1N4102 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N4102

1N4102: DescriptionZener Diode, 8.7V V(Z), 5%,; CategoryDiscrete semiconductor diode; File Size38KB，1 Pages; ManufacturerCobham PLC

Download Datasheet Parametric Compare View All

1N4102 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N4102	-	-	View	Buy Now

1N4102 Overview

Zener Diode, 8.7V V(Z), 5%,

1N4102 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Cobham PLC
package instruction	O-LALF-W2
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	LOW NOISE
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	200 Ω
JEDEC-95 code	DO-7
JESD-30 code	O-LALF-W2
JESD-609 code	e0
Number of components	1
Number of terminals	2
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Certification status	Not Qualified
Nominal reference voltage	8.7 V
Maximum reverse current	0.5 µA
surface mount	NO
technology	ZENER
Terminal surface	TIN LEAD
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	5%
Working test current	0.25 mA

Preview

Download Datasheet

View All

LOW LEVEL ZENER DIODES

LOW CURRENT: 250µA - LOW NOISE

1N4099-1N4121 ** 1N4614-1N4627

PART

NUMBER

1N4099

1N4100

1N4101

1N4102

1N4103

1N4104

1N4105

1N4106

1N4107

1N4108

1N4109

1N4110

1N4111

1N4112

1N4113

1N4114

1N4115

1N4116

1N4117

1N4118

1N4119

1N4120

1N4121

1N4614

1N4615

1N4616

1N4617

1N4618

1N4619

1N4620

1N4621

1N4622

1N4623

1N4624

1N4625

1N4626

1N4627

NOM ZENER

VOLTAGE

Vz @ 250 µA

(VOLTS)

6.8

7.5

8.2

8.7

9.1

10.0

11.0

12.0

13.0

14.0

15.0

16.0

17.0

18.0

19.0

20.0

22.0

24.0

25.0

27.0

28.0

30.0

33.0

1.8

2.0

2.2

2.4

2.7

3.0

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

MAX ZENER

IMPEDANCE

Zzt @ 250 µA

(OHMS)

200

100

150

200

1200

1250

1300

1400

1500

1600

1650

1700

1650

1600

1550

1500

1400

1200

MAX REVERSE

LEAKAGE CURRENT

(µAdc)

(Vdc)

10.0

1.0

0.05

0.01

7.5

5.0

4.0

2.0

1.0

0.8

7.5

5.0

4.0

10.0

5.17

5.70

6.24

6.61

6.92

7.60

8.44

9.12

9.87

10.65

11.40

12.15

12.92

13.67

14.44

15.20

16.72

18.25

19.00

20.46

21.28

22.80

25.08

1.0

1.5

2.0

3.0

4.0

5.0

MAX NOISE

DENSITY AT

Iz = 250 µA

µVz /

√

MAX REGULATOR

CURRENT Izm

(mAdc)

35.0

31.8

29.0

27.4

26.2

24.8

21.6

20.4

19.0

17.5

16.3

15.4

14.5

13.2

12.5

11.9

10.8

9.9

9.5

8.8

8.5

7.9

7.2

120.0

110.0

100.0

95.0

90.0

85.0

80.0

75.0

70.0

65.0

60.0

55.0

50.0

45.0

1. Package Style

DO-7

2. Vz tolerance: ± 5%

. Forward Voltage (VF) Maximum 1.0 Vdc

(1N4614 – 1N4627 IF = 100 mA; 1N4099 – 1N4121 IF = 200 mA)

4. Noise Density measured from 1000 to 3000 Hz.

5. MILITARY SCREENING AVAILABLE.

P.O. BOX 609

•

ROCKPORT, MAINE 04856

•

207-236-6076

•

FAX 207-236-9558
