that
require high safety and reliability functions or performance.
Würth Elektronik eiSos GmbH & Co. KG
D-74638 Waldenburg · Max-Eyth-Strasse 1 · Germany · Phone (+49) (0) 7942 - 945 - 0 · Fax (+49) (0) 7942 - 945 - 400
http://www.we-online.com
PAGE 1 OF 3
