6
5
25.5 REF.
4
3
2
1
D
Screw
Cover Gasket
15
M28 x 1.5 Thread
Receptacle Housing
M28 Thread Screw Type
Panel Gasket
Panel Nut (M28 x 1.5)
Ball Chain
Shielded or
Unshielded Cat. 5e
RJ45 Inline Coupler
n
32
D
32.71 REF.
Protective Cover
M28 Thread Screw Type
HEX 32 Metal Version
C
3.5
2.0
C
n
34
26.50
`
0.05
Notes:
1. Electrical Specifications:
- Meets EIA/TIA-568-B.2 Cat.5e Specification
- Contact Resistance: 20mOhm max.
- Insulation Resistance: 500MOhm min. @ 100 VDC
- Current Rating: 1.2A max. at 25
~
C
- Working Voltage: 100 VDC
- DWV: 1000 VDC/60s Contact to Contact, 1500 VDC/60s Contact to Metal Shell
- Operating Temperature: -40
~
C to +85
~
C
2. Material and Finish:
d
- Receptacle Housing, Zinc Die-Cast, Nickel Plated
- Metal HEX Cover, Panel Nut: Brass, Nickel Plated
- Ball Chain: Copper Alloy, Nickel Plated
- Panel Gasket: Silicon, Color: White
b
- Cover Gasket: Silicon, Color: White
- RJ45 Jack Metal Shell: Copper Alloy, Nickel Plated
- RJ45 Jack Plastic Housing: Glass filled PBT UL94 V-0, Color: Black
- RJ45 Jack Contacts: Phosphor Bronze, Finish: 50u" Gold min. over Nickel
3. Connector can be front or rear mounted to a maximum panel thickness of 3.2mm.
4. IP67 rated when fully mated with appropriate mating connector
Directive 2002/95/EC RoHS Compliant
3.0
n
28.00
`
0.05
19.4
32.5
34.50
c
B
32
Recommended Panel Cutout
c
B
Description
Part Number
17-101884
17-101894
Metal
Version Receptacle + HEX 32 Cover with Shielded RJ45 Inline Coupler
Metal Version Receptacle + HEX 32 Cover with Unshielded RJ45 Inline Coupler
THIS DRAWING MAY NOT BE COPIED OR REPRODUCED
IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD
PARTY WITHOUT WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC CORPORATION
DOT NOT ALTER CAD DRAWING BY HAND
Customer:
Approval Date
Unless otherwise specified
Tolerance
Name
Title
0 PLC
1 PLC
2 PLC
3 PLC
ANGLES
`
0.50
`
0.38
`
0.25
`
0.10
`
3
~
Scale: 1.2:1
Autodesk
Inventor
Name
Vincent Ke
J. Chaudry
Dim. in mm
Material: See Notes
Title:
2010
Draw.
Appd.
Date
Feb. 24
Feb. 24
Receptacle + HEX 32 Cover
Assembly Kit with Cat. 5e
RJ45 Inline Coupler (Metal Version)
A
A
DIN
d
c
b
a
Rev.
1
Jan/12/2012 Vincent Ke
Norm
2
Mar/08/2011 Vincent ke
D-old
Sep/28/2010 Vincent Ke
1
original
Changes
Date
Name
R
Drawing No.: 17K1A162
Part No.: SEE P/N TABLE
A3
Sheet
1/1
6
5
4
3
2
1
