Spacing 3.5 mm
AK1710/..-3.5-GREEN
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.14 mm²
1.5 mm²
0.14mm²
1.5 mm²
0.25 mm²
1.0 mm²
Order Data (Spacing 3.5 mm)
Insulating Material
Material
Flammability Class
PA 6.6
UL 94 V-0
Poles
2
3
4
5
Width (mm)
7.00
10.50
14.00
17.50
21.00
24.50
28.00
31.50
35.00
38.50
42.00
45.50
49.00
52.50
56.00
59.50
63.00
66.50
70.00
Article Designation
AK1710/2-3.5-GREEN
AK1710/3-3.5-GREEN
AK1710/4-3.5-GREEN
AK1710/5-3.5-GREEN
AK1710/6-3.5-GREEN
AK1710/7-3.5-GREEN
AK1710/8-3.5-GREEN
AK1710/9-3.5-GREEN
AK1710/10-3.5-GREEN
AK1710/11-3.5-GREEN
AK1710/12-3.5-GREEN
AK1710/13-3.5-GREEN
AK1710/14-3.5-GREEN
AK1710/15-3.5-GREEN
AK1710/16-3.5-GREEN
AK1710/17-3.5-GREEN
AK1710/18-3.5-GREEN
AK1710/19-3.5-GREEN
AK1710/20-3.5-GREEN
Article Number PU
51710020001 F
51710030001 F
51710040001 F
51710050001 F
51710060001 E
51710070001 E
51710080001 D
51710090001 D
51710100001 D
51710110001 D
51710120001 D
51710130001 D
51710140001 D
51710150001 D
51710160001 D
51710170001 D
51710180001 D
51710190001 D
51710200001 D
200
200
200
200
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
6
7
8
Dimensions
Stripped Length
7.0 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
9
10
11
12
13
Materials
Clamp
Screw
Contact Spring
Brass
Bronze
Bronze
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
14
15
16
17
Colours
GREEN, RAL 6018
LIGHT GREY, RAL 7035
LIGHT GREEN, similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
18
19
20
Accessoires
Figure
Designation
Series AK(Z)1710 with pull relief
Article Number
Order Data: on request
Counterparts (Spacing 3.5 mm)
Pin Strip
STL1550
In combination of connectors with different admission data, the lower value is valid.
Bridge, 2-pole, BR/2-3.5/3.81-L7.5
Order Data:
50000000015
Bridge, 3-pole, BR/3-3.5/3.81-L7.5
Order Data:
50000000016
Bridge, 2-pole, insulated,
BRI/2-7.0/7.62-L7.5-LIGHT GREY
Order Data:
50000000018
Bridge, 2-pole, angled,
BR/2-3.5/3.81-H-L7.5
Order Data:
50000000029
Ratings
UseGroup
Rated Voltage
Rated Current
Overvoltage Category
Rated Wire Size
- solid
- stranded
Torque
Screw Size
Test Voltage
Pollution Degree
B
300 V
8A
C
-
-
D
300 V
8A
160 V
8A
III
min
max
1.5 mm² (8 A)
1.5 mm² (8 A)
0.25 Nm
M2
2.5 kV
3
AWG 28-16
AWG 28-16
0.25 Nm
M2
1.60 kV
-
-
-
-
-
AWG 28-16
AWG 28-16
0.25 Nm
M2
1.60 kV
0.5 mm² (6 A)
0.5 mm² (6 A)
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
