Document 433-1
Shielded Power Inductors – LPS4012
• Very low DCR; excellent current handling
• 4.0 × 4.0 mm footprint; less than 1.2 mm tall
Core material
Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Environmental
RoHS compliant, halogen free
Terminations
RoHS compliant matte tin over nickel over silver.
Other terminations available at additional cost.
Weight
54 – 64 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
1000/7″ reel; 3500/13″ reel Plastic tape: 12 mm wide,
0.25 mm thick, 8 mm pocket spacing, 1.32 mm pocket depth
Recommended pick and place nozzle
OD: 4 mm; ID:
≤
2 mm
PCB washing
Tested with pure water or alcohol only. For other solvents,
see
Doc787_PCB_Washing.pdf.
Part number
1
Isat
(A)
5
DCR
SRF
Inductance
2
max
3
typ
4
10% 20% 30%
(µH)
(Ohms) (MHz) drop drop drop
375
220
180
140
115
100
70
60
55
40
30
25
22
19
15
12
11.5
10.0
8.0
7.0
7.0
4.0
3.5
3.0
3.0
3.0
2.5
2.0
1.0
5.2
3.5
2.8
2.6
2.3
1.3
1.6
1.5
1.3
0.98
0.79
0.74
0.45
0.35
0.30
0.24
0.23
0.21
0.18
0.15
0.14
0.10
0.10
0.10
0.090
0.080
0.080
0.079
0.079
5.4
3.6
2.9
2.7
2.4
1.4
1.7
1.6
1.3
1.0
0.82
0.78
0.47
0.37
0.32
0.26
0.24
0.22
0.19
0.16
0.14
0.11
0.105
0.105
0.095
0.090
0.090
0.085
0.083
5.5
3.7
3.0
2.8
2.5
1.4
1.8
1.6
1.4
1.1
0.84
0.79
0.48
0.38
0.33
0.27
0.25
0.23
0.20
0.17
0.15
0.12
0.115
0.110
0.095
0.095
0.090
0.087
0.085
Irms
(A)
6
20°C 40°C
rise rise
2.2
1.8
1.7
1.6
1.2
1.45
1.10
0.85
0.80
0.55
0.53
0.52
0.46
0.40
0.35
0.30
0.27
0.25
0.23
0.21
0.17
0.13
0.11
0.11
0.105
0.100
0.087
0.075
0.070
3.0
2.4
2.4
2.2
1.75
2.00
1.45
1.10
0.98
0.75
0.73
0.70
0.61
0.52
0.46
0.40
0.36
0.32
0.29
0.27
0.225
0.175
0.140
0.135
0.132
0.130
0.115
0.100
0.090
1. Please specify
termination
and
packaging
codes:
LPS4012-682MRC
Termination: R
= RoHS compliant matte tin over
nickel over silver.
Special order, added cost:
Q
= RoHS tin-silver-copper (95.5/4/0.5)
or
P
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481
embossed plastic tape (1000 parts
per full reel).
B
= Less than full reel. In tape, but not
machine ready.
To have a leader and trailer added
($25 charge), use code letter C
instead.
D
= 13″ machine-ready reel. EIA-481
embossed plastic tape. Factory
order only, not stocked (3500 parts
per full reel).
2. Inductance tested at 100 kHz, 0.1 Vrms using an
Agilent/HP 4192A. Inductance at 1 MHz is the same for
parts with SRF
≥10
MHz.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using Agilent/HP 8753ES or equivalent.
5. DC current that causes the specified inductance drop
from its value without current.
6. Current that causes the specified temperature rise
from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering.
LPS4012-331MR_
0.33 ±20% 0.025
LPS4012-681MR_
0.68 ±20% 0.055
LPS4012-102NR_
1.0 ±30% 0.060
LPS4012-152MR_
1.5 ±20% 0.070
LPS4012-222MR_
2.2 ±20% 0.100
LPS4012-332MR_
3.3 ±20% 0.100
LPS4012-472MR_
4.7 ±20% 0.175
LPS4012-562MR_
5.6 ±20% 0.260
LPS4012-682MR_
6.8 ±20% 0.340
LPS4012-103MR_ 10 ±20%
0.350
LPS4012-153MR_ 15 ±20%
0.550
LPS4012-223MR_ 22 ±20%
0.600
LPS4012-333MR_ 33 ±20%
0.825
LPS4012-473MR_ 47 ±20%
1.40
LPS4012-683MR_ 68 ±20%
1.70
LPS4012-104MR_ 100 ±20%
2.40
LPS4012-124MR_ 120 ±20%
3.30
LPS4012-154MR_ 150 ±20%
3.50
LPS4012-184MR_ 180 ±20%
5.00
LPS4012-224MR_ 220 ±20%
5.20
LPS4012-334MR_ 330 ±20%
7.20
LPS4012-474MR_ 470 ±20% 10.0
LPS4012-564MR_ 560 ±20% 12.5
LPS4012-684MR_ 680 ±20% 13.5
LPS4012-824MR_ 820 ±20% 20.0
LPS4012-105MR_ 1000 ±20% 21.5
LPS4012-155MR_ 1500 ±20% 30.0
LPS4012-185MR_ 1800 ±20% 35.0
LPS4012-225MR_ 2200 ±20% 42.0
Coilcraft
Designer’s Kit C392
contains samples
of 0.80 µH to 33 µH parts (3 each) from LPS3008,
LPS3010 and LPS3015.
Kit C401
contains samples
of 0.56 µH to 33 µH parts (3 each) from LPS4012
and LPS4018.
Kit C402
contains samples of 220 µH
to 3300 µH parts (3 each) from all five series. For
details of kit contents and to order, contact Coilcraft
or visit
http://order.coilcraft.com.
Document 433-1
Revised 08/01/13
© Coilcraft Inc. 2014
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 433-2
Shielded SMT Power Inductors – LPS4012 Series
Typical L vs Frequency
10000
2200 µH
1000 µH
220 µH
Typical L vs Current
10000
2200 µH
1000 µH
220 µH
1000
1000
Inductance (µH)
100
100 µH
22 µH
Inductance (µH)
100
100 µH
22 µH
10
10 µH
5.6 µH
10
10 µH
5.6 µH
2.2 µH
1 µH
1
2.2 µH
1 µH
1
0.1
0.01
0.1
Frequency (MHz)
1
10
0.1
0.01
0.1
Current (A)
1
10
Current Derating
120
110
100
0.1535 ±0.003
*
3,90 ±0,076
Percent of rated current
90
80
70
60
50
40
20
10
0
30
Isat
Irms
-40
-20
0
20
XXX X
Dash
number
Internal
code
0.1535 ±0.003
*
3,90 ±0,076
Winding
direction
Recommended
Land Pattern
0.0433 ±0.004
*
1,10 ±0,10
0.105
2,66
0.059
1,50
0.0305
0,775
25°C
40
60
80
100
120 140
Ambient temperature (°C)
0.060
1,52
0.110 0.045
2,79 1,15
0.153
3,89
0.129
3,28
0.173
4,40
Packaging
1000/7″ reel; 3500/13″ reel Plastic tape: 12 mm wide,
0.25 mm thick, 8 mm pocket spacing, 1.32 mm pocket depth
NOTE NEW PART ORIENTATION
Parts are rotated 90
°
in the
packaging tape compared to previous versions of this product.
NEW
OLD
of
including
*
Dimensions are Forthe case notoverall
the termination.
maximum
dimensions including the termination, add
0.005 in / 0,13 mm.
For optional tin-lead and tin-silver-copper
terminations, dimensions are for the
mounted part. Dimensions before mounting
can be an additional 0.005 inch / 0,13 mm).
Dimensions are in
123
123
123
123
123
123
inches
mm
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 433-2
Revised 08/01/13
© Coilcraft Inc. 2014
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
