Excenter |
Spacing 15.0 mm
AK2200/..-15.0-V-GREEN
- 2- to n-poles
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.2 mm²
4.0 mm²
0.2mm²
2.5 mm²
0.25 mm²
2.5 mm²
Order Data (Spacing 15.0 mm)
Insulating Material
Material
Flammability Class
PA 6.6
2
22.50
37.50
52.50
67.50
82.50
97.50
112.50
127.50
142.50
157.50
172.50
AK2200/2-15.0-V-GREEN
AK2200/3-15.0-V-GREEN
AK2200/4-15.0-V-GREEN
AK2200/5-15.0-V-GREEN
AK2200/6-15.0-V-GREEN
AK2200/7-15.0-V-GREEN
AK2200/8-15.0-V-GREEN
AK2200/9-15.0-V-GREEN
AK2200/10-15.0-V-GREEN
AK2200/11-15.0-V-GREEN
AK2200/12-15.0-V-GREEN
Poles
Width (mm)
Article Designation
Article
Number
52200020061 D
52200030061 D
52200040061 D
52200050061 D
52200060061 D
52200070061 D
52200080061 D
52200090061 D
52200100061 D
52200110061 D
52200120061 D
PU
50
50
50
50
50
50
50
50
50
50
50
UL 94 V-0
3
4
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
7
Dimensions
Stripped Length
PCB Hole Diameter
9.0 mm
1.3 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
8
9
10
11
12
Materials
Screw
Solder Tab
Clamp Cage
Excenter
Steel
Copper
Alloy
Steel
Steel
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
Accessoires
-
Figure
Designation
Spacer SPC-AK2200-GREEN
Article Number
Order Data: 52200000002
Colours
GREEN, RAL 6018
BLACK, RAL 9011
LIGHT GREEN, similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
Ratings
*
UseGroup
Rated Voltage
Rated Current
Rated Wire Size
- solid
- stranded
Torque
Screw Size
Test Voltage
B
600 V
20 A
C
-
-
D
600 V
5A
min
1000 V
24 A
max
2.5 mm²
2.5 mm²
0.50 Nm
M2.5
3.5 kV
AWG 30-12
AWG 30-12
0.50 - 0.60 Nm
M2.5
2.20 kV
-
-
-
-
-
AWG 30-12
AWG 30-12
0.50 - 0.60 Nm
M2.5
2.20 kV
0.5 mm²
0.5 mm²
* Data similar to UL 1059 (XCFR2.E101811) und CSA 22.2 No. 158 (XCFR8.E101811)
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
