SSMB Series
SSMB Type Connectors
●
SSMB series are super mini-size low profile,
push-on type coaxial cable connectors pro
-
duced corresponding to minimization of commu
-
nication equipment, and based on IEC-Pub.169-
19 Standard.
●
When fitted, the height from print base is less
than 6mm(in combination of SP and LR) or less
than 10mm(in combination of LP and SR).
CONFORMING STANDARD
IEC-Pub． 169-19
SPECIFICATION
Characteristic Impedance
Dielectric withstanding voltage
Insulation resistance
Contact resistance
VSWR
50Ω
500V AC (rms) for 1 minute
1000MΩ min. at 250V DC
7.5mΩ max.
1.3max. at DC½2GHz
Specifications depends on each connector although these are basic specifications.
MATERIAL/FINISH
Shell (Body)
Contact (male)
Contact (female)
Insulators
Copper alloy/Nickel plating
Copper alloy/Gold plating
Copper alloy/Gold plating
PTFE
Please ask us for the cable assemblies to assure its performance.
●
●
