ALUMINUM ELECTROLYTIC CAPACITORS
series
LOW LEAKAGE CURRENT TYPE
l
Excellant shelf performance
l
Leakage current is very low after subject to high temperature, no load condition.
l
Units of
φ6.3
or more are furnished with safety case vents.
l
Solvent proof.
■SPECIFICATIONS
Item
Operating Temperature Range
LK
Goback
Performance Characteristics
-40~+85℃
6.3~50V
0.1~3300uF
±20%
(M)【-10~+10%(K) is available at requests】 (at 120Hz , 25℃)
After 2 minutes application of rated voltage, leakage current is not more than 0.002CV
or 0.5 (uA) , whichever is greater.
For capacitance of more than 1000μF, add 0.02 for every increase of 1000μF,
(at 120Hz,:25℃)
Rated voltage (V)
Tan
δ
(MAX)
Rated Voltage(V)
Impedance ratio
Z(-25℃)/Z(+20℃)
ZT/Z20(MAX)
Z(-40℃)/Z(+20℃)
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current (MAX)
(tanδ)
0.26
6.3
0.22
6.3
3
5
10
0.18
10
2
4
16
Stability at Low
Temperature
0.16
0.14
0.12
Measurement frequency: 120Hz
16
25,35,50
2
3
1.5
2
25
35
50
Load Life
The following specifications shall be satisfied when the capacitors are restored
to 20℃ after the rate voltage applied for 2000hours at 85
℃
Leakage Current
Specified value or less
Capacitance
Within ±25% of initial value.
Change
tan ä
150% or less of specified value
After leaving capacitors under no load at 85℃ for 1000 hours and applying voltage according to JIS C-5102
4-3, they meet the specified value for load life characteristics listed above.
Shelf Life
Standard
According to JIS C 5141
■DIMENSIONS
(mm)
CATALOG NUMBERING SYSTEM (Example:10v 100uF)
1 2 3 4 5 6 7 8 9 10 11 12
LK R 1A M 1
0
1 D
1
1
φD
φd
F
α
5
0.5
2.0
6.3
0.5
2.5
8
0.6
3.5
1.5
10
0.6
5.0
12.5
0.6
5.0
16
0.8
7.5
2.0
Case size(φDxL)
Nominal capacitance in uF
Capacitance tolerance
Rated working voltage in volt
Terminal type
Series name
LK-0401
ALUMINUM ELECTROLYTIC CAPACITORS
LK
Cap(μF)
series
LOW LEAKAGE CURRENT TYPE
MAXIMUM RIPPLE CURRENT (mA rms/85℃, 120Hz)
■STANDARD
SIZES AND PERMISSIBLE RIPPLE CURRENT
DxL(mm)
W.V
6.3
0J
10
1A
16
1C
25
1E
35
1V
50
1H
0.1
0.15
0.22
0.33
0.47
0.68
1
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
1000
2200
3300
0R1
R15
R22
R33
R47
R68
010
1R5
2R2
3R3
4R7
6R8
100
150
220
330
470
680
101
151
221
331
471
102
222
332
5x11
5x11
6.3x11
6.3x11
6.3x11
8x11.5
10x12.5
12.5x20
12.5x25
150
180
250
310
400
490
650
1060
1270
5x11
5x11
5x11
6.3x11
6.3x11
8x11.5
8x11.5
10x16
12.5x20
12.5x25
110
160
210
280
330
440
530
810
1200
1420
5x11
5x11
5x11
5x11
5x11
5x11
6.3x11
8x11.5
8x11.5
8x11.5
10x12.5
10x16
12.5x20
16x25
55
70
85
100
140
180
250
310
370
420
550
910
1300
1550
5x11
5x11
5x11
5x11
5x11
5x11
5x11
5x11
6.3x11
8x11.5
8x11.5
10x12.5
10x16
12.5x20
45
55
70
85
100
140
170
230
280
370
400
490
660
1010
5x11
5x11
5x11
6.3x11
6.3x11
8x11.5
10x12.5
10x12.5
10x16
10x20
85
105
145
190
235
300
400
440
550
840
5x11
5x11
5x11
5x11
5x11
5x11
5x11
5x11
5x11
5x11
5x11
5x11
5x11
5x11
5x11
6.3x11
6.3x11
6.3x11
8x11.5
10x16
10x16
12.5x20
12.5x20
1.1
1.6
2.3
3.5
5.0
7.3
10.7
16
23
40
45
55
70
95
110
165
190
250
320
420
490
600
960
■MULTIPLIER
FOR RIPPLE CURRENT
Frequency coefficient
60(50)
0.1~47
0.80
6.3~50 100~470 0.80
1000~3300 0.80
Cap(Uf)
Temperature coefficient
300
1.35
1.23
1.10
1K
1.57
1.34
1.13
10K~
2.00
1.50
1.15
Temperature
Coefficient
45℃
1.48
60℃
1.41
70℃
1.30
85℃
1.00
W.V.
FREQUENCY
(Hz)
120
1.00
1.00
1.00
