Technical specification:
27
Rated voltage:
IEC 61076-2-101
Current rating:
IEC 61076-2-101
5pos
60 V
4 A at 40°
C
Ø14,5
A
Insulation resistance:
IEC 60512
Pollution degree:
IEC 60664-1
>=100 M
3/2
IP 67, in mated
condition
-30° ... +80°C
C
>=100
28
Width across
flats 13
D
Degree of protection:
IEC 60529
Temperature range:
IEC 60664-1
L
Mating cycles:
IEC 60512-9a
Width across
flats 13
M12x1
28
Materials:
Contact:
Contact plating:
Contact carrier:
CuZn
Nickel, gold plated
TPU GF, UL 94
FPM
GD-Zn, nickel plated
TPU, UL 94, grey
Ø14,5
B
Sealing:
Coupling nut/
screw:
Moulding body:
32
Installation specification:
Recommended
torque:
0,6 Nm
Torque wrench:
36-000200
Insert across flats 13:
36-000220
A
1
2
1
B
4
Conec
installation tool:
3
4
5
2
3
5
Contact assignment:
1
2
3
4
5
brown
white
blue
black
green-yellow
Part no:
43-14677
43-14678
43-14679
43-14680
Description:
SAL - 12 - RKW5 - RSW5 - 0,3 / A1 / A1090
SAL - 12 - RKW5 - RSW5 - 0,6 / A1 / A1090
SAL - 12 - RKW5 - RSW5 - 1,5 / A1 / A1090
SAL - 12 - RKW5 - RSW5 - 3,0 / A1 / A1090
SAL - 12 - RKW5 - RSW5 - ... / A1 / A1090
dim. in mm
Length L: Cable:
0,3m
0,6m
1,5m
3m
x
PVC,
grey, 5x0,34mm²
Cable: 781-A13500
D see data sheet cable
DO NOT ALTER CAD DRAWING BY HAND
43-xxxxx
Directive 2002/95/EC RoHS compliant
title:
date
name
tolerance of cable:
L <= 4m: L + 40mm
L > 4m: L + 1%
drawn
19.01.11
appd.
Franz
Mankopf
R
Connecting cable M12x1, female
connector angled - male connector
angled
43K1A1296
19.01.11
dwg no:
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
part no:
see table
