MWD Series Micro-D Plastic Shell
Solder Cup
MWD Plastic
– These connectors feature gold plated
TwistPin contacts and mil spec crimp termination. High
temperature liquid crystal polymer (LCP) housings are
30% glass-filled.
Solder Cup Contacts
– Choose standard size contacts
for #26 gage, or select oversize contacts for #24 AWG
solid or stranded wire.
MWD Low-Profile Plastic Micro-D’s
do not have an
interfacial seal, and are smaller and lighter weight than
metal shell versions.
HOW TO ORDER MWD PLASTIC SHELL PRE-WIRED MICRO-D CONNECTORS
Series
MWDL
Contact Layout
9
15
21
25
31
37
51
Contact Type
Size #26 Solder Cup
Contacts (Standard)
P
– Pin
S
– Socket
Size #24 Solder Cup
Contacts
N
– Pin
Termination
S
–
Solder Cup
Hardware
B
P
M
M1
S
S1
T
– Socket
Sample Part Number
MWDL
– 25
S
S
B
MICRO-D MOUNTING HARDWARE
B
P
M
M1
S
S1
Thru-Hole
Order Hardware
Separately
Jackpost
Removable
Includes Nut and
Washer
Jackscrew
Hex Head
Removable
E-ring
Jackscrew
Hex Head
Removable
E-ring
Extended
Jackscrew
Slot Head
Removable
E-ring
Jackscrew
Slot Head
Removable
E-ring
Extended
© 2006 Glenair, Inc.
CAGE Code 06324/0CA77
Printed in U.S.A.
GLENAIR, INC.
www.glenair.com
• 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
K-2
E-Mail: sales@glenair.com
MWD Series Micro-D Plastic Shell
Solder Cup
PERFORMANCE SPECIFICATIONS
Current Rating
DWV
Insulation Resistance
Contact Resistance
Operating Temperature
Shock, Vibration
Mating Force
3 AMP
600 VAC Sea level
5000 Megohms Minimum
8 Milliohms Maximum
-55° C. to +150° C.
50 g., 20g.
(10 Ounces) X (# of Contacts)
MATERIALS AND FINISHES
Connector Shell
Insulator
Interfacial Seal
Pin Contact
Socket Contact
Hardware
Encapsulant
Liquid Crystal Polymer (LCP)
Liquid Crystal Polymer (LCP)
Flourosilicone Rubber, Blue
Beryllium Copper Gold over Nickel Plating
Copper Alloy Gold Over Nickel Plating
300 Series Stainless Steel
Epoxy Resin Hysol EE4215
A
B
C
D
D
.110 (2.79)
MAX
H
.200 (5.08)
MAX
J
PIN CONNECTOR
.096/.088 (2.43/2.23) DIA.
SOCKET CONNECTOR
E
F
.100/.088
(2.54/2.24)
G
DIMENSIONS
A Max.
In .
Layout
9P
9S
15P
15S
21P
21S
25P
25S
31P
31S
37P
37S
51P
51S
In.
.785
.785
.935
.935
1.080
1.080
1.185
1.185
1.335
1.335
1.485
1.485
1.435
1.435
B
mm.
± 0.08
14.35
14.35
18.16
18.16
21.97
21.97
24.51
24.51
28.32
28.32
32.13
32.13
30.86
30.86
± .003
.565
.565
.715
.715
.865
.865
.965
.965
1.115
1.115
1.265
1.265
1.215
1.215
C Max.
In.
.292
.380
.442
.530
.592
.680
.692
.780
.842
.930
.992
1.080
.942
1.030
D Max.
In.
.218
.218
.218
.218
.218
.218
.218
.218
.218
.218
.218
.218
.260
.260
E Max.
In.
.202
.185
.202
.185
.202
.185
.202
.185
.202
.185
.202
.185
.202
.185
F Max.
In.
.395
.375
.395
.375
.395
.375
.395
.375
.395
.375
.395
.375
.395
.375
G Max.
In.
.408
.408
.558
.558
.708
.708
.808
.808
.958
.958
1.108
1.108
1.058
1.058
H Max.
In.
.173
.173
.173
.173
.173
.173
.173
.173
.173
.173
.173
.173
.220
.220
J Max.
In.
.139
.139
.139
.139
.139
.139
.182
K
mm.
19.94
19.94
23.75
23.75
27.43
27.43
30.01
30.01
33.91
33.91
37.72
37.72
36.45
36.45
mm.
7.42
9.65
11.23
13.46
15.04
17.27
17.58
19.81
21.39
23.62
25.20
27.43
23.93
26.16
mm.
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
6.60
6.60
mm.
5.13
4.70
5.13
4.70
5.13
4.70
5.13
4.70
5.13
4.70
5.13
4.70
5.13
4.70
mm.
10.03
9.53
10.03
9.53
10.03
9.53
10.03
9.53
10.03
9.53
10.03
9.53
10.03
9.53
mm.
10.36
10.36
14.17
14.17
17.98
17.98
20.52
20.52
24.33
24.33
28.14
28.14
26.87
26.87
mm.
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
5.59
5.59
mm.
3.53
3.53
3.53
3.53
3.53
3.53
4.62
© 2006 Glenair, Inc.
CAGE Code 06324/0CA77
Printed in U.S.A.
GLENAIR, INC.
www.glenair.com
• 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
K-3
E-Mail: sales@glenair.com
