ChipInductors 0603CSSeries(1608)
Ultra-small size, exceptional Q and high SRFs make
these inductors ideal for high frequency applications
where size is at a premium. They also have excellent
DCR and current carrying characteristics.
Part Number
0603CS-1N6X _ B _
0603CS-1N8X _ B _
0603CS-3N6X _ B _
0603CS-3N9X _ B _
0603CS-4N3X _ B _
0603CS-4N7X _ B _
0603CS-5N1X _ B _
0603CS-6N8X _ B _
0603CS-7N5X _ B _
0603CS-8N7X _ B _
0603CS-9N5X _ B _
0603CS-10NX _ B _
0603CS-11NX _ B _
0603CS-12NX _ B _
0603CS-15NX _ B _
0603CS-16NX _ B _
0603CS-18NX _ B _
0603CS-22NX _ B _
0603CS-24NX _ B _
0603CS-27NX _ B _
0603CS-30NX _ B _
0603CS-33NX _ B _
0603CS-36NX _ B _
0603CS-39NX _ B _
0603CS-43NX _ B _
0603CS-47NX _ B _
0603CS-56NX _ B _
0603CS-68NX _ B _
0603CS-72NX _ B _
0603CS-82NX _ B _
0603CS-R10X _ B _
0603CS-R11X _ B _
0603CS-R12X _ B _
0603CS-R15X _ B _
0603CS-R18X _ B _
0603CS-R20X _ B _
0603CS-R21X _ B _
0603CS-R22X _ B _
0603CS-R25X _ B _
0603CS-R27X _ B _
0603CS-R33X _ B _
0603CS-R39X _ B _
1
Coilcraft
Designer’s Kit C124
contains samples of
all 5% tolerance parts. A kit with 2% tolerance is
also available. To order, contact Coilcraft or visit
http://order.coilcraft.com
to order on-line.
DCR
Max
6
(Ohms)
.030
.045
.063
.080
.063
.116
.140
.110
.106
.109
.135
.130
.086
.130
.170
.104
.170
.190
.135
.220
.144
.220
.250
.250
.280
.280
.310
.340
.490
.540
.580
.610
.650
.920
1.25
1.98
2.06
2.10
3.55
2.30
3.89
4.35
I
DC
Max
7
900 Mhz
1.7 Ghz
(mA)
L Typ Q Typ L Typ Q Typ
700
1.67
49
1.65
63
700
1.63
35
1.66
50
700
3.72
53
3.71
65
700
3.95
49
3.96
67
700
4.32
50
4.33
70
700
4.72
47
4.75
57
700
4.93
47
4.95
56
700
6.75
60
7.10
81
700
7.70
60
7.82
65
700
8.86
62
9.32
58
700
9.7
59
9.92
61
700
10.0
66
10.6
83
700
11.0
53
11.5
56
700
12.3
72
13.5
83
700
15.4
64
16.8
89
700
16.2
55
17.3
52
700
18.7
70
21.4
69
700
22.8
73
26.1
71
700
24.5
45
28.7
39
600
29.2
74
34.6
65
600
31.4
47
39.9
28
600
36.0
67
49.5
42
600
39.4
47
52.7
24
600
42.7
60
60.2
40
600
47.0
44
64.9
21
600
52.2
62
77.2
35
600
62.5
56
97.0
26
600
80.5
54 168
21
400
82.0
53 135
20
400
96.2
54 177
21
400
124
49
—
—
300
138
43
—
—
300
166
39
—
—
280
250
25
—
—
240
305
22
—
—
200
—
—
—
—
200
—
—
—
—
200
480
8
—
—
120
—
—
—
—
170
980
4
—
—
100 1800
3
—
—
100 2600
3
—
—
Color
Code
Red
Black
Red
Brown
Orange
Violet
Green
Red
Brown
Yellow
Blue
Orange
Gray
Yellow
Green
White
Blue
Violet
Black
Gray
Brown
White
Red
Black
Orange
Brown
Red
Orange
Yellow
Green
Blue
Violet
Gray
White
Black
Green
Gray
Brown
Violet
Red
Blue
Yellow
Inductance
2
Percent
(nH)
Tolerance
3
1.6 @ 250 MHz
10,5
1.8 @ 250 MHz
10,5
3.6 @ 250 MHz
10,5,2
3.9 @ 250 MHz
10,5,2
4.3 @ 250 MHz
10,5,2
4.7 @ 250 MHz
10,5,2
5.1 @ 250 MHz
10,5,2
6.8 @ 250 MHz
10,5,2
7.5 @ 250 MHz
10,5,2
8.7 @ 250 MHz
5,2
9.5 @ 250 MHz
5,2
10 @ 250 MHz
5,2
11 @ 250 MHz
5,2
12 @ 250 MHz
5,2
15 @ 250 MHz
5,2
16 @ 250 MHz
5,2
18 @ 250 MHz
5,2
22 @ 250 MHz
5,2
24 @ 250 MHz
5,2
27 @ 250 MHz
5,2
30 @ 250 MHz
5,2
33 @ 250 MHz
5,2
36 @ 250 MHz
5,2
39 @ 250 MHz
5,2
43 @ 250 MHz
5,2
47 @ 200 MHz
5,2
56 @ 200 MHz
5,2
68 @ 200 MHz
5,2
72 @150 MHz
5,2
82 @ 150 MHz
5,2
100 @ 150 MHz
5,2
110 @ 150 MHz
5,2
120 @ 150 MHz
5,2
150 @ 150 MHz
5,2
180 @ 100 MHz
5,2
200 @ 100 MHz
10,5
210 @ 100 MHz
10,5
220 @ 100 MHz
5,2
250 @ 100 MHz
10,5
270 @ 100 MHz
5,2
330 @ 100 MHz
5
390 @ 100 MHz
5
Q
Min
4
24
16
22
22
22
20
20
27
28
28
28
31
33
35
35
34
35
38
37
40
37
40
38
40
39
38
38
37
34
34
34
32
32
28
25
25
27
25
25
24
25
25
SRF
Min
5
(MHz)
12500
12500
5900
6900
5900
5800
5700
5800
4800
4600
5400
4800
4000
4000
4000
3300
3100
3000
2650
2800
2250
2300
2080
2200
2000
2000
1900
1700
1700
1700
1400
1350
1300
990
990
900
895
900
822
900
900
900
1. When ordering, please specify tolerance and packaging codes:
Inductance tolerance code:
Table above shows stock tolerances in bold.
G=
±2%,
J=
±5%,
K=
±10%
0603CS-R27X_B_
Packaging code:
W
=
7″ machine-ready reel
EIA RS-481 punched
paper tape. 2000 per reel.
U
=
Less than full reel
Not machine-ready. The
carrier tape may not be a single continuous
length. To have a leader and trailer added ($25
charge), use code letter W instead.
2. Inductance measured using Coilcraft SMD-A fixture in Agilent/HP4286
impedance analyzer with Coilcraft-provided correlation pieces. For
recommended test procedures, contact Coilcraft.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured using Agilent/HP4291A with Agilent/HP16193 test fixture and
on Agilent/HP8753D with Coilcraft SMD-D test fixture.
5. SRF measured using Agilent/HP8720D network analyzer and Coilcraft
SMD-D test fixture.
6. DCR measured on Cambridge Technology micro-ohmmeter and Coilcraft
CCF858 test fixture.
7. For 15° C rise.
8. Operating temperature range
−40°
C to +125° C.
9. Electrical specifications at 25° C.
For environmental data see Product Specifications section.
Specifications subject to change without notice. Document 195-1 Revised 4/23/02
Document 195-2
0603CS Series (1608)
TYPICAL Q vs FREQUENCY
100
12 nH
80
33 nH
22 nH
68 nH
60
Q
40
120 nH
3.9 nH
20
0
1
10
100
1000
10000
Frequency (MHz)
L vs FREQUENCY
200
175
Inductance (nH)
120 nH
150
125
100
75
50
25
0
1
10
100
1000
22 nH
12 nH
3.9 nH
33 nH
68 nH
A
B
C
D
E
F
G
H
I
J
Max. Max. Max. Ref.
.071 .044 .040 .015 .030 .013 .034 .040 .025 .025
1,80 1,12 1,02 0,38 0,76 0,33 0,86 1,02 0,64 0,64
Parts/reel: 7″ 2,000 Tape width: 8 mm
For packaging data see Tape and Reel Specifications section.
10000
Frequency (MHz)
Specifications subject to change without notice. Document 195-2 Revised 4/22/02
