1719-20

Description
RF Power Bipolar Transistor, 1-Element, L Band, Silicon, NPN, HERMETIC SEALED, 55AW, 2 PIN
CategoryDiscrete semiconductor    The transistor
File Size182KB,2 Pages
ManufacturerADPOW
Websitehttp://www.advancedpower.com/
Download Datasheet Parametric View All

1719-20 Overview

RF Power Bipolar Transistor, 1-Element, L Band, Silicon, NPN, HERMETIC SEALED, 55AW, 2 PIN

1719-20 Parametric

Parameter NameAttribute value
MakerADPOW
package instructionFLANGE MOUNT, R-CDFM-F2
Reach Compliance Codeunknown
Other featuresHIGH RELIABILITY
Maximum collector current (IC)6 A
ConfigurationSINGLE
highest frequency bandL BAND
JESD-30 codeR-CDFM-F2
Number of components1
Number of terminals2
Package body materialCERAMIC, METAL-SEALED COFIRED
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Polarity/channel typeNPN
Certification statusNot Qualified
surface mountYES
Terminal formFLAT
Terminal locationDUAL
transistor applicationsAMPLIFIER
Transistor component materialsSILICON
1719 - 20
20 Watt - 28 Volts, Class C
Microwave 1700 - 1900 MHz
GENERAL DESCRIPTION
The 1719-20 is a COMMON BASE transistor capable of providing 20 Watts
of Class C, RF output power over the band 1700-1900 MHz. This transistor is
designed for Microwave Broadband Class C amplifier applications. It includes
Input and Output prematching and utilizes Gold metalization and diffused
ballasting to provide high reliability and supreme ruggedness. The transistor
uses a fully hermetic High Temperature Solder sealed package.
CASE OUTLINE
55AW, STYLE 1
ABSOLUTE MAXIMUM RATINGS
Maximum Power Dissipation @ 25
o
C
Maximum Voltage and Current
BVces
Collector to Emitter Voltage
BVebo
Emitter to Base Voltage
Ic
Collector Current
Maximum Temperatures
Storage Temperature
Operating Junction Temperature
67 Watts
50 Volts
3.5 Volts
6.0 A
- 65 to + 200
o
C
+ 200
o
C
ELECTRICAL CHARACTERISTICS @ 25
O
C
SYMBOL
Pout
Pin
Pg
CHARACTERISTICS
Power Out
Power Input
Power Gain
Collector Efficiency
Load Mismatch Tolerance
TEST CONDITIONS
F = 1900 MHz
Vcb = 28 Volts
Pin = 5.0 Watts
As Above
F = 1.7 GHz, Pin = 5.0
MIN
20
5.0
6.0
6.5
38
4:1
TYP
MAX
UNITS
Watt
Watt
dB
%
η
c
VSWR
1
BVces
BVebo
Icbo
h
FE
Cob
θ
jc
Collector to Emitter Breakdown
Emitter to Base Breakdown
Collector to Base Current
Current Gain
Output Capacitance *
Thermal Resistance
Ic = 10 mA
Ie = 10 mA
Vcb = 28 Volts
50
3.5
4.0
20
2.6
Volts
Volts
mA
o
Vce = 5 V, Ic = 1.2 A
F =1 MHz, Vcb = 28 V
pF
C/W
* Not measureable due to Output Match
Issue August 1996
GHz TECHNOLOGY INC. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. GHz RECOMMENDS THAT
BEFORE THE PRODUCT(S) DESCRIBED HEREIN ARE WRITTEN INTO SPECIFICATIONS, OR USED IN CRITICAL APPLICATIONS,
THAT THE PERFORMANCE CHARACTERISTICS BE VERIFIED BY CONTACTING THE FACTORY.
GHz Technology Inc. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 / 986-8120
