Ultra High Voltage Resistors
The content of this specification may change without notification 11/12/08
HVP Series -
Up to 5 Gig ohm, 250 Watt and 300 KV DC
Custom solutions are available..
HOW TO ORDER
HVP 100 7507
F B
Buck Packing
Resistance Torrance
F = + 1% J = + 5%
G = + 2% K= + 10%
Resistance
1% = 4 Digits
2%, 5%, 10% = 3 Digits
Rated Power (W)
5
10
100
150
25
200
50
250
FEATURES
•
•
•
•
Low temperature coefficient
Wide range of resistance values
Ultra high stability
Excellent load life
APPLICATIONS
Widely used in electron microscopes, X-ray
apparatuses, electric precipitators, and many other high
voltage equipments.
HVP Series
Power Type High Voltage
CHARACTERISTICS
Item
Operating temperature range
Temperature coefficient
Short-time overload
Load life
Characteristics
-25°C~+125°C
-300~+600ppm/°C
+ 2.5%
+ 5%
The test date is based on a temperature difference of 100 C
(reference temperature, 25 C ; measurement temperature, 125 C
Immersed in oil at 75 C ; rated voltage 2.5applied for 5 sec
Immersed in oil at 75 C ; rated voltage applied for 1,000hr
Test method
ELECTRICAL SPECIFICATIONS
Range of resistance
values
Min.
(MΩ)
0.05
0.05
0.05
0.05
0.05
0.1
0.1
0.1
Max.
(MΩ)
2000
5000
5000
5000
5000
5000
5000
5000
Rated
Power
(W)
5
10
25
50
100
150
200
250
Max.
working
voltage
DC (kV)
30
60
90
120
150
200
250
300
Impulse voltage
(kV)
1.2X50 µ sec
40
80
120
160
200
Dimensions (mm)
L
D
H
10
15
20
20
25
25
32
32
M8
H6
2
M4
1 (F)
2 (G)
5 (J)
10(K)
Center
tap
Resistance
tolerance
(%)
H2
H3
H4
H5
Holder
Type
Type
HVP5
HVP10
HVP25
HVP50
HVP100
HVP150
HVP200
HVP250
100 2 19 0.5
200 2 23 0.5
280 2 30 0.5
370 2 46 0.5
470 2 46 0.5
600 3 46 0.5
800 3 54 0.5
1000 5 54 0.5
Shape
H
L
H
Holder
Type
H2
H3
H4
H5
H6
Dimensions (mm)
R
9
11
D
10
15
L
16
18
24
36
45
H
25
32
39
60
70
h
1
M
t
0.8
1.0
1.0
1.5
1.5
W
1.5 0.5
1.5 0.5
1.5 1
2 1
2 1
15 4.2
21 4.2
26 6.5
38 6.5
47 6.5
Derating Curve
100
80
60
40
20
0
25
50
75
100
Ambient temperature ( C)
125
14.5 18
22.5 20
26.5 25
