Under locked conditions VMON should be > 0.3V and <3.0V. The input frequency may
be out of range if the voltage exceeds these levels
LVCMOS
Output Disable
Disabled = Logic “1”
Enabled = Logic “0” or no connect
Case and Electrical Ground
Frequency Output
Complementary Frequency Output – Note for LVCMOS option this pad will be tied to
GND.
Lock Detect
Locked = Logic “1”
Loss of Signal = Logic “0”
Case and Electrical Ground
Case and Electrical Ground
6
OD
I
7
8
9
10
GND
FOUT
CFOUT
LD
GND
O
O
O
Supply
LCPECL. LVDS or
LVCMOS
LVPECL, LVDS or
LVCMOS
LVCMOS
11
12
GND
GND
GND
GND
Supply
Supply
13
14
*
FIN
VCC
I
VCC
LVCMOS or
LVPECL
Supply
Input Frequency – AC Coupled
Power Supply Voltage (3.3 V ±5%)
For applications requiring two to four input frequencies, Vectron will assign a unique part number and the Input Frequency versus SEL[1:0] settings will be pro-
vided in a Specification Control Drawing. For single input configurations it is recommended that SEL0 and SEL1 are tied to ground.
