Lift |
Spacing 5.0 mm
AK370/..-5.0-V-GREEN-HC
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.14 mm²
2.5 mm²
0.14mm²
1.5 mm²
0.25 mm²
1.5 mm²
Order Data (Spacing 5.0 mm)
Insulating Material
Material
Flammability Class
PA 6.6
2
13.10
18.10
23.10
28.10
33.10
38.10
43.10
48.10
53.10
58.10
63.10
AK370/2-5.0-V-GREEN-HC
AK370/3-5.0-V-GREEN-HC
AK370/4-5.0-V-GREEN-HC
AK370/5-5.0-V-GREEN-HC
AK370/6-5.0-V-GREEN-HC
AK370/7-5.0-V-GREEN-HC
AK370/8-5.0-V-GREEN-HC
AK370/9-5.0-V-GREEN-HC
AK370/10-5.0-V-GREEN-HC
AK370/11-5.0-V-GREEN-HC
AK370/12-5.0-V-GREEN-HC
Poles
Width (mm)
Article Designation
Article
Number
50370020009 E
50370030009 E
50370040009 E
50370050009 D
50370060009 D
50370070009 D
50370080009 D
50370090009 D
50370100009 D
50370110009 D
50370120009 D
PU
100
100
100
50
50
50
50
50
50
50
50
UL 94 V-0
3
4
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
7
Dimensions
Stripped Length
PCB Hole Diameter
6.0 mm
1.3 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
8
9
10
11
12
Materials
Clamp
Screw
Solder Tab
Brass
Steel
Copper
Alloy
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
Accessoires
-
Figure
Designation
Bridge, 2-pole, insulated,
BRI/2-5.0/5.08-LIGHT GREY
Article Number
Order Data: 50000000006
Colours
GREEN, RAL 6018
LIGHT GREEN, similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
Bridge, 3-pole, insulated,
BRI/3-5.0/5.08-LIGHT GREY
Order Data: 50000000007
Bridge, 2-pole,
BR/2-5.0/5.08-L7.0
Order Data: 50000000008
Ratings
UseGroup
Rated Voltage
Rated Current
Rated Wire Size
- solid
- stranded
Torque
Screw Size
Test Voltage
B
300 V
19 A
C
150 V
19 A
D
300 V
10 A
min
250 V
24 A
max
2.5 mm²
1.5 mm²
0.50 Nm
M3
2.0 kV
AWG 22-12
AWG 22-12
0.50 Nm
M3
1.60 kV
AWG 22-12
AWG 22-12
0.50 Nm
M3
1.30 kV
AWG 22-12
AWG 22-12
0.50 Nm
M3
1.60 kV
0.5 mm²
0.5 mm²
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
