SAFETY
RL-2260
ALL IN ONE™ POWER
TRANSFORMERS
DESCRIPTION
• Linear Transformer
UL RECOGNIZED
E132629
FEATURES & APPLICATIONS
•
•
•
•
Meets UL, CSA, VDE and IEC specifications
Low interwinding capacitance and the shrouded design
eliminates the need for electrostatic shielding
For ease of use, they are supplied with mounting brackets
and uick connector solder terminals
q
Hipot tested at 4000 VRMS 60 Hz 2 seconds winding to
winding, windings to core
ENVIRONMENTAL DATA
•
•
Storage temperature range:
-55°C to +130°C
Operating temperature range:
-40°C to +130°C
PACKAGING INFORMATION
• Packaging information: pg. 494
Verify operation with sample in actual circuit. Order samples at www.rencousa.com.
MECHANICAL DIMENSIONS
U.S. Standard (mm)
PART NUMBER VA (SIZE)
RL-2260
RL-2260
RL-2260
80
130
175
A (MAX.)
2.50 (63.50)
2.81 (71.37)
3.20 (81.28)
B (MAX.)
3.00 (76.20)
3.38 (85.85)
3.77 (95.75)
C (MAX.)
2.69 (68.33)
3.05 (77.47)
3.16 (80.26)
D
2.38 (60.45)
2.67 (67.82)
2.67 (67.82)
E (MAX.)
1.38 (35.05)
1.62 (41.15)
1.62 (41.15)
F (MAX.)
0.312 (7.93)
0.375 (9.53)
0.375 (9.53)
G
2.00 (50.80)
2.25 (57.15)
H
2.19 (55.63)
2.50 (63.50)
2.50 (63.50)
I
2.93 (74.42)
3.24 (82.29)
3.24 (82.29)
MOUNTING B
FRONT VIEW
A
2.50 (63.50)
SIDE VIEW
C
D
E
BOTTOM VIEW
12 X 0.19W X
0.03THK
QUICK-
CONNECT
TERMINALS
6
SCHEMATIC
7
1
F
6
5
2
1
12
11
B
8
7
12
11
8
7
7
115V
50/60Hz
5
2
8
11
H I
115V
50/60Hz
1
12
WASHER
G
0.188 (4.78) Mounting Holes
RENCO ELECTRONICS INC.
595 International Place, Rockledge, FL 32955-4200 USA • www.rencousa.com • ISO 9001 Certified
Toll Free Engineering Hot Line: 800.645.5828 • P: 321.637.1000 • F: 321.637.1600
TRANSFORMERS
Primaries and secondaries
are designed to be used
simultaneously. They
must be used either series
or parallel connected
(as one winding).
RL-2260
MOUNTING C
FRONT VIEW
A
SIDE VIEW
C
D
E
BOTTOM VIEW
1
7
SCHEMATIC
12 X 0.19W X
0.03THK
QUICK-
CONNECT
TERMINALS
6
7
F
115V
50/60Hz
5
8
11
6
5
2
1
12
11
8
7
B
12
11
8
7
2
G
115V
50/60Hz
1
12
0.188 (4.78) Mounting Holes
Primaries and secondaries
are designed to be used
simultaneously. They
must be used either series
or parallel connected
(as one winding).
MECHANICAL DIMENSIONS
U.S. Standard (mm)
PART NUMBER
RL-2260
RL-2260
VA
(SIZE)
25
43
A
(MAX.)
B
(MAX.)
C
(MAX.)
D
E
(MAX.)
F
(MAX.)
G
2.85 (72.39) 2.37 (60.20) 2.24 (56.90) 1.93 (49.02) 1.12 (28.45) 0.312 (7.93) 2.38 (60.45)
3.23 (82.04) 2.75 (69.85) 2.37 (60.20) 2.06 (52.32) 1.12 (28.45) 0.312 (7.93) 2.78 (70.61)
PART NUMBER
RL-2260
RL-2260
RL-2260
RL-2260
RL-2260
VA (SIZE)
25
43
80
130
175
STYLE
C
C
B
B
B
MTG. SCREW TERMINALS
0.1875 (4.76)
0.1875 (4.76)
0.1875 (4.76)
0.2500 (6.35)
0.2500 (6.35)
MTG. SCREW
SIZE
LBS (KG)
#6
#6
#6
#8
#8
1.25 (0.57)
1.60 (0.73)
2.80 (1.27)
4.10 (1.86)
5.50 (2.50)
PART NUMBER
RL-2260-25
RL-2260-43
RL-2260-80
RL-2260-130
RL-2260-175
PART WEIGHT
557.0g (19.65oz)
764.0g (26.95oz)
1,230.0g (43.39oz)
1,849.0g (65.22oz)
2,043.0g (72.02oz)
TRANSFORMERS
RENCO ELECTRONICS INC.
595 International Place, Rockledge, FL 32955-4200 USA • www.rencousa.com • ISO 9001 Certified
Toll Free
Engineering Hot Line: 800.645.5828 • P: 321.637.1000 • F: 321.637.1600
RL-2260
Renco Part No.
RL-2260-25-10
RL-2260-43-10
RL-2260-80-10
RL-2260-130-10
RL-2260-175-10
RL-2260-25-12
RL-2260-43-12
RL-2260-80-12
RL-2260-130-12
RL-2260-175-12
RL-2260-25-16
RL-2260-43-16
RL-2260-80-16
RL-2260-130-16
RL-2260-175-16
RL-2260-25-20
RL-2260-43-20
RL-2260-80-20
RL-2260-130-20
RL-2260-175-20
RL-2260-25-24
RL-2260-43-24
RL-2260-80-24
RL-2260-130-24
RL-2260-175-24
RL-2260-25-28
RL-2260-43-28
RL-2260-80-28
RL-2260-130-28
RL-2260-175-28
RL-2260-25-36
RL-2260-43-36
RL-2260-80-36
RL-2260-130-36
RL-2260-175-36
RL-2260-25-230
RL-2260-43-230
RL-2260-80-230
RL-2260-130-230
RL-2260-175-230
VA (Size)
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
Secondary RMS Rating
Series
Parallel
10V C.T. @ 2.50 A
10V C.T. @ 4.30 A
10V C.T. @ 8.00 A
10V C.T. @ 13.00 A
10V C.T. @ 17.50 A
12.6V C.T. @ 2.00 A
12.6V C.T. @ 3.40 A
12.6V C.T. @ 6.30 A
12.6V C.T. @ 10.30 A
12.6V C.T. @ 14.00 A
16V C.T. @ 1.60 A
16V C.T. @ 2.70 A
16V C.T. @ 5.00 A
16V C.T. @ 8.10 A
16V C.T. @ 11.00 A
20V C.T. @ 1.25 A
20V C.T. @ 2.20 A
20V C.T. @ 4.00 A
20V C.T. @ 6.50 A
20V C.T. @ 8.80 A
24V C.T. @ 1.00 A
24V C.T. @ 1.80 A
24V C.T. @ 3.30 A
24V C.T. @ 5.40 A
24V C.T. @ 7.30 A
28V C.T. @ 0.90 A
28V C.T. @ 1.50 A
28V C.T. @ 2.80 A
28V C.T. @ 4.60 A
28V C.T. @ 6.25 A
36V C.T. @ 0.70 A
36V C.T. @ 1.20 A
36V C.T. @ 2.20 A
36V C.T. @ 3.60 A
36V C.T. @ 4.80 A
230V C.T. @ 0.11 A
230V C.T. @ 0.19 A
230V C.T. @ 0.35 A
230V C.T. @ 0.57 A
230V C.T. @ 0.76 A
5V @ 5.00 A
5V @ 8.60 A
5V @ 16.00 A
5V @ 26.00 A
5V @ 35.00 A
6.3V @ 4.00 A
6.3V @ 6.80 A
6.3V @ 12.60 A
6.3V @ 20.60 A
6.3V @ 28.00 A
8V @ 3.20 A
8V @ 5.40 A
8V @ 10.00 A
8V @ 18.20 A
8V @ 22.00 A
10V @ 2.50 A
10V @ 4.40 A
10V @ 8.00 A
10V @ 13.00 A
10V @ 17.60 A
12V @ 2.00 A
12V @ 3.60 A
12V @ 6.60 A
12V @ 10.80 A
12V @ 14.60 A
14V @ 1.86 A
14V @ 3.00 A
14V @ 5.60 A
14V @ 9.20 A
14V @ 12.50 A
18V @ 1.40 A
18V @ 2.40 A
18V @ 4.40 A
18V @ 7.20 A
18V @ 9.60 A
115V @ 0.22 A
115V @ 0.38 A
115V @ 0.70 A
115V @ 1.14 A
115V @ 1.52 A
NOTES:
1. ELECTRICAL SPECIFICATIONS MEASURED AT 25ºC
