Shanghai Lunsure Electronic
Technology Co.,Ltd
Tel:0086-21-37185008
Fax:0086-21-57152769
1F10
THRU
1F18
0.5 Amp Fast
Recovery Rectifier
1000 to 1800 Volts
R-1
•
•
•
•
•
Features
High Current Capability
Low Leakage
Fast Switching for High Efficiency
Low Forward Voltage Drop
High Reliability
Maximum Ratings
•
•
•
Operating Temperature: -55°C to +125°C
Storage Temperature: -55°C to +150°C
For capacitive load. Derate current by 20%
Maximum
Recurrent
Peak Reverse
Voltage
1000V
1200V
1400V
1500V
1600V
1800V
Maximum DC
Blocking
Voltage
1000V
1200V
1400V
1500V
1600V
1800V
Part Number
1F10
1F12
1F14
1F15
1F16
1F18
Maximum
RMS
Voltage
700V
840V
980V
1050V
1120V
1260V
D
A
Cathode Mark
B
Electrical Characteristics @ 25°C Unless Otherwise Specified
Average Forward
Rectified Current
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Typical Junction
Capacitance
Maximum Reverse
Recovery Time
I
O
I
FSM
V
F
0.5A
25A
1.8V
T
A
= 25°C
8.3ms, half sine
I
FM
= 0.5A;
T
C
= 25°C
C
D
I
R
5.0µA
T
C
= 25°C
DIM
DIMENSIONS
INCHES
MM
NOTE
MIN
A
B
C
D
0.116
0.091
0.020
0.787
MAX
0.140
0.102
0.024
-----
MIN
2.90
2.30
0.50
20.00
MAX
3.50
2.60
0.60
-----
C
J
t
rr
15pF
300ns
Measured at
1.0MHz, V
R
=4.0V
I
F
=0.5A,
I
R
=1A,
I
rr
=0.25A
www.cnelectr.com
