Tension Spring |
Spacing 5.0 mm
AK3001/..KD-5.0-PEBBLE GREY
- 1- to n-poles
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.08 mm²
2.5 mm²
0.14mm²
2.5 mm²
0.14 mm²
1.5 mm²
Order Data (Spacing 5.0 mm)
Insulating Material
Material
Flammability Class
PA 6.6
1
7.90
12.90
17.90
22.90
27.90
32.90
37.90
42.90
47.90
52.90
57.90
62.90
67.90
72.90
77.90
82.90
87.90
92.90
97.90
102.90
107.90
112.90
117.90
122.90
Poles
Width (mm)
Article Designation
AK3001/1KD-5.0-PEBBLE
GREY
AK3001/2KD-5.0-PEBBLE
GREY
AK3001/3KD-5.0-PEBBLE
GREY
AK3001/4KD-5.0-PEBBLE
GREY
AK3001/5KD-5.0-PEBBLE
GREY
AK3001/6KD-5.0-PEBBLE
GREY
AK3001/7KD-5.0-PEBBLE
GREY
AK3001/8KD-5.0-PEBBLE
GREY
AK3001/9KD-5.0-PEBBLE
GREY
AK3001/10KD-5.0-PEBBLE
GREY
AK3001/11KD-5.0-PEBBLE
GREY
AK3001/12KD-5.0-PEBBLE
GREY
AK3001/13KD-5.0-PEBBLE
GREY
AK3001/14KD-5.0-PEBBLE
GREY
AK3001/15KD-5.0-PEBBLE
GREY
AK3001/16KD-5.0-PEBBLE
GREY
AK3001/17KD-5.0-PEBBLE
GREY
AK3001/18KD-5.0-PEBBLE
GREY
AK3001/19KD-5.0-PEBBLE
GREY
AK3001/20KD-5.0-PEBBLE
GREY
AK3001/21KD-5.0-PEBBLE
GREY
AK3001/22KD-5.0-PEBBLE
GREY
AK3001/23KD-5.0-PEBBLE
GREY
AK3001/24KD-5.0-PEBBLE
GREY
Article
Number
53001010001 G
53001020001 F
53001030001 F
53001040001 F
53001050001 E
53001060001 E
53001070001 E
53001080001 D
53001090001 D
53001100001 D
53001110001 D
53001120001 D
53001130001 D
53001140001 D
53001150001 D
53001160001 D
53001170001 D
53001180001 D
53001190001 D
53001200001 D
53001210001 D
53001220001 D
53001230001 D
53001240001 D
PU
250
200
200
200
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
UL 94 V-0
2
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
3
4
5
6
7
8
9
10
Dimensions
Stripped Length
PCB Hole Diameter
6.0 mm
1.1 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
Materials
Solder Tab
Tension Spring
Copper
Alloy
Stainless
Steel
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
Colours
PEBBLE GREY, RAL 7032
GREY, RAL 7016
LIGHT GREEN, similar RAL 6018
GREEN, RAL 6018
RED, RAL 3003
11
12
13
14
15
ORANGE, RAL 2011
BLUE, RAL 5015
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
16
17
18
19
20
21
22
23
24
Accessoires
Figure
Designation
Bridge, 2-pole, insulated,
BRI/2-5.0/5.08-LIGHT GREY
Article Number
Order Data: 50000000006
Ratings
Bridge, 3-pole, insulated,
BRI/3-5.0/5.08-LIGHT GREY
UseGroup
Rated Voltage
Rated Current
Rated Wire Size
- solid
- stranded
Test Voltage
AWG 28-14
AWG 28-14
1.60 kV
-
-
-
AWG 28-14
AWG 28-14
1.60 kV
B
300 V
15 A
C
-
-
D
300 V
10 A
250 V
Order Data: 50000000007
Bridge, 2-pole,
BR/2-5.0/5.08-L7.0
min
0.5 mm²
0.5 mm²
24 A
Order Data: 50000000008
max
2.5 mm²
2.5 mm²
2.0 kV
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
